TSC Printronix Auto ID PEX-2000 Series User Manual page 7

Printer
6-INCH: PEX-2260L/ PEX-2260R
4-INCH: PEX-2240L/ PEX-2240R
Item
◼ 512MB Flash memory
◼ 512MB DDR2 RAM memory
Memory
◼ USB device memory (FAT32)
◼ Micro SD card reader for memory expansion, up to 32GB
◼ RS-232 (Max. 115,200 bps )
◼ USB 2.0 (High speed mode)
Interface ◼ Internal Ethernet 10/100 Mbps
◼ USB host *2 (front and rear side), connecting USB storage device
◼ GPIO (DB15F) + Centronics
Auto sensing power supply (20% print ratio):
Power ◼ Input: AC 100-240V, 4-2A, 50-60Hz
◼ Output: DC 5V, 5A; DC 24V, 7A; DC 36V, 1.4A; Total 243W
◼ Multi-language selectable
LCD display ◼ 3.5" IPS QVGA color display
◼ 1 status indicator
Operation switch, button ◼ 6 operation buttons (Menu, Pause/Feed, Up, Down, Left, Right)
◼ Gap transmissive sensor (Position adjustable, 1 mm - 98 mm)
Black mark reflective sensor (Bottom or Top black mark sensor switchable and position adjustable, 5 mm - 92 mm)
◼
◼ Ribbon end sensor (transmissive)
Sensors ◼ Ribbon encoder sensor
◼ Head open sensor
◼ Media cover open sensor
◼ Label holder cover open sensor
◼ 8 alpha-numeric bitmap fonts
Built-in font ◼ One Monotype Imaging® CG Triumvirate Bold Condensed scalable font
◼ Built-in Monotype True Type Font engine
1D barcode:
Code 11, Code 39, Code 49, Code 93, Code128UCC, Code128 subsets A.B.C, Codabar, Standard 2 of 5, Industrial 2 of 5,
Interleave 2 of 5, EAN-8, EAN-13, EAN-14, EAN-128, ITF14, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI,
Barcode
PLESSEY, PLANET, POSTNET, RSS-Stacked, GS1 DataBar, China Post, Telepen, LOGMARS
2D barcode:
PDF-417, Micro PDF 417, Maxicode, DataMatrix, QR code, Aztec, TLC 39, RSS
6-INCH: PEX-2360L/ PEX-2360R
4-INCH: PEX-2340L/ PEX-2340R
4-INCH: PEX-2640L/ PEX-2640R
5
