ProCon — DO3000-C Series
®
Dissolved Oxygen Controller
Cabinet Installation
Wall Mount Installation
a) Install a mounting bracket for the instrument
b) Wall screw fixation
25-0671 © Icon Process Controls Ltd.
D+ D-
B2 L N
Schematic of Installation
Schematic of Installation
Top view of mounting bracket.
Pay attention to installation direction
a) Embedded in an open hole
b) Fix the instrument
150.3mm
6x1.5mm
5
