Printed Matter No. 9839 0470 01
Valid from Serial No.
2017-06-10
MT Focus 6000
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
MT Focus 6000
8432085100
WARNING
Control and drive unit
Product Instructions
Advertisement
Table of Contents
Related Manuals for Atlas Copco MT Focus 6000
Summary of Contents for Atlas Copco MT Focus 6000
- Page 1 MT Focus 6000 Printed Matter No. 9839 0470 01 Control and drive unit Valid from Serial No. Product Instructions 2017-06-10 MT Focus 6000 8432085100 WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
Ergonomic guidelines ............ 13 Service .................. 14 Preventing ESD problems ............. 14 Maintenance instructions............ 14 Service recommendations ........... 14 Recycling .................. 15 Recycling instruction ............. 15 Recycling information ............ 15 © Atlas Copco Industrial Technique AB - 9839 0470 01... -
Page 3: Product Information
• To avoid damage or destruction of tool parts, service the tool according to the recommended maintenance schedules and follow the correct instruc- tions. • Warranty repairs are only performed in Atlas Copco workshops or by Certi- fied Service Partners. Atlas Copco offers extended warranty and state of the art preventive mainte- nance through its ToolCover contracts. -
Page 4: Servaid
ServAid is available on DVD and on the website: https://servaid.atlascopco.com For further information contact your Atlas Copco sales representative or e-mail us at: servaid.support@se.atlascopco.com Website Log in to Atlas Copco: www.atlascopco.com. -
Page 5: On/Off Switch On Power Supply Unit
On/off switch on power supply unit The on/off switch to the controller is located on the external power supply unit (PSU). The on/off switch on the PSU must be easy to access. © Atlas Copco Industrial Technique AB - 9839 0470 01... -
Page 6: Compatible Tools
MT Focus 6000 is compatible with the following tools: • ETD M xxx V2 • QMC 21 • QMC 41 The tool must be calibrated for running with MT Focus 6000. Normal environmental conditions This product is designed to be safe under the following conditions: • Indoor use •... -
Page 7: Installation
+24V IO DO COMMON 0-3 DO COMMON 4-7 DO 0 DO 1 DO 2 DO 3 DO 4 DO 5 DO 6 DO 7 DI 0 DI 1 DI 2 © Atlas Copco Industrial Technique AB - 9839 0470 01... - Page 8 NPN mode (sink type, negative logic). PNP and NPN mode can, if required, be mixed bank wise (for example DO COMMON 0-3 PNP and DO COMMON 4-7 NPN). PNP mode Description +24V IO +24V output © Atlas Copco Industrial Technique AB - 9839 0470 01...
- Page 9 DO 0-7 The outputs will be connected to the external 0 V when activated. DI 0-11 The inputs will be activated by a 0 V signal applied to the input pin. © Atlas Copco Industrial Technique AB - 9839 0470 01...
- Page 10 The ethernet connection is used to connect the controller to the factory network. VP - Vacuum pump output 5-pole socket connector for the connection with Atlas Copco Vacuum pump. Use a 5-pole pin plug from the Binder 719 Series. Signal...
- Page 11 The IAM MT may store: • Necessary software for the MTF 6000 • Configuration data • Result database • Trace database • License and MAC-address. © Atlas Copco Industrial Technique AB - 9839 0470 01...
-
Page 12: Controller Connectors
Some functions in the controller, such as the built-in clock, are powered by a built-in battery. The charging time is 5 hours and the function is maintained for 100 days if not recharged. © Atlas Copco Industrial Technique AB - 9839 0470 01... -
Page 13: Operation
Adapt the torque setting to the operator's strength and posture and use a torque arm or reaction bar if the torque is too high. • Use dust extraction system or mouth protection mask in dusty environments. © Atlas Copco Industrial Technique AB - 9839 0470 01... -
Page 14: Service
If no detailed information about preventive maintenance is included, follow these general guidelines: • Clean appropriate parts accurately • Replace any defective or worn parts © Atlas Copco Industrial Technique AB - 9839 0470 01... -
Page 15: Recycling
Clamps Stainless steel Display WEEE Housing Aluminum IAM MT lid Polypropylene Front panel WEEE Main board WEEE Hexagon spacing nut (4 pcs) Brass Back plate Stainless steel Screw Stainless steel © Atlas Copco Industrial Technique AB - 9839 0470 01... - Page 16 Recycling MT Focus 6000 Part Recycle as Connector sleeve Stainless steel Screw Stainless steel Screw Stainless steel LiIon battery WEEE Screws Steel Foot weight Zink © Atlas Copco Industrial Technique AB - 9839 0470 01...
- Page 20 Original instructions Atlas Copco Industrial © Copyright 2017, Atlas Copco Industrial Technique AB. All rights reserved. Any Technique AB unauthorized use or copying of the contents or part thereof is prohibited. This SE-10523 STOCKHOLM applies in particular to trademarks, model denominations, part numbers and drawings.
