CanyCom SC75PD Operator's Manual page 20

Controls and Components
3 Clutch Lever . . . . . . . . . . . . Disengages the clutch to help start the engine in the cold.
4 Control Stick. . . . . . . . . . . . Control stick is used to control the traveling direction
5 Parking Brake Lever . . . . . Parking brake lever is used to park the machine securely.
6 Throttle Lever . . . . . . . . . . . Throttle lever is used to control the engine speed.
7 Engine Oil Warning Lamp . L i g h t s u p w h e n t h e M a i n S w i t c h i s t u r n e d t o t h e
8 Main Switch . . . . . . . . . . . . Main switch is used to start or stop the engine.
9 Choke Knob . . . . . . . . . . . . Pulling the choke knob closes the choke valve to help start
10 Horn Button . . . . . . . . . . . . Pressing this button sounds the horn. Use this for warning
11 Fuel Gauge . . . . . . . . . . . . . Displays the amount of fuel in the tank.
12 Hour Meter . . . . . . . . . . . . . Hour meter displays and records the total amount of time
(forward or backward, as well as left or right) and speed of
the machine.
[ (run)] position. If there is no problem, it goes off when
the engine is started. If a problem is detected when the
engine is running, it lights up.
the engine in the cold weather. Push the knob back to
open the valve once the engine starts.
during traveling or signaling during operation.
the machine has been in use, in the unit of 0.1 hour.
