- Page 1 AO 081 S-DIAS Analog Output Module Instruction Manual Date of creation: 05.08.2013 Version date: 26.07.2023 Article number: 20-010-081-E...
- Page 2 (print, photocopy, microfilm or in any other process) without the express permission. We reserve the right to make changes in the content without notice. The SIGMATEK GmbH & Co KG is not responsi- ble for technical or printing errors in the handbook and assumes no responsibility for damages that occur through...
- Page 3 S-DIAS ANALOG OUTPUT MODULE AO 081 S-DIAS Analog Output Module AO 081 with 8 analog outputs The S-DIAS AO 081 analog output module has eight, ±10 V analog out- puts with a resolution of 12 bits. 26.07.2023 Page 1...
-
Page 4: Table Of Contents
AO 081 S-DIAS ANALOG OUTPUT MODULE Contents Introduction ................5 Target Group/Purpose of this Operating Manual ...... 5 Important Reference Documentation ......... 5 Contents of Delivery ..............5 Basic Safety Directives ............6 Symbols Used ................6 Disclaimer ..................8 General Safety Directives ............ - Page 5 S-DIAS ANALOG OUTPUT MODULE AO 081 Connector Layout ..............17 Status LEDs ................. 17 Applicable Connectors ............... 18 Label Field ................... 19 Wiring ..................20 Wiring Example ................20 Notes .................... 21 Connection Variants ..............22 8.3.1 Connecting the Analog Outputs ............22 Assembly/Installation ............
- Page 6 AO 081 S-DIAS ANALOG OUTPUT MODULE 14.2 Repair ................... 29 15 Disposal ..................29 16 Hardware Class AO081 ............30 16.1 General ..................31 16.2 Analog Outputs ................32 16.3 Communication Interfaces ............32 Page 4 26.07.2023...
-
Page 7: Introduction
General knowledge of automation technology is required. Further help and training information, as well as the appropriate accessories can be found on our website www.sigmatek-automation.com. Our support team is happily available to answer your questions. Please see our website for our hotline number and business hours. -
Page 8: Basic Safety Directives
AO 081 S-DIAS ANALOG OUTPUT MODULE Basic Safety Directives Symbols Used The following symbols are used in the operator documentation for warning and danger messages, as well as informational notes: DANGER Danger indicates that death or serious injury will occur, if the speci- fied measures are not taken. - Page 9 S-DIAS ANALOG OUTPUT MODULE AO 081 INFORMATION Information Provides important information on the product, handling or relevant sections of the documentation, which require atten- tion. 26.07.2023 Page 7...
-
Page 10: Disclaimer
It does not guarantee properties under the warranty. Please thoroughly read the corresponding documents and this operat- ing manual before handling a product. SIGMATEK GmbH & Co KG is not liable for damages caused through, non-compliance with these instructions or applicable regulations. -
Page 11: General Safety Directives
S-DIAS ANALOG OUTPUT MODULE AO 081 General Safety Directives The Safety Directives in the other sections of this operating manual must be observed. These instructions are visually emphasized by symbols. INFORMATION According to EU Directives, the operating manual is a component of a product. -
Page 12: Software/Training
AO 081 S-DIAS ANALOG OUTPUT MODULE CAUTION Handle the device with care and do not drop or let fall. Prevent foreign bodies and fluids from entering the device. The device must not be opened! Manipulez l’appareil avec précaution et ne le laissez pas tomber. -
Page 13: Standards And Directives
The product was constructed in compliance with the following European Union directives and tested for conformity. 3.1.1 EU Conformity Declaration EU Declaration of Conformity The product AO 081 conforms to the following European directives: • 2014/35/EU Low-voltage Directive • 2014/30/EU Electromagnetic Compatibility (EMC Directive) •... -
Page 14: Type Plate
AO 081 S-DIAS ANALOG OUTPUT MODULE Type Plate HW: Hardware version SW: Software version Page 12 26.07.2023... -
Page 15: Technical Data
S-DIAS ANALOG OUTPUT MODULE AO 081 Technical Data Analog Output Specifications Number of channels Output range -10 ... +10 V Output value -10.000 ... +10.000 Resolution 12-bit (ca. 5 mV/LSB) Refresh time for all channels 1 ms Output voltage capacity >... - Page 16 AO 081 S-DIAS ANALOG OUTPUT MODULE Page 14 26.07.2023...
-
Page 17: Voltage Monitor External +24 V Supply
S-DIAS ANALOG OUTPUT MODULE AO 081 Voltage Monitor External +24 V Supply +24 V supply voltage Supply voltage > 18 V (DC OK-LED lights green) Miscellaneous Article number 20-010-081 Standard UL 508 (E247993) Approbations UL, cUL, CE, UKCA Environmental Conditions Storage temperature -20 ... -
Page 18: Mechanical Dimensions
AO 081 S-DIAS ANALOG OUTPUT MODULE Mechanical Dimensions Page 16 26.07.2023... -
Page 19: Connector Layout
S-DIAS ANALOG OUTPUT MODULE AO 081 Connector Layout Status LEDs green Module Status module active no supply available BLINKING (5 Hz) no communication yellow User can be set from the application (e.g. the module LED can be set to blinking through the visuali-... -
Page 20: Applicable Connectors
AO 081 S-DIAS ANALOG OUTPUT MODULE Applicable Connectors Connectors: X1-X5: Connectors with spring terminals (included in delivery) The spring terminals are suitable connecting ultrasonically compacted (ultrasonically weld- ed) strands. Connections: Stripping length/Sleeve length: 10 mm Plug-in direction: parallel to conductor axis or to PCB Conductor cross section, rigid: 0.2-1.5 mm... -
Page 21: Label Field
S-DIAS ANALOG OUTPUT MODULE AO 081 Label Field Manufacturer Weidmüller Type MF 10/5 CABUR MC NE WS Weidmüller article number 1854510000 Compatible printer Weidmüller Type Printjet Advanced 230V Weidmüller article number 1324380000 26.07.2023 Page 19... -
Page 22: Wiring
AO 081 S-DIAS ANALOG OUTPUT MODULE Wiring Wiring Example Page 20 26.07.2023... -
Page 23: Notes
S-DIAS ANALOG OUTPUT MODULE AO 081 Notes To ensure error-free operation, a careful wiring method must be followed: • The 0 V connection of the supply voltage must be connected with the 0 V collection point over the shortest route possible. -
Page 24: Connection Variants
AO 081 S-DIAS ANALOG OUTPUT MODULE Connection Variants 8.3.1 Connecting the Analog Outputs Example application: Axis control for a DC servo, frequency converter. Page 22 26.07.2023... -
Page 25: Assembly/Installation
S-DIAS ANALOG OUTPUT MODULE AO 081 Assembly/Installation Check Contents of Delivery Ensure that the contents of the delivery are complete and intact. See chapter Contents of Delivery. INFORMATION On receipt and before initial use, check the device for damage. If the device is damaged, contact our customer service and do not install the device in your system. -
Page 26: Mounting
AO 081 S-DIAS ANALOG OUTPUT MODULE Mounting The S-DIAS modules are designed for installation into the control cabinet. To mount the modules a DIN-rail is required. The DIN rail must establish a conductive connection with the back wall of the control cabinet. The individual S-DIAS modules are mounted on the DIN rail as a block and secured with latches. - Page 27 S-DIAS ANALOG OUTPUT MODULE AO 081 Recommended minimum distances of the S-DIAS modules to the surrounding components or control cabinet wall: a, b, c … distances in mm (inches) 26.07.2023 Page 25...
-
Page 28: Addressing
AO 081 S-DIAS ANALOG OUTPUT MODULE 10 Addressing Address Size Access Type Description (hex) (bytes) 0000 Cyclic Data for Firmware 0000 Analog output 1 0000 Analog output 2 0004 Analog output 3 0006 Analog output 4 0008 Analog output 5... -
Page 29: Supported Cycle Times
S-DIAS ANALOG OUTPUT MODULE AO 081 11 Supported Cycle Times 11.1 Cycle Times below 1 ms (in µs) V1.20 11.2 Cycle Times equal to or above 1 ms (in ms) V1.20 V1.20 26.07.2023 Page 27... -
Page 30: Transport/Storage
AO 081 S-DIAS ANALOG OUTPUT MODULE 12 Transport/Storage INFORMATION This device contains sensitive electronics. During transport and stor- age, high mechanical stress must therefore be avoided. For storage and transport, the same values for humidity and vibration as for operation must be maintained! Temperature and humidity fluctuations may occur during transport. -
Page 31: Maintenance
S-DIAS ANALOG OUTPUT MODULE AO 081 14 Maintenance INFORMATION During maintenance as well as servicing, observe the safety instruc- tions from chapter 2 Basic Safety Directives. 14.1 Service This product was constructed for low-maintenance operation. 14.2 Repair INFORMATION In the event of a defect/repair, send the device with a detailed error description to the address listed at the beginning of this document. -
Page 32: Hardware Class Ao081
Hardware Class AO081 for the S-DIAS AO081 analog output module This hardware class is used to control the AO 081 hardware module. The module has 6 x ±10 V analog outputs. More information on the hardware can be found in the module docu- mentation. -
Page 33: General
S-DIAS ANALOG OUTPUT MODULE AO 081 16.1 General Class State State This server shows the actual status of the hardware class. Device ID State The device ID of the hardware module is shown in this server. FPGA Version State FPGA version of the module in 16#XY (e.g. 16#10 = version 1.0). -
Page 34: Analog Outputs
AO 081 S-DIAS ANALOG OUTPUT MODULE 16.2 Analog Outputs AO[1-8] minimal Property Minimum output value AO[1-8]. If this value is written to the respective value channel server, the module outputs -10 V AO[1-8] maxi- Property Maximum output value AO [1-8]. If this value is written to the respective mal value channel server, the module outputs +10 V. - Page 35 S-DIAS ANALOG OUTPUT MODULE AO 081 Documentation Changes Change date Affected Chapter Note page(s) 23.10.2013 Vibration resistance added 23.12.2013 3 Connector Layout Changed image 4.1 Wiring example Wiring example added 11.02.2014 3 Connector Layout Changed image 3.2 Applicable Connectors Connection capacity added...
- Page 36 AO 081 S-DIAS ANALOG OUTPUT MODULE Page 34 26.07.2023...
