TSC Printronix Auto ID PEX-2000 Series User Manual page 8

Printer
6-INCH: PEX-2260L/ PEX-2260R
4-INCH: PEX-2240L/ PEX-2240R
Item
Font & barcode rotation
Command set
Media type
Media wound type
Media width (Label and
Liner)
◼ Standard (Default): 0.076 mm - 0.305 mm (2.99 mil - 12.01mil)
Media thickness (Includes
◼ RFID tag: 0.076 mm - 1.2 mm (2.99 mil - 47.2mil), lift up the front gap sensor wall when thickness > 0.9mm
liner, if any)
◼ Ribbon saver: 0.076 mm - 0.3 mm (2.99 mil - 11.81 mil)
4-INCH:
Standard mode: 12.7mm - 152mm (0.5" - 6")
Label length (peel-off mode) Small label mode: 5mm - 12.7mm (0.2" - 0.5", mode switchable on the display)
6-INCH:
25.4mm - 152mm (1" - 6")
Label exit angle (peel-off
Angle adjustable: 15°
mode)
◼ The maximum unwind force: 940 g
Media Pull-in/pull out force
◼ The maximum rewind force: 1,840 g
The pulling forces in the label web must be applied evenly.
Gap height
Black mark height
Black mark width
RFID
RTC and Buzzer
TSPL-EZD (compatible to EPL, ZPL, ZPL II, DPL); Option for TSPL-EZS (compatible to EPL, ZPL, ZPL II, SBPL)
Continuous, die-cut, black mark, fan-fold, notch
RAIN UHF Passive (GS1 EPC Gen2 v2 / ISO 18000-63)
Minimum Label/Tag Pitch 0.625" (15.9mm)
6-INCH: PEX-2360L/ PEX-2360R
4-INCH: PEX-2340L/ PEX-2340R
0, 90, 180, 270 degree
Outside wound
4-INCH: 16mm - 118mm (0.63" - 4.64")
6-INCH: 50.8mm - 180mm (2" - 7.09")
Min. 2mm (0.79")
Min. 2mm (0.79")
Min. 8mm (0.31")
Fixed Position Antenna Standard
Standard
4-INCH: PEX-2640L/ PEX-2640R
6
