ProCon — DO3000-C Series
®
Dissolved Oxygen Controller
Display Descriptions
All electrical connections should be checked before use. After the power is switched on, the meter will display as follows.
Corresponding Voltage
(Blue is OFF & Red is ON)
Measurement Mode
Fluorescence Dissolved Oxygen
Calibration Mode
Air
8.25 mg/L
Fluorescence Dissolved Oxygen
25-0671 © Icon Process Controls Ltd.
Relay 2
Relay 1
(Blue is OFF & Red is ON)
Calibrating
Date
Year | Month | Day
Main
Value
Fluorescence Dissolved Oxygen
Instrument
Type
Relay 3
Cleaning
(Blue is OFF & Red is ON)
Setting Mode
Measurement
Calibration
Alarm
Current Setting
Communication
System
Fluorescence Dissolved Oxygen
Trend Chart Display
Fluorescence Dissolved Oxygen
Time
Hour | Minutes | Seconds
Abnormal alarm of
Electrode Communication
Temperature
Automatic Temperature
Compensation
Current 1
Current 2
Switch Display
