COM Express® Eval Type 10
Document Revision 141
If it‟s embedded, it‟s Kontron.

Advertisement

Table of Contents
loading

Related Manuals for Kontron COM Express Eval 10

Summary of Contents for Kontron COM Express Eval 10

  • Page 1 COM Express® Eval Type 10 Document Revision 141 If it‟s embedded, it‟s Kontron.

  • Page 2: Table Of Contents

    Connectors and Features ..............16 Power supply ........................16 5.1.1 ATX connector ........................16 5.1.2 PS_ON override & S5 Eco ......................17 5.1.3 Reset and Power button ......................18 5.1.4 LID and Sleep ........................19 COM Express® connector ......................20 www.kontron.com...
  • Page 3 High Definition Audio ......................24 Ethernet ..........................26 USB ............................ 27 PCI ............................. 28 5.10 PCIexpress and Express Card ....................29 5.11 Kontron Feature connector ...................... 31 5.12 DVI-D ..........................33 5.13 LVDS ..........................34 5.14 External BIOS ........................35 5.15...

  • Page 4: User Information

    “as-is” and is subject to change without notice. For the circuits, descriptions and tables indicated, Kontron assumes no responsibility as far as patents or other rights of third parties are concerned.

  • Page 5: Warranty

    This Kontron Embedded Modules GmbH product is warranted against defects in material and workmanship for the warranty period from the date of shipment. During the warranty period, Kontron Embedded Modules GmbH will at its discretion decide to repair or replace defective products.

  • Page 6: Introduction

    Simply select a Type 1 or Type 10 COM Express® CPU module, then Plug & Go. The Kontron COM Express® Eval Type 10 is an evaluation backplane for COM Express® Computer-on-Modules following the PICMG COM.0 specification Rev 1.0 or Rev 2.0 with pin-out Type 1 or Type 10.

  • Page 7: Specification

    6 x USB 2.0/1.1 » 1 x USB Client » LPC Firmware Hub and SPI Flash support for external BIOS » Kontron feature connector » Front panel connectors (HDD Act., Reset and Power Switch) » Status LED » SD-Card Socket »...

  • Page 8: Block Diagram

    COM Express® Eval Type 10 / Specification Block Diagram HD Audio SPKR COM1 7.1 Analog (J73) SPK1 COM2 Audio Jack RS232 (J9) (J8) HD Audio Winbond Realtek Optical S/PDIF 83627 HD Audio ALC888 (J24) (J2) LPC-I/0 HD-Audio Codec S/PDIF in (FAN) (J81) (J11)

  • Page 9: Mechanical Specification

    COM Express® Eval Type 10 / Specification Mechanical Specification » Size: 243.8mm x 304.8mm » max height on top: 34.7mm (Connector J8) » PCB thickness: 1.4mm ±10%...
  • Page 10 COM Express® Eval Type 10 / Specification...

  • Page 11: Electrical Specification

    COM Express® Eval Type 10 / Specification Electrical Specification Supply Voltage » ATX Main Power 24pin » ATX_12V P4 connector (wide range input depends on module specification) Power Supply Rise time » The input voltages shall rise from ≤10% of nominal to within the regulation ranges within 0.1ms to 20ms. »...

  • Page 12: Environmental Specification

    COM Express® Eval Type 10 / Specification Environmental Specification Ambient temperature » Operating: 0 to +60 °C » Non-operating: -30 to +85 °C Humidity » Operating: 10% to 90% (non condensing) » Non operating: 5% to 95% (non condensing) MTBF The following MTBF (Mean Time Between Failures) values were calculated using a combination of manufacturer‟s test data, if the data was available, and a Bellcore calculation for the remaining parts.

  • Page 13: Connector Layout

    COM Express® Eval Type 10 / Connector Layout Connector Layout Rear Panel...

  • Page 14: Connector Locations

    COM Express® Eval Type 10 / Connector Layout Connector Locations...
  • Page 15 COM Express® Eval Type 10 / Connector Layout...

  • Page 16: Component Overview

    COM Express® Eval Type 10 / Connector Layout Component overview Connector Short Description B01-B09 Baseboard mounting holes Status LED: VCC 3.3V Status LED: VCC 5V Status LED: VCC 5V SBY Status LED: VCC 12V Module Status LED: VCC 12V Status LED: VCC 3.3V SBY Status LED: VCC 1.0V Status LED: VCC 1.5V Status LED: SUS_STAT#...
  • Page 17 PCIexpress Slot B (x16, electrically x1) PCIexpress Slot C (x1) SATA0 LVDS FFC40 SATA1 HDD Activity COM Express® AB connector for Type1/Type10 Computer-on-Modules Kontron Feature Connector PCI Slot0 PCI Slot 1 Power Button Front Panel connector Express Card ResetButton Front Panel connector SD-Card socket...
  • Page 18 COM Express® Eval Type 10 / Connector Layout SPK1 Speaker Power button Reset button POST Code back POST Code foward SLEEP Reset WDT Latch PEX8505 PCIe Switch PLX8112 PCIe2PCI Bridge Altera CPLD Winbond 83627 LPC-I/O...

  • Page 19: Connectors And Features

    COM Express® Eval Type 10 / Connectors and Features Connectors and Features Power supply 5.1.1 ATX connector The COM Express® Eval Type 10 power supply follows the ATX 2.x specification and the baseboard should be supplied by connecting an ATX PSU with 24pin ATX and 4pin ATX_12V supply cable in correct orientation. The 4pin ATX_12V connector mainly supplies power to the module over 0R resistor R876 and allows powering the module directly in specified wide range power input.

  • Page 20: Ps_On Override & S5 Eco

    COM Express® Eval Type 10 / Connectors and Features 5.1.2 PS_ON override & S5 Eco With PS_ON override jumper J14 it is possible to switch off the ATX power supply manually. Jumper J66 should be opened to test module S5Eco or single supply mode. In S5Eco mode all baseboard components (including status LED) are disconnected from standby voltages in S5 state.

  • Page 21: Reset And Power Button

    COM Express® Eval Type 10 / Connectors and Features 5.1.3 Reset and Power button The COM Express® Eval Type 10 provides an onboard Reset Button (SW1) and Power Button (SW2). To connect a front panel button from your chassis use J40 (Power) or J42 (Reset). Connector Function Power Button...

  • Page 22: Lid And Sleep

    COM Express® Eval Type 10 / Connectors and Features 5.1.4 LID and Sleep The specification update for PICMG COM.0 modules to revision 2.0 implements new signals for LID and Sleep. The low active signals can be simulated by switch 5 and 6 similar to notebook functionality of closing the lid or pressing the sleep button.

  • Page 23: Com Express® Connector

    COM Express® Eval Type 10 / Connectors and Features COM Express® connector The COM Express® Eval Type 10 is an evaluation backplane for Type 1 or Type 10 based Computer-on-Modules. Both types are module pin-outs based on one connectors with 2 rows (Row A and B) with 220 pins overall. Please refer to your module documentation for detailed pin-out descriptions.

  • Page 24: Status Led

    COM Express® Eval Type 10 / Connectors and Features Status LED The onboard main status and voltage LED D6-D21 indicates the current power state of the module and if all voltages are working correctly. Some additional status LED shows active or inactive slots and signals. See table below for detailed information.

  • Page 25: Serial Ata

    COM Express® Eval Type 10 / Connectors and Features Serial ATA The COM Express® Type 10 pin-out specification according to COM.0 specification revision 2.0 defines 2 SATA ports. The COM Express® Eval Type 10 provides two 7-pin SATA data connectors as standard 1.27mm Pitch Serial ATA High Speed Header with Locking Latch.

  • Page 26: Sd-Card / Module Gpio

    COM Express® Eval Type 10 / Connectors and Features SD-Card / Module GPIO The SD-Card standard is a standard for removable memory storages designed and licensed by the SD Card Association (http://sdcard.org). The card form factor, electrical interface and protocol are all part of the SD Card specification. COM Express®...

  • Page 27: High Definition Audio

    Note1: In addition to the default speaker settings, the analog audio Jacks can be reconfigured to perform different functions via the Realtek HDAudio Driver Software which is available on Kontron website. Only microphones still must be connected to the default pink jack.
  • Page 28 COM Express® Eval Type 10 / Connectors and Features Front Panel Audio Connector J4 The front panel audio connector J4 allows connecting a chassis front panel audio with analog microphone input and stereo speaker output. Description MIC2-L MIC2-R (MIC Power) PRESENCE# LINE2-R (LineOut-R) MIC2-JD...

  • Page 29: Ethernet

    COM Express® Eval Type 10 / Connectors and Features Ethernet The COM Express® Eval Type 10 provides a RJ45/Dual USB Combo with a single RJ45 in combination with 2 USB ports (USB 4/6). Ethernet Connector J61 with integrated magnetics and LED is configured to support modules with Gigabit Ethernet controller only.

  • Page 30: Usb

    COM Express® Eval Type 10 / Connectors and Features The COM Express® module's USB ports 0 to 3 are available on rear panel connector J7. USB port 5 is used on Express Card connector. The COM Express® Eval Type 10 provides USB port 4 and 6 on RJ45/USB Combo connector J61. Additionally USB7 is available on USB mini-A connector J3 as non-powered connector for USB client functionality.

  • Page 31: Pci

    COM Express® Eval Type 10 / Connectors and Features The mini size COM Express® form factor for Type 1 and Type 10 pin-out based modules does not specify an interface for PCI. Therefore on COM Express® Eval Type 10 a PLX8112 PCIexpress to PCI switch (U38) is used to provide two PCI Slots following the PCI 2.x specification.

  • Page 32: Pciexpress And Express Card

    COM Express® Eval Type 10 / Connectors and Features 5.10 PCIexpress and Express Card The COM Express® Eval Type 10 provides one PCIexpress x1 port, two PCIexpress x16 ports (electrically x1) and one Express Card Slot in different configuration. To allow usage of multiple PCIexpress connectors and PCI the PEX8505 PCIexpress switch (U31) is connected to module's PCIexpress Lane #0.
  • Page 33 COM Express® Eval Type 10 / Connectors and Features PCIexpress status LED The PCIexpress status LED D32-D37 shows active devices on available PCIexpress ports and if the PCIe switch is working correctly Description PCIe Switch Lane 4 good (PCIe Slot C) PCIe Switch Lane 3 good (PCIe Slot B) PCIe Switch Lane 2 good (Express Card) PCIe Switch Lane 1 good (PCIe2PCI Bridge)

  • Page 34: Kontron Feature Connector

    COM Express® Eval Type 10 / Connectors and Features 5.11 Kontron Feature connector The Kontron Feature connector provides additional interfaces such as I2C, SMBus or Power Control Signals. See the table below for detailed pin-out description Signal Level Signal Description...
  • Page 35 COM Express® Eval Type 10 / Connectors and Features Ground #ATA_ACT 3.3V-O Low active output signal, which indicates activity on IDE interfaces. #CB_RESET 3.3V-O Low active Reset output from module to carrier board...

  • Page 36: Dvi-D

    COM Express® Eval Type 10 / Connectors and Features 5.12 DVI-D On COM Express® Eval Type 10 the DVI output is available through a Silicon Image SiL1364/A SDVO to single link DVI PanelLink Transmitter. Check your module documentation if SDVO is available on DDI interface defined for Type 10 pin-out based modules.

  • Page 37: Lvds

    COM Express® Eval Type 10 / Connectors and Features 5.13 LVDS The 40-pin JILI LVDS panel connector J33 allows connecting a flat panel directly to the module's dual channel LVDS output. Check your module documentation for available BIOS configurations for this flat panel output. LVDS Signal LVDS Signal LCDDO13...

  • Page 38: External Bios

    Flashing the external BIOS: » Prepare a bootable USB flash drive and save BIOS and flash utility in the root folder Please check Application Note KEMAP046 avialble at Kontron's customer section for more details » Open J46/J75 to boot from the module's BIOS »...

  • Page 39: Serial Interface

    J83 and J84. J78 and J79 allow both interfaces to be used as 2-pin RS232 interfaces COMA and COMB with Kontron Adapter cable KAB-DSUB9-3. Please check the documentation of your module if this interface is supported and how to configure.

  • Page 40: Status & Debug Connector

    COM Express® Eval Type 10 / Connectors and Features 5.16 Status & Debug Connector For debugging and measurements some important status signals are available on pin-header J80 for direct access. Description Description +3.3V SBY TPM_PP SUS_STAT# WDT_LATCHED SUS_S3# RST_WDT_L# SUS_S4# SPKR SUS_S5# EXCD0_CPPE#...

  • Page 41: Cpld & Post-Code Display

    COM Express® Eval Type 10 / Connectors and Features 5.17 CPLD & POST-Code Display Power Management control, 4 digits LPC/PCI Port 80/81 Post Code and additional GPIOs are implemented in onboard Altera CPLD (U44). Port 80/81 POST Code display The 7-segment display D53/D54 for Port 81 and D40/41 for Port 80 shows BIOS status codes during boot-up process. Last 8 check codes are stored automatically and can be controlled by switch SW3 (Post Code step backward) and switch SW4 (Post code step forward).
  • Page 42 COM Express® Eval Type 10 / Connectors and Features J77 - CPLD I/O Port The I/O Port J77 provides 8 I/O ports directly from the CPLD without any functionality in default configuration. J7 pin Function J7 pin Function VCC 3.3V SBY CPLD_IO_PIN64 CPLD_IO_PIN66 CPLD_IO_PIN67...

  • Page 43: Winbond 83627 Super-I/O

    COM Express® Eval Type 10 / Connectors and Features 5.18 Winbond 83627 Super-I/O A Winbond 83627HFJ Super-I/O controller (U53) is connected to module's LPC bus to offer legacy interfaces like RS232 and parallel ports additionally to temperature, FAN and voltage monitoring features. The default SIO LPC address is 2Eh.

  • Page 44: Rs232

    COM Express® Eval Type 10 / Connectors and Features 5.18.1 RS232 With Winbond 83627 LPC-I/O two serial ports are supported. Both COM ports can be configured in module BIOS setup if Super-I/O support is implemented. Signal...

  • Page 45: Lpt

    COM Express® Eval Type 10 / Connectors and Features 5.18.2 LPT The Winbond 83627 LPC-I/O supports one parallel port available on baseboard's pin header J24. Use the optional available KAB-DSUB25-1 cable adapter to access the LPT port and check to module BIOS to configure the port resources.

  • Page 46: Fan

    COM Express® Eval Type 10 / Connectors and Features 5.18.3 FAN The COM Express® Eval Type 10 provides one 4-pin PWM FAN connector directly controlled by the LPC-I/O PWM output 1. If configuration jumper J60 is open (default) the PWM FAN J44 is controlled by the module FAN output specified in COM.0 revision 2.0 specification if supported by the module.

  • Page 47: Sio Debug Connectors

    COM Express® Eval Type 10 / Connectors and Features 5.18.4 SIO Debug connectors For debugging Winbond 83627 LPC-I/O GPIOs and FAN/Voltage interfaces are available via pin-header. J72 - GPIO J81 - FAN J82 - Voltage +3.3V SIO HWM IN - VCOREA SIO HWM IN - 12V SIO GP10 / JOAYABTN0 Module FAN_PWMOUT#...

  • Page 48: Fru-Prom (I2C Eeprom)

    COM Express® Eval Type 10 / Connectors and Features 5.19 FRU-PROM (I2C EEPROM) Following the new COM Express® specification the COM Express® Eval Type 10 provides an I2C EEPROM. The FRU-PROM (Field Replacable Unit; U76) at I2C address 07h can be used to store user specific data or baseboard configuration settings.

  • Page 49: Battery Information

    COM Express® Eval Type 10 / Battery Information Battery Information English: CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer‟s instructions.
  • Page 50 English, German, French, Danish, Finish and Spanish language. If the battery of this product however is accessible by the end user, it is in the responsibility of the Kontron customer to give the corresponding safety instructions in the required language(s).

  • Page 51: Module Single Supply And Wide Range

    VCC on J15 parallel to ATX supply J22 for the baseboard. Please check the documentation of your product if a wide range voltage input is supported. Kontron Computer-on- Modules usually supports: »...

  • Page 52: Compatibility Matrix

    The COM Express® Eval Type 10 supports Computer-on-Modules following PICMG COM.0 Revision 1.0 pin-out Type 1 or COM.0 revision 2.0 pin-out Type 10. See table below wich features are supported by Kontron's COM Express® mini form factor modules: Feature COMe-mSP1...

  • Page 53: Power Distribution

    COM Express® Eval Type 10 / Power Distribution Power Distribution...

  • Page 54: Security Advice

    COM Express® Eval Type 10 / Security Advice 10 Security Advice To protect the external power lines to peripheral devices the customer has to take care about: - The wires to the external device have the right diameter to withstand the max. available current - The housing of the external device fulfils the fire protection requirements of IEC/EN 60950.

  • Page 55: Document Revision History

    Poway, CA 92064-7147 Germany Beijing 100070, P.R.China Tel.: +49 (0)8165/ 77 777 Tel.: + 86 10 63751188 Tel.: +1 888 294 4558 Fax: +49 (0)8165/ 77 219 Fax: + 86 10 83682438 Fax: +1 858 677 0898 info@kontron.com info@kontron.cn info@us.kontron.com...
