norix PROT200 Series Assembly Instructions

www.norix.com ● TEL 800 234-4900
Assembly Notes:
Norix is not responsible for any damage due to improper installation. If your shipment does not match the parts list, please contact Norix Customer Service at 800-234-4900.
Norix reserves the right to modify design specifications at any time without an obligation to owners of previously sold products.
___________________________________________________________________________________________________________________________________________________________________________________________________
ITEM
NO. QTY REV
A 4 A
B 1 A
C 1 A
D 1 A
E 3 A
F 3 A
G 5 A
H 5 A
I 2 A
J 9 A
K 1 A
L 1 A
M 2 A
N 2 A
O 2 B
P 1 A
Q 1 A
R 3 A
S 2 A
Note: Do not tighten screws until assembly is complete.
This product requires two people for final assembly
Rev. B - 4/3/14
091-823
Assembly Instructions
See PROT100-XX and Assemle First
PART NUMBER
036-PT002-XX Protege II Vertical Connector
030-PT002-XX Protege II Long Safety Rail
030-PT003-XX Protege II Short Safety Rail
036-PT003-XX Protege II Ladder
Screw, Machine, 5/16-18 X 4", CH, 5mm Hex Socket,
021-129
Black Oxide
025-042 Washer, Radius 1-1/2", 3/8" ID x 1-3/16" OD, Black Oxide
Screw, Machine, 5/16-18 X 2-3/4", CH, 5mm Hex Socket,
021-128
Black Oxide
025-043 Washer, Flat, 3/8" ID x 11/16" OD, Black Oxide
Screw, Machine, 1/4-20 X 2-3/4", CH, 4mm Hex Socket,
021-130
Black Oxide
025-041 Washer, Flat, 1/4" ID x 5/8 OD, Black Oxide
Nut, Barrel 1/4-20 X.875", 5/16" OD, 4mm Hex Socket,
021-134
Black Oxide
Screw, Machine, 1/4-20 X .625", CH, 4mm Hex Socket,
021-133
Black Oxide
030-PT004-XX Protege II Wall Bracket
025-044 Nut, Lock, 1/4-20, Black Oxide
Screw, Machine, 1/4-20 X 2-1/2", CH, 4mm Hex Socket,
021-131
Black Oxide
071-016 Allen Wrench, 4mm
071-017 Allen Wrench, 5mm
060-194 Spacer Tube, Protege II 1/2" OD x 3/8" ID x 2-13/16
Screw, Machine, 1/4-20 X 1", CH, 4mm Hex Socket,
021-132
Black Oxide
Protege II Bunked
Model Number
PROT200-XX
PARTS LIST
DESCRIPTION
Page 1 of 5
