Summary of Contents for ZKTeco M2-LR
- Page 1 Installation Guide M2-LR/M2F PRO-LR Version: 1.0 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
-
Page 2: Device Installation
1.Device Installation Please refer to the following recommendations for installation. The following illustration takes M2F PRO-LR as an example. Installation Environment INSTALL INDOORS AVOID INSTALLATION AVOID DIRECT AVOID USE OF ANY ONLY NEAR SUNLIGHT HEAT SOURCE GLASS WINDOWS AND EXPOSURE NEAR THE DEVICE Install on the wall ①... -
Page 3: Power Connection
2.Power Connection AC Adapter DC12V, 3A : 12V 3A Recommended AC adapter To share power with other devices, use an AC adapter with higher current ratings. 3. Ethernet Connection Connect the device and computer software via an Ethernet cable. As shown in the example below: Router Enter [COMM.] >... -
Page 4: Lock Relay Connection
4. Door Sensor & Exit Button Connection Door Sensor Exit Button 5. Lock Relay Connection The system supports Normally Opened Lock and Normally Closed Lock. The NO LOCK (normally unlocks when power on) is connected with 'NO' and 'COM' terminals, and the NC LOCK (normally locks when power on) is connected with 'NC' and 'COM' terminals. -
Page 5: Download Center
6. Download Center Scan the QR Code to download the User Manual, Installation Guide and Quick Start Guide. QR Code (Download Center) - Page 6 Copyright © 2025 ZKTECO CO., LTD. All Rights Reserved.
