Liquid Crystal Display (LCD)
The modem's backlit liquid crystal display (LCD) has two functions: to display the current status of the
modem and to display configuration menus, which are selected using the four push buttons on the front
panel.
Option Selection
To select most configuration options, simply display the option in the LCD, and then press the
Enter button to select it. An OPTION SET message appears to confirm the selection. To exit the
OPTION SET message, press any button.
Some options, such as password options and phone number options, require you to enter a
character string. To select a character, press the arrow buttons. To go to the next character
position, press the
exit without saving, press the
button.
Menu Structure
The LCD menus have a tree structure with multiple trunks, limbs, branches, and twigs. For a
schematic view, refer to the menu map on the next page.
Trunks
Limbs
arrow buttons to among the limbs.
Branches
the arrow buttons to move among branches.
Twigs
move from a branch to its first status LCD or option. Then use the arrow buttons to move among
the options. Press the Enter button to select an option.
