Technical Specifications
Your MultiModem II modem meets the following specifications:
Trade Name
Model Number
Server-to-Client
Data Rates
Client-to-Client
Data Rates
Fax Data Rates
Data Format
Commands
Command Buffer
Modem Compatibility
Fax Compatibility
Error Correction
Data Compression
Speed Conversion
Mode of Operation
Flow Control
Transmission Level
Frequency Stability
Receiver Sensitivity
AGC Dynamic Range
Connectors
Cables
Indicators
Speaker
Manual Controls
Multi-Tech Systems, Inc. MT5600BA-V92 User Guide
Downloaded from Elcodis.com electronic components distributor
®
MultiModem II
MT5600BA-V92
V.92/56K speeds when accessing a V.92 server
(actual speed depends on server capabilities and line conditions)
33600, 31200, 28800, 26400, 24000, 21600, 19200, 16800,
14400, 12000, 9600, 7200, 4800, 2400, 1200, 0-300 bps
14400, 12000, 9600, 7200, 4800, 2400, 300 bps
Synchronous and asynchronous
AT Commands, V.25bis
60 characters
V.92, V.90, 56K, V.34 enhanced, V.34, V.32terbo, V.32bis, V.32,
V.25bis, V.22bis, V.22; Bell 212A and 103/113; V.42, V.42bis; V.21 &
V.23 in international versions, V.44
V.17/14.4K, Group 3, Class 1, 1.0, 2
V.42
V.44 (6:1 throughput), V.42bis, MNP Class 5 (2:1 throughput)
Serial port data rates adjustable to 300, 1200, 2400, 4800, 9600, 19200,
38400, 57600, 115200, and 230400 bps
Fax online modes; full duplex over dial-up and two-wire or four-wire
leased lines; data mode, command mode, online command mode, V.54
test mode
XON/XOFF (software), RTS/CTS (hardware)
-11 dBm (dial-up—varies depending on country or region for which the
modem is set), -10 dBm (leased-line)
±0.01%
-43 dBm under worst-case conditions
33 dB
One DB25F (RS-232C/D) connector; three RJ-11s
Three modular telephone cords (USA); country- or region-specific
cordage for International models; one 9-pin to 25-pin serial cable for
International models; external power transformer
Note: Any cables connected to the computer should be shielded to
reduce interference.
32-character backlit LCD for status and configuration information; LEDs
for Transmit Data, Receive Data, Carrier Detect, Off Hook, Terminal
Ready, and Test Mode
1-inch speaker for call progress monitoring
Power switch, speaker volume control, four LCD control buttons
