  • Page 1 FDS-3G...KS Fire Damper FDS-3G with Kit-S Handbook...

  • Page 2: Table Of Contents

    2/56 | FDS-3G...KS Table of Contents Overview ............3 Technical Parameters .

  • Page 3: Material Composition

    3/56 | FDS-3G...KS Description Fire dampers with square Kit up to size 800x600 mm represent passive fire protection, designed with the help of compartmentalization to prevent the spread of toxic gases, smoke and fire. FDS-3G...KS fire dampers installation is designed with simplicity in mind. Standard fire dampers are designed and certified in accordance with EN 15650 and tested for EIS criteria according to EN 1366–2.

  • Page 4: Activation Types

    4/56 | FDS-3G...KS Highlights • Fast installation rated EI60S, EI90S, EI120S • Casing tightness class C as standard • Exceptionally low pressure drop • Changeable mechanism • Two inspection openings for all sizes greater than 200x200 mm • Modulated actuator suitable for system balancing - possibility to open the blade at the desired angle. Activation Types Manually Operated Fire Dampers By default, all manually operated fire dampers are supplied with manual control, optionally with micro switches and...
  • Page 5 5/56 | FDS-3G...KS Fire damper with an activation mechanism with a Belimo or Gruner spring return actuator (24V AC/DC) with an electro- thermal fuse 72°C and auxiliary switches, with provided cable connectors for the supply and communication unit (communication unit not part of the mechanism). •...

  • Page 6: Technical Parameters

    6/56 | FDS-3G...KS Technical Parameters Durability test • 50 cycles/manually operated activation mechanism – with no change of the required properties • 10000 + 100 + 100 cycles/actuator operated activation mechanism – with no change of the required properties • 20 000 cycles/modulated actuator (B24T-SR-KS and G24T-SR-KS) – with no change of the required properties Fire testing pressure Underpressure up to 300 Pa Safety position...
  • Page 7 7/56 | FDS-3G...KS Blade tightness (STN EN 1751) Class 2 as standard Tightness of the housing (STN EN 1751) Class C as standard Conformity with EC directives 2006/42/EC Machinery Directive 2014/35/EU Low Voltage Directive 2014/30/EU Electromagnetic Compatibility Directive Modulated Actuator Can be set to any position when opening the blade - see types of activation mechanisms B24T-SR-KS/G24T-SR-KS Driving actuator types Belimo: BLF230-T, BLF24-T, BFL24-SR-T, BF230-T, BF24-T, BF24-SR-T, BFN230-T, BFN24-T, BFN24-T, BFL230-T, BFL24-...
  • Page 8 8/56 | FDS-3G...KS Legend P1 Blade P2 Casing P3 Manually operated activation mechanism (H0;H...)
  • Page 9 9/56 | FDS-3G...KS P4 Actuator operated activation mechanism (B...;G...) P5 Inspection lid P6 Thermoelectric fuse (BAT72;TA-72) P7 Supply and communication unit (BKN230-24;FS-UFC24-2) P9 Release and test button P10 Crank P11 Open position P12 Closed position P13 Hexagon bent wrench No.10 (not part of delivery) P14 Kit Base plate P15 Cover plate (PROMAT) P16 Intumex...
  • Page 10 10/56 | FDS-3G...KS Assessed Performance - FDS-3G 19 CE 1396 Systemair Production a.s. Hlavná 371, 900 43 Kalinkovo, Slovakia 1396-CPR-0163, FDS-3G (valid for subgroups: …EX, …KS, …OF) EN 15650 : 2010 Rectangular fire dampers Pass Nominal activation conditions/sensitivity • sensing element load bearing capacity •...

  • Page 11: Diagrams

    11/56 | FDS-3G...KS Diagrams The pressure drop and A-weighted total discharged sound power level depend on the nominal width and height of the damper and air flow volume at different duct pressures. The type of activation does not influences the airflow parameter, therefore only one activation type is shown in the diagrams.
  • Page 12 12/56 | FDS-3G...KS FDS-3G-...-KS FDS-3G-...-KS Pressure drop & A-weighted sound power level in dB(A) Pressure drop & A-weighted sound power level in dB(A) 1000 2000 2000 3000 5000 W: 800, H: 200 W: 800, H: 100 W: 800, H: 400 W: 800, H: 500 W: 800, H: 600 W: 800, H: 300 1000...

  • Page 13: Dimensions & Weights

    13/56 | FDS-3G...KS Free area W (mm) 100 150 200 250 300 315 350 355 400 450 500 550 560 600 630 650 700 710 750 800 0,007 0,010 0,014 0,018 0,022 0,023 0,026 0,026 0,030 0,030 0,034 0,037 0,038 0,041 0,043 0,044 0,048 0,049 0,051 0,055 0,011 0,015 0,021 0,027 0,033 0,034 0,038 0,039 0,044 0,047 0,052 0,058 0,059 0,063 0,066 0,068 0,074 0,075 0,079 0,085 0,013 0,019 0,026 0,033 0,040 0,042 0,047 0,048 0,054 0,058 0,064 0,071 0,072 0,078 0,082 0,084 0,091 0,092 0,098 0,104 0,014 0,019 0,027 0,034 0,041 0,043 0,048 0,049 0,056 0,060 0,067 0,074 0,075 0,081 0,085 0,087 0,094 0,096 0,101 0,108...
  • Page 14 14/56 | FDS-3G...KS...
  • Page 15 15/56 | FDS-3G...KS {dimensions} H (mm) R1 (mm) -188 -163 -150 -148 -143 -118 -93 R2 (mm) Weights W (mm) (kg ±10%) 100 150 200 250 300 315 350 355 400 450 500 550 560 600 630 650 700 710 750 800 7,1 7,9 8,8 9,6 10,5 10,8 11,4 11,5 12,3 13,2 14,0 14,9 15,1 15,8 16,3 16,5 17,6 17,8 18,4 19,3 9,1 9,9 10,8 11,6 12,5 12,8 13,4 13,5 14,3 15,2 16,0 16,9 17,1 17,8 18,3 18,5 19,6 19,8 20,4 21,3 7,9 8,8 9,7 10,7 11,7 11,9 12,6 12,7 13,5 14,5 15,4 16,3 16,5 17,4 17,9 18,1 19,2 19,4 20,1 21,0...

  • Page 16: Ordering Code

    16/56 | FDS-3G...KS Ordering Code A - Damper type W - Width Dimension from 100 mm up to 800 mm H - Height Dimension from 100 mm up to 600 mm B - Type of Activation (H0 up to B24T-SR) H0-KS (Manual crank, no switches) H2-KS (Manual crank, 2 switches 230V AC or 24V AC/DC) H5-2-KS (Manual crank, 24V AC/DC electromagnet, 2 switches 230V AC or 24V AC/DC)
  • Page 17 17/56 | FDS-3G...KS Inspection opening possitions (Removable mechanism is available for all sizes) W and H < 200 No inspection openning. Inspection possible through removable mechanism or additional inspection opening must be added to the conecting duct. W and H ≥ 200 Standardardly in position: BR and TR;...

  • Page 18: Installation

    18/56 | FDS-3G...KS Installation Methods EI 60 (v i ↔ o) S FDS-3G...KS EI 90 (v i ↔ o) S 100 × 100 ..800 × 600 360° 4 Kit EI 120 (v i ↔ o) S Legend: 4. Kit - Kit Installation, using an Installation Kit a) - Flexible (plasterboard) wall b) - Concrete/masonry/cellular concrete (rigid) wall - Vertical wall...
  • Page 19 19/56 | FDS-3G...KS Installation 4 - Kit Installation Using an Installation Kit IMPORTANT: The installation kit can not be delivered separately!The installation kit is delivered pre-mounted on a damper. 1. The supporting construction opening must be prepared as depicted. Opening surfaces must be even and cleaned off.
  • Page 20 20/56 | FDS-3G...KS...
  • Page 21 21/56 | FDS-3G...KS...
  • Page 22 22/56 | FDS-3G...KS...
  • Page 23 23/56 | FDS-3G...KS Legend F1 Screw ≥ 5,5 DIN7981 or suitable wall plug and screw size 6. 1 Fire damper with KIT (factory fitted) 2 Kit base plate - fixed directly onto the wall 3 Concrete/masonry/cellular concrete wall or ceiling 4 Flexible (plasterboard) wall 4a 2 layers of plasterboard fireproof plate type F, EN 520 4b Vertical CW –...
  • Page 24 24/56 | FDS-3G...KS 4d Mineral wool; thickness/cubic density see picture. Notes a) - Flexible (plasterboard) wall b) - Concrete/masonry/cellular concrete (rigid) wall - Vertical wall...
  • Page 25 25/56 | FDS-3G...KS...

  • Page 26: Electrical Connections

    26/56 | FDS-3G...KS Electrical Connections W (mm) T/PC/A B230T-KS/6,5 VA/BFL230-T B24T-KS/4 VA/BFL24-T B24T-W-KS/4 VA/BFL24-T-ST H (mm) B24T-SR-KS/6,5 VA/BFL24-T-SR...
  • Page 27 27/56 | FDS-3G...KS W (mm) T/PC/A G230T-KS/9,5 VA/340TA-230-05... G24T-KS/9 VA/340TA-024-05... G24T-W-KS/9 VA/340TA-024-05...ST01 H (mm) GST0-KS/11 VA/340TA-024-05...ST01 + fs-UFC24-2 G24T-SR-KS/7,5 VA/340CTA-024-05... NOTE: T/PC/A - Activation Type / Power Consumption / Actuator Type of activation H0-KS This type of activation mechanism does not have any electrical equipment.

  • Page 28: Electrical Parameters

    28/56 | FDS-3G...KS Type of activation H2-KS IMPORTANT: Danger of electric shock! Switch off the power supply before working on any electrical equipment. Allow only qualified electricians to work on the electrical system. Microswitch:Power Supply: AC 125/250 V or DC 12/24 V Electric Parameters: 3A NOTES: •...
  • Page 29 29/56 | FDS-3G...KS Legend 1 Grey cable colour 2 Orange cable colour...
  • Page 30 30/56 | FDS-3G...KS 3 Pink cable colour 4 White cable colour 5 Red cable colour 6 Brown cable colour (Do not use for type of activation H2) X:7 Blue cable colour (Do not use for type of activation H2)
  • Page 31 31/56 | FDS-3G...KS Type of activation H5-2-KS IMPORTANT: Danger of electric shock! Switch off the power supply before working on any electrical equipment. Allow only qualified electricians to work on the electrical system. Microswitch: Power Supply: AC 125/250 V or DC 12/24 V Electric Parameters: 3A Impulse Electromagnet: Power Supply: AC (50/60 Hz)/DC 24 V...
  • Page 32 32/56 | FDS-3G...KS Legend 1 Grey cable colour 2 Orange cable colour 3 Pink cable colour 4 White cable colour 5 Red cable colour 6 Brown cable colour X:7 Blue cable colour...
  • Page 33 33/56 | FDS-3G...KS Type of activation H6-2-KS IMPORTANT: Danger of electric shock! Switch off the power supply before working on any electrical equipment. Allow only qualified electricians to work on the electrical system. Microswitch: Power Supply: AC 125/250 V or DC 12/24 V Electric Parameters: 3A Impulse Electromagnet: Power Supply: AC 230 V, 50/60 Hz...
  • Page 34 34/56 | FDS-3G...KS Legend 1 Grey cable colour 2 Orange cable colour 3 Pink cable colour 4 White cable colour 5 Red cable colour 6 Brown cable colour X:7 Blue cable colour...
  • Page 35 35/56 | FDS-3G...KS Type of activation B230T-KS IMPORTANT: Danger of electric shock! Switch off the power supply before working on any electrical equipment. Allow only qualified electricians to work on the electrical system. Actuator power supply: AC 230 V, 50/60 Hz NOTES: •...
  • Page 36 36/56 | FDS-3G...KS S2 Red cable colour S3 White cable colour S4 Orange cable colour S5 Pink cable colour S6 Grey cable colour Tf Thermal fuse...
  • Page 37 37/56 | FDS-3G...KS Type of activation G230T-KS IMPORTANT: Danger of electric shock! Switch off the power supply before working on any electrical equipment. Allow only qualified electricians to work on the electrical system. Actuator power supply: AC 230 V, 50/60 Hz NOTES: •...
  • Page 38 38/56 | FDS-3G...KS S3 White cable colour S4 Orange cable colour S5 Pink cable colour S6 Grey cable colour Tf Thermal fuse...
  • Page 39 39/56 | FDS-3G...KS Type of activation B24T-KS IMPORTANT: Danger of electric shock! Switch off the power supply before working on any electrical equipment. Allow only qualified electricians to work on the electrical system. Actuator power supply: AC (50/60 Hz)/DC 24 V NOTES: •...
  • Page 40 40/56 | FDS-3G...KS S3 White cable colour (white for BF24-T) S4 Orange cable colour (white for BF24-T) S5 Pink cable colour (white for BF24-T) S6 Grey cable colour (white for BF24-T) Tf Thermal fuse...
  • Page 41 41/56 | FDS-3G...KS Type of activation G24T-KS IMPORTANT: Danger of electric shock! Switch off the power supply before working on any electrical equipment. Allow only qualified electricians to work on the electrical system. Actuator power supply: AC (50/60 Hz)/DC 24 V NOTES: •...
  • Page 42 42/56 | FDS-3G...KS S3 White cable colour S4 Orange cable colour S5 Pink cable colour S6 Grey cable colour Tf Thermal fuse...
  • Page 43 43/56 | FDS-3G...KS Type of activation GST0-KS IMPORTANT: Danger of electric shock! Switch off the power supply before working on any electrical equipment. Allow only qualified electricians to work on the electrical system. This type of activation is with a Gruner supply and communication unit fs-UFC24-2 (other communication units on demand).
  • Page 44 44/56 | FDS-3G...KS Legend A1, A2 Analog Application; Digital input for manual override can be selected via bus as „Normally Open“ (= standard open) or „Normally Closed“ (= standard closed) Default: „Normally Open“ B Position of line termination 120 ohm if FS-UFC24-2 is last Modbus or BACnet device in line C RS-485 Coms;...
  • Page 45 45/56 | FDS-3G...KS P Main power 24 V AC/DC; Daisy chain from and to other FS-UFC24-2 So Contact open Sc Contact closed...
  • Page 46 46/56 | FDS-3G...KS Type of activation B24T-W-KS IMPORTANT: Danger of electric shock! Switch off the power supply before working on any electrical equipment. Allow only qualified electricians to work on the electrical system. This type of activation is with provided cable connectors for the supply and communication unit (communication unit not part of the mechanism).
  • Page 47 47/56 | FDS-3G...KS S1 Violet cable colour (white for BF24-T) in connector 2 S2 Red cable colour (white for BF24-T) in connector 2 S3 White cable colour (white for BF24-T) in connector 2 S4 Orange cable colour (white for BF24-T) in connector 2 S5 Pink cable colour (white for BF24-T) in connector 2 S6 Grey cable colour (white for BF24-T) in connector 2 Tf Thermal fuse...
  • Page 48 48/56 | FDS-3G...KS Type of activation G24T-W-KS IMPORTANT: Danger of electric shock! Switch off the power supply before working on any electrical equipment. Allow only qualified electricians to work on the electrical system. This type of activation is with provided cable connectors for the supply and communication unit (communication unit not part of the mechanism).
  • Page 49 49/56 | FDS-3G...KS S2 Red cable colour (white for BF24-T) in connector 2 S3 White cable colour (white for BF24-T) in connector 2 S4 Orange cable colour (white for BF24-T) in connector 2 S5 Pink cable colour (white for BF24-T) in connector 2 S6 Grey cable colour (white for BF24-T) in connector 2 Tf Thermal fuse...
  • Page 50 50/56 | FDS-3G...KS Type of activation B24T-SR-KS IMPORTANT: Danger of electric shock! Switch off the power supply before working on any electrical equipment. Allow only qualified electricians to work on the electrical system. Actuator power supply: AC (50/60 Hz)/DC 24 V NOTES: •...
  • Page 51 51/56 | FDS-3G...KS S6 Grey cable colour Tf Thermal fuse...
  • Page 52 52/56 | FDS-3G...KS Type of activation G24T-SR-KS IMPORTANT: Danger of electric shock! Switch off the power supply before working on any electrical equipment. Allow only qualified electricians to work on the electrical system. Actuator power supply: AC (50/60 Hz)/DC 24 V NOTES: •...
  • Page 53 53/56 | FDS-3G...KS S6 Grey cable colour Tf Thermal fuse...

  • Page 54: Operation Manual

    54/56 | FDS-3G...KS Operation Manual Warning To avoid injury, make sure to wear gloves and keep the blades movement area clear while manipulating with the damper.NEVER OPEN THE INSPECTION LID WHEN THERE IS AIR FLOWING IN THE DUCT CONNECTED TO THE FIRE DAMPER! Fire Damper Functionality Check Manually Operated Activation Mechanism 1.
  • Page 55 55/56 | FDS-3G...KS Due to the need to perform a visual check of the damper’s internal parts, open the inspection lid. For small sizes there is the possibility of removing the mechanism to perform the inspection. The removable mechanism always needs to be returned back into the damper with the damper blade being closed.
