Quick Installation Guide
KBox E-430-ADN
Thank you for purchasing the Kontron KBox E-430-ADN box PC. This document provides information to allow you to
quickly install this product.
Packing Checklist
1. Take the KBox E-430-ADN out of the packing box and check if the unit is properly secure in the plastic bag.
2. Check the contents of the carton box: (*: optional)
1x KBox E-430-ADN (corresponding to the ordered system configuration)
1x Power Terminal Block Plug Connector (attached on the system in case of not ordering power adapter)
1x Quick Installation Guide
1x Driver CD
1x Power Adapter* (power terminal block plug connector attached)
Memory Module* (It may be pre-installed in the system depending on ordered configuration.)
Internal 2.5" HDD / SSD* (It may be pre-installed in the system depending on ordered configuration.)
M.2 Key B Expansion Card / SSD* (It may be pre-installed in the system depending on ordered configuration.)
M.2 Key E Expansion Card* (It may be pre-installed in the system depending on ordered configuration.)
M.2 Key M SSD* (It may be pre-installed in the system depending on ordered configuration.)
Antenna(s)*
DIN Rail Mount Kit*
VESA Mount Kit*
Vertical Wall Mount Plate*
Horizontal Wall Mount Kit*
Quick Installation Guide - KBox E-430-ADN - - Rev. 1 - - 0D20KE430A010000
