XIO 341
X-DIAS Multi I/O Module
Instruction Manual
Date of creation: 12.07.2024
Version date: 06.02.2025
Article number: 21-013-341-E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XIO 341 and is the answer not in the manual?

Questions and answers

Summary of Contents for SIGMATEK XIO 341

  • Page 1 XIO 341 X-DIAS Multi I/O Module Instruction Manual Date of creation: 12.07.2024 Version date: 06.02.2025 Article number: 21-013-341-E...
  • Page 2 (print, photocopy, microfilm or in any other process) without express permission. We reserve the right to make changes in the content without notice. SIGMATEK GmbH & Co KG is not responsible for technical or printing errors in this handbook and assumes no responsibility for damages that occur through...
  • Page 3 1x LED output 0-1 A 3x analog input 0-5 V with +5 V supply The X-DIAS Multi I/O Module XIO 341 has 4 LED outputs in a range of 0-1 A. The module also has three analog inputs from 0-5 V with an own +5 V sensor supply.
  • Page 4: Table Of Contents

    XIO 341 X-DIAS MULTI I/O MODULE Table of Contents 1 Introduction 1.1 Target Group/Purpose of this Operating Manual 1.2 Important Reference Documentation 1.3 Contents of Delivery 2 Basic Safety Directives 2.1 Symbols Used 2.2 Disclaimer 2.3 General Safety Directives 3 Standards and Directives 3.1 Directives...
  • Page 5 X-DIAS MULTI I/O MODULE XIO 341 9.1 Module Coding XIO 341 9.2 Coding Hole Positions on Wiring Board (TOP View) 10 Wiring 10.1 ESD Protection 10.2 Wiring Example 10.3 Note 11 Assembly/Installation 11.1 Mounting 12 Supported Cycle Times 12.1 Cycle Times below 1 ms (in µs) 12.2 Cycle Times equal to or higher than 1 ms (in ms)
  • Page 6: Introduction

    Please see our website for our hotline number and business hours. 1.2 Important Reference Documentation X-DIAS Designguide This and additional documents can be downloaded from our website or obtained through support. 1.3 Contents of Delivery 1x XIO 341 Page 4 06.02.2025...
  • Page 7: Basic Safety Directives

    X-DIAS MULTI I/O MODULE XIO 341 2 Basic Safety Directives 2.1 Symbols Used The following symbols are used in the operator documentation for warning and danger messages, as well as informational notes. DANGER Danger indicates that death or serious injury will occur, if the specified measures are not taken.
  • Page 8 XIO 341 X-DIAS MULTI I/O MODULE CAUTION Caution indicates that moderate to slight injury can occur, if the specified measures are not taken. To avoid moderate to slight injuries, observe all guidelines. Attention indique une situation dangereuse qui, faute de prendre les mesures adéquates, peut entraîner des blessures assez graves ou...
  • Page 9: Disclaimer

    Please thoroughly read the corresponding documents and this operating manual before handling a product. SIGMATEK GmbH & Co KG is not liable for damages caused through, non-compliance with these instructions or applicable regulations.
  • Page 10: General Safety Directives

    Regarding the requirements for Safety and health connected to the use of machines, the manufacturer must perform a risk assessment in accordance with machine directives 2006/42/EG before introducing a machine to the market. Operate the unit with devices and accessories approved by SIGMATEK only. Page 8 06.02.2025...
  • Page 11 X-DIAS MULTI I/O MODULE XIO 341 CAUTION Handle the device with care and do not drop or let fall. Prevent foreign bodies and fluids from entering the device. The device must not be opened! Manipulez l’appareil avec précaution et ne le laissez pas tomber.
  • Page 12: Standards And Directives

    The product was constructed in compliance with the following European Union directives and tested for conformity. 3.1.1 EU Conformity Declaration EU Declaration of Conformity The product XIO 341 conforms to the following European directives: 2014/35/EU Low-voltage Directive 2014/30/EU Electromagnetic Compatibility (EMC Directive) 2011/65/EU “Restricted use of certain hazardous substances in electrical and electronic equipment”...
  • Page 13: Type Plate

    X-DIAS MULTI I/O MODULE XIO 341 4 Type Plate HW: Hardware version SW: Software version FW: Firmware version LD: Logic Device version 06.02.2025 Page 11...
  • Page 14: Technical Data

    XIO 341 X-DIAS MULTI I/O MODULE 5 Technical Data 5.1 LED Outputs Specifications Number LED output 1 0-20 mA at max. +10 V LED forward bias Resolution LED output 1 8-bit LED output 2 0-350 mA at max. +12 V LED forward bias up to 50 °C ambient temperature...
  • Page 15: Analog Input Specifications

    X-DIAS MULTI I/O MODULE XIO 341 5.2 Analog Input Specifications Number of channels Measurement range 0 … +5 V 0 … 100 % Measurement value 0 … 5,000 0 … 10,000 with an open input, the firmware returns the positive maximum value and a...
  • Page 16: Electrical Requirements

    XIO 341 X-DIAS MULTI I/O MODULE 5.4 Electrical Requirements Voltage supply from S-DIAS bus +24 V DC ±20 % (SELV/PELV) UL: NEC Class 2 Protection class Current consumption on the typically 26.5 mA maximum 33 mA S-DIAS bus (+24 V supply) Supply for I/Os +24 V ±20 %...
  • Page 17: Environmental Conditions

    X-DIAS MULTI I/O MODULE XIO 341 5.6 Environmental Conditions Storage temperature -40 ... +85 °C Environmental temperature -25 ... +55 °C Humidity 0-95 %, non-condensing Installation altitude above sea 0-2000 m without derating level > 2000 m up to a maximum of 5000 m with derating of the maximum environmental temperature by 0.5 °C per 100 m...
  • Page 18: Mechanical Dimensions

    XIO 341 X-DIAS MULTI I/O MODULE 6 Mechanical Dimensions Measurements 12.5 x 101.8 x 62.7 mm (W x H x D) Weight 0.2 kg Page 16 06.02.2025...
  • Page 19: Connector Layout

    X-DIAS MULTI I/O MODULE XIO 341 7 Connector Layout Signal Description +24 V bus +24 V bus S-DIAS bus The +24 V voltage supply is provided by the S-DIAS CPU or RxD- OUT RxD- IN the S-DIAS interface module. RxD+ OUT...
  • Page 20: Status Leds

    XIO 341 X-DIAS MULTI I/O MODULE 7.1 Status LEDs Page 18 06.02.2025...
  • Page 21: Applicable Connectors

    X-DIAS MULTI I/O MODULE XIO 341 Module status green module active no supply available BLINKING (5 Hz) no communication User yellow adjustable by application (e.g. the module LED can be set to blinking through the visualization so that the module is easily found in...
  • Page 22: Label Field

    XIO 341 X-DIAS MULTI I/O MODULE 8 Label Field The labeling field is printed directly on the module. Page 20 06.02.2025...
  • Page 23: Module Coding

    9 Module Coding X-DIAS modules have module coding by means of coding pins on the module housing. In combination with coding holes on the wiring board, a mismating protection can be realized. 9.1 Module Coding XIO 341 Position 1 Position 2...
  • Page 24: Wiring

    XIO 341 X-DIAS MULTI I/O MODULE 10 Wiring 10.1 ESD Protection CAUTION The operator must ensure that no ESD interference affects the product. L'opérateur doit s'assurer qu'aucune interférence due à des décharges électrostatiques n'affecte le produit. Page 22 06.02.2025...
  • Page 25: Wiring Example

    X-DIAS MULTI I/O MODULE XIO 341 10.2 Wiring Example 06.02.2025 Page 23...
  • Page 26: Note

    XIO 341 X-DIAS MULTI I/O MODULE 10.3 Note The signals recorded by the analog modules are very small, as compared to the digital signals. To ensure error-free operation, a careful wiring method must be followed: The functional grounding of the X-DIAS modules is carried out via their GND connection on the wiring board.
  • Page 27: Assembly/Installation

    X-DIAS MULTI I/O MODULE XIO 341 11 Assembly/Installation 11.1 Mounting The S-DIAS modules are designed for installation into the control cabinet. To mount the modules, a DIN-rail is required. The DIN rail must establish a conductive connection with the back wall of the control cabinet. The individual S-DIAS modules are mounted on the DIN rail as a block and secured with latches.
  • Page 28 XIO 341 X-DIAS MULTI I/O MODULE Recommended minimum distances between the S-DIAS modules and the surrounding components or control cabinet wall: a, b, c … distances in mm (inches) Page 26 06.02.2025...
  • Page 29: Supported Cycle Times

    X-DIAS MULTI I/O MODULE XIO 341 12 Supported Cycle Times 12.1 Cycle Times below 1 ms (in µs) x = supported 12.2 Cycle Times equal to or higher than 1 ms (in ms) x = supported x = supported 06.02.2025...
  • Page 30: Transport/Storage

    XIO 341 X-DIAS MULTI I/O MODULE 13 Transport/Storage INFORMATION This device contains sensitive electronics. During transport and storage, high mechanical stress must therefore be avoided. For storage and transport, the same values for humidity and vibration as for operation must be maintained! Temperature and humidity fluctuations may occur during transport.
  • Page 31: Storage

    X-DIAS MULTI I/O MODULE XIO 341 14 Storage INFORMATION When not in use, store the operating panel according to the storage conditions. See chapter 13 Transport/Storage. During storage, ensure that all protective covers (if available) are placed correctly, so that no contamination, foreign bodies or fluids enter the device.
  • Page 32: Maintenance

    XIO 341 X-DIAS MULTI I/O MODULE 15 Maintenance INFORMATION During maintenance as well as servicing, observe the safety instructions from chapter 2 Basic Safety Directives. Lors de l'entretien et de la maintenance, respectez les consignes de sécurité du chapitre 2 Basic Safety Directives.
  • Page 33: Disposal

    X-DIAS MULTI I/O MODULE XIO 341 16 Disposal INFORMATION Should you need to dispose of the device, the national regulations for disposal must be followed. The device appliance must not be disposed of as household waste. 06.02.2025 Page 31...
  • Page 34: Change History

    XIO 341 X-DIAS MULTI I/O MODULE Change History Change Affected Chapter Note date page(s) 30.09.2024 Document Revision 17.12.2024 Document Layout changes 03.02.2025 Document Layout changes 06.02.2025 5.6 Environmental Conditions Environmental and storage temperature changed Page 32 06.02.2025...

This manual is also suitable for:

21-013-341
