9 Ribbon Saver Function (Optional)
Ribbon saver is a function that enables the printer to save ribbon consumption when processing print job. The ribbon saver function
is only available when the ribbon saver kit is installed.
9.1 Ribbon Saver Operation
The drawing below illustrates the media/ribbon feed direction and the printhead position when the ribbon saver function is activated.
Feed Direction
A: The printhead is ascending.
B: The printhead keeps up.
C: The printhead is descending.
D: The printhead keeps down and prints data on the label.
E: The printhead still keeps down. To optimize the print quality, the printhead cannot ascend immediately after the D phase.
