SQ Combo Wash and Dry
Cabinet Freestanding
Vend
Refer to Page 11 for Model Identification
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the machine.
(If this machine changes ownership, this manual must accompany machine.)
Part No. D2596ENR1
www.alliancelaundry.com
October 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SQ Combo SZ135 and is the answer not in the manual?

Questions and answers

Related Manuals for Alliance Laundry Systems SQ Combo SZ135

Summary of Contents for Alliance Laundry Systems SQ Combo SZ135

  • Page 1 SQ Combo Wash and Dry Cabinet Freestanding Vend Refer to Page 11 for Model Identification Original Instructions Keep These Instructions for Future Reference. CAUTION: Read the instructions before using the machine. (If this machine changes ownership, this manual must accompany machine.) Part No.
  • Page 3 Any problems or conditions not understood should be reported to the dealer, distributor, service agent or the manufacturer. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 4: Models With Wireless Board Installed

    20cm from all person and not be co-located with any other transmitters except in accord- ance with FCC and Industry Canada multi-transmitter product procedures. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 5: Table Of Contents

    Cycle Preset....................18 © Copyright 2022, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher.
  • Page 6 Machine ID Menu..................44 Alarms Menu....................44 Inputs/Outputs Menu..................44 Machine Errors..................... 45 Error Descriptions..................45 Reset Menu...................54 Fan Inverter Parameters Loading............55 Default Cycles..................56 Default Cycles....................56 © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 7: Safety Information

    STALLATION manual for the proper earth/ground connection times [preferably in a locked cabinet]. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 8: Safety Decals

    Any problems or conditions not understood should be reported to ator or service technician. the dealer, distributor, service agent or the manufacturer. Use manufacturer-authorized spare parts to avoid safety hazards. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 9: Operator Safety

    Do not bypass any safety devices in the machine. WARNING Operating the machine with severe out-of-balance loads could result in personal injury and serious equipment damage. W728 © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 10: Introduction

    Refer to Figure 3 . Phone: 55 11 5505 2917 CNPJ: 17.658.250/0001-16 For technical assistance, contact your local distributor. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 11: Preliminary Information

    Using Wi-Fi communication, the user can receive audit and pro- gram data from the control and send programming data and diag- nostic commands to the control. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 12: Special Features

    The Special Vend option allows the owner to set a special vend price or free vend between specific times of day, days of week, dates, months and years. Refer to the System Menu for manual programming. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 13: Control Identification

    Selecting a different language changes all dis- plays to that language. Back Touch to navigate to the previously-displayed menu. Table 1  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 14: Operation Modes

    If this con- dition persists after an attempt to restart, then the control must be replaced. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 15: Menu Navigation

    Menu Navigation Menu Navigation Refer to the following charts for maps of the display menus. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 16 Menu Navigation © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 17 Global Drying temperature Anti-wrinkle RESET Global Settings Cycle Resets VEND SETTINGS System Resets Currency Payment Settings Vend Prices Top-off Settings Special Vend Rinse the machine interval CZW96R © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 18: Machine Cycle Definition And Operation

    While the machine is powering up, wait spinner is shown. Refer to Figure 7 . After the control has powered up, the display shows the Cycle Preset. CZW97R Figure 7 © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 19: Cycle Preset

    Rinse the Machine allows the user to select a rinse-only cycle to Touch or the masked area to close the menu. remove any residue from the wash basket before adding laundry. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 20: Language Selection Panel

    2. For combo cycles and Dry Only cycle, select desired options from the Additional Options Menu. When finished adding op- tions, touch NEXT (refer to Figure 13 ). CZW82R Figure 15 © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 21: Close Door Menu

    The control displays the Close Door Menu when the loading door is open when starting a cycle. Close the door to start or resume the cycle. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 22: Run Menu

    3. Language Selection Panel 4. Help Menu 5. Status Ring 6. Pause icon Figure 17 The display shows the Cycle Complete Menu when the cycle is complete. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 23: Cycle Pause Menu

    Parameters of anti-wrinkle sequence can be set in System Menu. top-off option is shown on display. Maximum drying time is 90 minutes. Refer to Figure 19 . CZW99R Figure 19 Figure 21 © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 24: Manual Programming

    The owner can program the control to require users to enter a enter the System Menu. passcode to access sections of the System Menu. 2. Touch Activate next to RAPID ADVANCE. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 25: Cancel Cycle

    1. To access, touch and hold the menu header from the display to enter the System Menu. 2. Enter access core 2021 and confirm. 3. Machine will end running cycle and after safety sequence door get unlocked. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 26: Advanced Info Menu

    2. Touch ADVANCED INFO from the display to enter the Ad- vanced Info Menu. 3. When finished, touch ADVANCED INFO to return to the Sys- tem Menu or EXIT to exit the System Menu. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 27: Settings Menu

    2. Touch SETTINGS from the display to enter the Settings Menu. 3. When finished making changes, touch SETTINGS to return to the System Menu or EXIT to exit the System Menu. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 28: Vend Settings

    Kn Kuna R Rand R$ Real Tk Token Zł Złoty Rp Indonesian Rupee RM Ringgit ฿ Baht ₭ Kip K Kyat ₫ Đồng Table 2  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 29 0-65535 Top-Off Settings Coin 1 Top-Off Time 1-90 Special Vend Set parameters for special vend time slots. Special Vend 1 Enable/Disable Disabled Table 2  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 30 Dry Only 0-65535 Rinse the Machine 0-65535 Special Vend 1 Top-Off Settings Coin 1 Top-Off Time 1-90 Rinse The Machine Time Interval No limit/1-127 Table 2 © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 31: Basic Settings

    Settings Menu Basic Settings BASIC SETTINGS Display Description Default Language Settings Default Language Set the language that appears on all displays by default. Table 3  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 32 Dansk Svenska Norsk Polski Slovenščina Română Hrvatski Magyar Latviešu Lietuvių kalba Slovenčina ελληνικά български Türkçe Bahasa Indonesia Bahasa Melayu ภาษาไทย Tiếng Việt Table 3  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 33 Magyar Enable/Disable Disable Latviešu Enable/Disable Disable Lietuvių kalba Enable/Disable Disable Slovenčina Enable/Disable Disable ελληνικά Enable/Disable Disable български Enable/Disable Disable Türkçe Enable/Disable Disable Table 3  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 34 End Week of Month End Day of Week Sunday - Saturday Sunday End Hour 0-23 Temperature Units ˚C/˚F ˚C Speed Units G-force/RPM Table 3  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 35: Additional Basic Settings

    1-99 seconds Hot Water Heater Temperature 122-176°F [50-80°C] 140°F [60°C] Maximum Water Fill Time 5-99 minutes Overfill Dectection 3-25 Pause Button Enable/Disable Enabled Table 4 © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 36: Machine Settings

    SSID 1-20 characters Security Key 8-20 characters Maintain Connected Network "Disconnect" SIGNAL STATUS Signal Level -XXXdBm Signal Noise Level -XXX RF Channel Table 5  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 37: Cycle Settings

    Set which supplies are used. Supply 1 Enable/Disable, 0-99 seconds Supply 2 Enable/Disable, 0-99 seconds Supply 3 Enable/Disable, 0-99 seconds Supply 4 Enable/Disable, 0-99 seconds Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 38 Enable/Disable, 0-99 seconds Disable Supply 2 Enable/Disable, 0-99 seconds Disable Supply 3 Enable/Disable, 0-99 seconds Disable Supply 4 Enable/Disable, 0-99 seconds Disable Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 39 Rotate Time 1-99 seconds (reversing drain only) Pause Time 1-99 seconds (reversing drain only) Final Set parameters for a final rinse step. Rinse Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 40 13kg / 135l: 150-930RPM 24kg / 240l: 150-850RPM Rotate Time 1-99 seconds (reversing drain only) Pause Time 1-99 seconds (reversing drain only) Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 41 GLOBAL WATER LEVELS (refer to Table 7 for default water levels by machine type) Machine depending Medium Machine depending High Machine depending Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 42 3-180 Audio notification Enabled/Disabled Disabled Table 6 Global Default Water Levels Machine Type Minimum Maximum Medium High 13kg / 135l 24kg / 240l Table 7 © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 43: Audit Data Menu

    3. Swipe to view the information. 4. When finished viewing or running diagnostics, touch AUDIT DATA to return to the System Menu or EXIT to exit the Sys- tem Menu. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 44: Diagnostics Menu

    Front-end Control Software Version Figure 36 1. To access, touch MACHINE ID from the Diagnostics Menu. 2. Swipe to scroll through the Machine ID Menu. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 45: Machine Errors

    CLEAR ERROR (when shown) or cycle power to the machine. Certain errors trigger a 15 second Machine Error Tone. Touch the display to silence the tone. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 46: Error Descriptions

    Defective temperature At power up: error dis- At power up sensor played, cycle start not Running cycle allowed Running cycle: full stop + tumble Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 47 Weigh Not Calibrated The Ultrabalance weigh- The Ultrabalance weigh- Before start ing system was not cali- ing system cannot be brated before the first used Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 48 Database Run Errors Database Errors Full stop + tumble Any time E747, E748, E800- Initialization Errors Initialization Errors Can cause firmware Firmware Initialization E804* downgrade Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 49 This error will occur if the wash computer error will occur when the target temperature has not been reached detects that the door switch is not closed during the wash cycle. If © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 50 If service is not per- formed and the cycle counter is not reset, the message will appear again at the end of the next wash cycle. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 51 A different value is required for each machine model and power 301/401 Err OC2 Overcurrent supply type. Err OC3 Overcurrent Table 9  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 52 If this does not clear the error message, then the in- Err MB4* Brake sequence er- verter must be replaced. ror 4 Table 9 Table 9  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 53 E721-E743: Database Run Errors These errors occur when database operations fail. E747, E748, E800-E804: Initialization Errors These errors occur when firmware initialization fails. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 54: Reset Menu

    5. Touch RESET to reset the list item to the factory default set- ting or touch CANCEL to return to the Reset Menu. 6. When finished making changes, touch EXIT to return to the System Menu. © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 55: Fan Inverter Parameters Loading

    Confirm value change by pressing 3x button SET • Turn dial knob to select parameter 79 • Press button SET and then with dial knob set value 0 © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

  • Page 56: Default Cycles

    Rotate Time Pause Time Speed ture (°C) (RPM) Wash 1:20 Wash Spin Rinse Wash Spin Warm Rinse 2:20 Wash Spin Max Speed High Cooldown Tumble © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 57 Machine ca- 24kg 13kg pacity Step Time (min.) Time (min.) Water Level Tempera- Soap Rotate Time Pause Time Speed ture (°C) (RPM) High Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...
  • Page 58 Time (min.) Time (min.) Water Level Tempera- Soap Rotate Time Pause Time Speed ture (°C) (RPM) Wash 1:20 Wash Drain Rinse 2:20 Wash Spin Cooldown Tumble © Copyright, Alliance Laundry Systems LLC - Part No. D2596ENR1 DO NOT COPY or TRANSMIT...

This manual is also suitable for:
