Remote Configuration Options
The following LCDs are used to configure remote configuration options. For more information about
remote configuration, see Chapter 5, "Remote Configuration."
Diagnostic Options
Use the following LCDs to turn loopback tests on and off.
Phone Number Memory Options
Use the following LCDs to list, enter, and dial stored phone numbers. Up to four phone numbers can
be stored. The number in memory location 0 is used for DTR dialing, if DTR dialing is enabled.
Note: Only 16 characters can be displayed at a time. To display characters 17–30, press the
button. To go to the previous LCD, press the
Multi-Tech Systems, Inc. MT5600BA-V92 User Guide
Downloaded from Elcodis.com electronic components distributor
ENABLE/DISABLE R.C
Use the and Enter buttons to turn remote configuration on or off.
REMOTE CONFIG. PASSWORD
Use to enter the remote configuration password. To scroll through a list of digits and
characters, press the
To back up or to exit without saving, press the
password, press the Enter button.
ANALOG LOOPBACK
Press the and Enter buttons to start the analog loopback test. The TEST IN
PROGRESS LCD appears. To stop the test, press the
DIGITAL LOOPBACK
Press the and Enter buttons to start the local digital loopback test. The TEST IN
PROGRESS LCD appears. To stop the test, press the
as the &T3 command.
REMOTE DIGITAL LOOPBACK
Press the and Enter buttons to start the remote digital loopback test. The TEST IN
PROGRESS LCD appears. To stop the test, press the
as the &T6 command.
Note: Digital Loopback and Remote Digital Loopback tests must be performed using AT
Commands. The LCD option to run these tests has been temporarily removed.
LIST PHONE NUMBERS
Press the button several times to display the phone number stored in each memory
location.
ENTER PHONE NUMBERS
Use to store up to four phone numbers in memory locations 0–3. Each number can have up
to 30 characters. To scroll through a list of digits and characters, press the
buttons. To go to the next position, press the
saving, press the button several times. To save the number, press the Enter button.
Same as the &Z= commands.
DIAL STORED NUMBERS
Press the and Enter buttons to dial a stored phone number. Same as the DS=
commands.
and buttons. To go to the next position, press the
button several times. To save the
button. To go to the next LCD, press the
button. To back up or to exit without
Chapter 3 – Using the Front Panel
button.
and Enter buttons again.
and Enter buttons again. Same
and Enter buttons again. Same
button.
and
