ProCon — DO3000-C Series
®
Dissolved Oxygen Controller
Current Setting
Communication
System
25-0671 © Icon Process Controls Ltd.
Description
Current 1
Description
Current 2
Baud Rate
Parity Check
Stop Bit
Address
Restore 000000 (Default)
Display
Year / Month / Date
Description
Set Time
Password 000000 (Default)
Series No.
Version
Language
Main (Default)
Channel
Temp
4-20mA (Default)
Output Type 0-20mA
20-4mA
Upper Limit 20.00 mg/L
Lower Limit 0.00 mg/L
Main
Channel
Temp (Default)
4-20mA (Default)
Output Type 0-20mA
20-4mA
Upper Limit 212.0
Lower Limit 32.0
o
4800BPS
9600BPS Default
19200BPS
None Parity Default
Odd Parity
Even Parity
1 Bit Default
2 Bit
000001
Calibration Recovery
Parameter Recovery
Display Rate Low | Standard (Default) | Medium | High
Back light 30 Sec | 5 min | 15 min | 30 min | Always On
Hr : Min : Sec
0000047105
6.2.36
English
F
o
F
