Page 2
IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
Page 3
Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 15 B x 15 C x 33 D x 22 E x 2 6 x 35 mm 15 x 9 mm 6 x 30 mm...
Page 5
G x 4 F x 8 3 x 14 mm(BLACK) Fix hook(G) to plate 4 using screw(F) as shown. D x 4 C x 2 6 x 30 mm 4 x 35 mm Connect plate 2 and 3 with plate 4 using wooden dowel(C) and fix using screw(D) as shown.
Page 6
D x 7 C x 4 6 x 30 mm 4 x 35 mm Cover plate 1 to plate 2,4 and 3 with wooden dowel(C), then fix using screw(D) as shown. L x 1 M x 1 I x 2 J x 4 K x 4 4 x 14 mm...
Page 7
A x 15 6 x 35 mm Insert quickfit screw(A) ino corresponding holes in plate 8,10,12,13 and 16 with a screwdriver as shown. 7/16...
Page 8
C x 2 6 x 30 mm Connect plate 6 and 7 with plate 5 using wooden dowel(C) as shown. D x 7 C x 6 6 x 30 mm 4 x 35 mm Cover plate 8 to plate 6,5 and 7 with wooden dowel(C), then fix using screw(D) as shown.
Page 9
D x 2 C x 2 6 x 30 mm 4 x 35 mm Attach plate 11 to plate 13 with wooden dowel(C), then fix using screw(D) as shown. C x 4 B x 4 15 x 9 mm 6 x 30 mm Connect plate 10 and 12 with plate 13 using wooden dowel(C), insert cam lock(B) into plate 13 and turn clockwise to tighten as shown.
Page 10
C x 2 B x 2 6 x 30 mm 15 x 9 mm Attach plate 15 to plate 13 with wooden dowel(C), insert cam lock(B) into plate 15 and turn clockwise to tighten as shown. 180° B x 3 C x 5 15 x 9 mm 6 x 30 mm...
Page 11
Slide plate 9 along grooves in plate 10 and 12. C x 6 B x 6 6 x 30 mm 15 x 9 mm Cover plate 8 to plate 10,11 and 12 with wooden dowel(C), insert cam lock(B) into plate 10,11,12 and turn clockwise to tighten as shown.
Page 12
J x 8 4 x 14 mm Attach plate 14 to plate 13 by fixing hinge with screw(J) as shown. 12/16...
Page 13
If there is misalignment after you install, adjust the screw to the best condition 13/16...
Page 14
K x 4 4 x 12 mm Fix support part(L&M) to plate 10 and 12 respectively using screw(K) as shown. E x 2 H x 1 3 x12 m m(BLACK) Fix handle(H) to plate 14 using screw(E) as shown. 14/16...
Page 15
P x 4 Q x 4 (WHITE) 3 x 16 mm Insert part(Q) and reinforce back plate using screw(P) as shown. Place the pad. 15/16...
Page 16
D x 2 N x 2 O x 2 (WHITE) 4 x 35 mm 6 x 30 mm WALL Drill holes on your wall, knock into part(N). Fix the component(assembled in step 3) to wall using screw(D) as shown. Use sticker(O) to cover screw(D). 16/16...
