FUFU & GAGA KF180199-01 Product Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Version: 180199-01-24A-FR

Advertisement

loading
Need help?

Need help?

Do you have a question about the KF180199-01 and is the answer not in the manual?

Questions and answers

Related Manuals for FUFU & GAGA KF180199-01

Summary of Contents for FUFU & GAGA KF180199-01

  • Page 1 Version: 180199-01-24A-FR...
  • Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
  • Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 54+5 B x 10+1 C x 6 D x 2 E x 24+3 6 x 35 mm 15 x 11 mm 8 x 30 mm...
  • Page 4 ALWAYS install Anti-tip device provided. NEVER put a TV on this product. NEVER allow children to stand,climb or hang on drawers,doors,or shelves. NEVER open more than one drawer at a time. Place heaviest items in the lowest drawers. This is a permanent label. Do not remove! 4/49...
  • Page 5 ALWAYS install Anti-tip device provided. NEVER put a TV on this product. NEVER allow children to stand,climb or hang on drawers,doors,or shelves. NEVER open more than one drawer at a time. Place heaviest items in the lowest drawers. This is a permanent label. Do not remove! 5/49...
  • Page 6 Q x 4 6 x 30 mm Connect panel 5, 6 and 7 using wooden dowel(Q) as shown. E x 8 H x 4 3 x 12 mm Fix iron sheet(H) to panel 5, 6 and 7 with screw(E) as shown. 6/49...
  • Page 7 A x 2 D x 1 E x 4 6 x 35 mm L = 350 mm 3 x 12 mm L-CL L-CR L-CR Fix rail(CR) to panel 42 with screw(E) at first. Flip to back, fix rail(CL) as shown. L-CR 180°...
  • Page 8 G x 2 4 x 30 mm Fix panel 42 to panel 6 with screw(G) as shown. 8/49...
  • Page 9 F x 4 3 x 12 mm Fix hinge(F) to plate 24 and 25 as shown. G x 4 4 x 30 mm Fix plate 24 and 25 to panel 27 with screw(G) as shown. 9/49...
  • Page 10 G x 2 4 x 30 mm Fix panel 28 to panel 29 with screw(G) as shown. 10/49...
  • Page 11 F x 4 3 x 12 mm Fix panel 28 and 29 to the assembled hinges. A x 2 Q x 2 6 x 35 mm 6 x 30 mm Screw eccentric rod(A) and insert wooden dowel(Q) into panel 10 as shown. 11/49...
  • Page 12 A x 2 6 x 35 mm Screw eccentric rod(A) into panel 8 as shown. A x 2 Q x 2 6 x 35 mm 6 x 30 mm Screw eccentric rod(A) and insert wooden dowel(Q) into panel 18 as shown. 12/49...
  • Page 13 V x 2 15 x 9.5 mm Attach panel 8 to panel 10, add cam lock(V) into panel 8 and turn clockwise to tighten as shown. N x 3 4 x 25 mm Fix plate 11 to plate 10 with screw(N) as shown. 13/49...
  • Page 14 A x 2 6 x 35 mm Screw eccentric rod(A) into panel 19 as shown. V x 2 15 x 9.5 mm 180° Attach panel 18 to panel 19, add cam lock(V) into panel 19 and turn clockwise to tighten as shown.
  • Page 15 N x 2 4 x 25 mm Fix plate 17 to plate 18 with screw(N) as shown. G x 6 4 x 30 mm Fix the component(assembled in step 9) to board 18 with screw(G) as shown. 15/49...
  • Page 16 A x 1 Q x 1 6 x 35 mm 6 x 30 mm Screw eccentric rod(A) and insert wooden dowel(Q) into panel 41 as shown. A x 1 Q x 1 6 x 35 mm 6 x 30 mm Screw eccentric rod(A) and insert wooden dowel(Q) into panel 40 as shown.
  • Page 17 A x 6 D x 1 E x 2 Q x 4 6 x 35 mm L = 350 mm 3 x 12 mm 6 x 30 mm Screw eccentric rod(A) and insert wooden dowel(Q) into panel 3 at first. Fix rail(CL) with screw(E) as shown.
  • Page 18 A x 6 D x 1 E x 2 Q x 4 6 x 35 mm L = 350 mm 3 x 12 mm 6 x 30 mm Screw eccentric rod(A) and insert wooden dowel(Q) into panel 4 at first. Fix rail(CR) with screw(E) as shown.
  • Page 19 B x 1 15 x 11 mm Attach panel 40 to panel 3, add cam lock(B) into panel 40 and turn clockwise to tighten as shown. 180° 19/49...
  • Page 20 B x 1 V x 3 15 x 11 mm 15 x 9.5 mm Attach panel 3 and 40 to panel 5 and 42, add cam lock(B) into panel 40 and cam lock(V) into panel 5, then turn clockwise to tighten as shown. 180°...
  • Page 21 B x 1 15 x 11 mm Attach panel 41 to panel 4, add cam lock(B) into panel 41 and turn clockwise to tighten as shown. 180° 21/49...
  • Page 22 B x 1 V x 3 15 x 11 mm 15 x 9.5 mm Attach panel 4 and 41 to panel 7 and 42, add cam lock(B) into panel 41 and cam lock(V) into panel 7, then turn clockwise to tighten as shown. 180°...
  • Page 23 V x 2 15 x 9.5 mm Attach the component(assembled in step 14) to board 3, add cam lock(V) into panel 10, then turn clockwise to tighten as shown. 180° 23/49...
  • Page 24 V x 2 15 x 9.5 mm Attach the component(assembled in step 18) to board 4, add cam lock(V) into panel 18, then turn clockwise to tighten as shown. 180° 24/49...
  • Page 25 G x 2 4 x 30 mm Fix panel 43 to panel 42 with screw(G) as shown. 25/49...
  • Page 26 V x 2 15 x 9.5 mm Attach panel 15 to panel 19, add cam lock(V) into panel 15, then turn clockwise to tighten as shown. 180° 26/49...
  • Page 27 L x 1 8 x 30 mm Fix pillar part 14 to panel 15 with screw(L) as shown. 27/49...
  • Page 28 L x 1 V x 2 8 x 30 mm 15 x 9.5 mm Fix panel 13 to pillar part 14 with screw(L) as shown. 180° Attach panel 13 to panel 8, add cam lock(V) into panel 13, then turn clockwise to tighten as shown.
  • Page 29 L x 2 8 x 30 mm Fix pillar part 12 to panel 13 and 43 with screw(L) as shown. 29/49...
  • Page 30 L x 1 8 x 30 mm Fix pillar part 14 to panel 15 with screw(L) as shown. 30/49...
  • Page 31 C x 3 8 x 30 mm Connect panel 20 and 21 using wooden dowel(C) as shown. Y x 16 4 x 35 mm Fix panel 36 and 37 to panel 20 and 21 with screw(Y) as shown. 31/49...
  • Page 32 G x 4 L x 1 Q x 14 4 x 30 mm 8 x 30 mm 6 x 30 mm Attach panel 20 and 21 to the bottom using wooden dowel(Q), and fix with screw(G) as shown. Fix panel 21 to pillar part 14 with screw(L) as shown.
  • Page 33 G x 4 4 x 30 mm Fix part 23 and 22 to panel 16 with screw(G) as shown. M x 2 Q x 2 U x 2 6 x 30 mm 3.5 x 14 mm Fix part(M) to panel 16 with screw(U) and insert wooden dowel(Q) into as shown.
  • Page 34 B x 2 G x 2 15 x 11 mm 4 x 30 mm Attach panel 16 to panel 40 and 41, add cam lock(B) into panel 16, then turn clockwise to tighten at first. Fix panel 16 to panel 20 and 21 with screw(G) as shown. 180°...
  • Page 35 G x 4 4 x 30 mm Fix panel 20 and 21 to panel 8 and 19 with screw(G) as shown. 35/49...
  • Page 36 Stick light strip 26 to the item. 36/49...
  • Page 37 A x 14 6 x 35 mm Screw eccentric rod(A) into panel 1 and 2 at first. 37/49...
  • Page 38 C x 3 8 x 30 mm Connect the two panels using wooden dowel(C) as shown. 38/49...
  • Page 39 B x 4 Q x 14 V x 10 15 x 11 mm 6 x 30 mm 15 x 9.5 mm 180° Cover panel 1 and 2 to the top using wooden dowel(Q), add cam lock(V) into panel 5,6,7, 42 and cam lock(B) into panel 3,4, then turn clockwise to tighten as shown.
  • Page 40 J x 2 K x 2 U x 12 3.5 x 14 mm Fix hinge(K) and bolt(J) to plate 38 with screw(U) as shown. J x 2 K x 2 U x 12 3.5 x 14 mm Fix hinge(K) and bolt(J) to plate 38 with screw(U) as shown.
  • Page 41 U x 8 3.5 x 14 mm Assemble door 38 to panel 3 and 4 by fixing hinge with screw(U) as shown. 41/49...
  • Page 42 J x 4 U x 8 3.5 x 14 mm Fix bolt(J) to plate 16 with screw(U) as shown. 42/49...
  • Page 43 A x 4 6 x 35 mm Screw eccentric rod(A) into panel 32 at first. G x 8 V x 4 4 x 30 mm 15 x 9.5 mm Attach panel 35 to panel 32, add cam lock(V) into and turn clockwise to tighten as shown. Fix panel 30 and 31 to panel 32 with screw(G) as shown.
  • Page 44 Insert bottom panel 33 along available grooves as shown. A x 12 P x 2 6 x 35 mm 4 x 9 mm Screw eccentric rod(A) into panel 34 at first. Fix handle(P) as shown. 44/49...
  • Page 45 V x 12 15 x 9.5 mm Attach panel 34 to panel 30, 31 and 35, add cam lock(V) into and turn clockwise to tighten as shown. 180° 45/49...
  • Page 46 D x 2 E x 8 L = 350 mm 3 x 12 mm D-DL D-DR Fix track(DL) and (DR) to panel 30 and 31 with screw(E) as shown. D-DR D-DL D-DL 46/49...
  • Page 47 47/49...
  • Page 48 X x 8 48/49...
  • Page 49 S x 6 T x 54 49/49...

  • Page 50: Warranty Claims

    WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part.
  • Page 51 RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please call us.
