- Page 1 Sideboard Version:05/26/2022 1/14...
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
- Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 16 B x 16 C x 8 D x 12 E x 20 3 x 12 mm 6 x 30 mm 4 x 35 mm...
- Page 4 4/14...
- Page 5 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size 5/14...
- Page 6 A x 4 7 x 35 mm Fix quickfit screw A to panel 1 as shown. Please note don't use an electric screwdriver or use force to rotate, may cause crack. A x 4 E x 12 J x 2 H x 2 7 x 35 mm 3 x 12 mm...
- Page 7 B x 4 15 x 9 mm Connect panel 15 to panel 3&4,turn cam locks B clockwise to tighten as shown. C x 4 B x 4 15 x 9 mm 6 x 30 mm First insert half wooden dowels C into panel 3&4, then attach panel 1 to panel 3&4,turn cam locks B clockwise to tighten as shown.
- Page 8 C x 4 D x 4 4 x 35mm 6 x 30 mm Slide panel 5 into available slot in panel 3&4, insert half wooden dowels C into panel 3&4,and attach panel 2 using screw D as shown. Please note don't use an electric screwdriver or use force to rotate, may cause crack.
- Page 9 F x 6 4 x 45 mm Connect 2 assembled components using screw F as shown. G x 8 L x 8 16x 1 mm 6 x 50 mm Fix legs 9 using bolt L&G as shown. 16x 1 mm 12x 1 mm 9/14...
- Page 10 A x 8 B x 8 7 x 35 mm 15 x 9 mm Fix quickfit screw A to panel 10 as shown. Attach panel 11 and 12 to panel 10, turn cam locks B clockwise to tighten as shown. K x 2 P x 2 Q x 2...
- Page 11 E x 8 H x 2 J x 2 3 x 12 mm Fix glide H&J to panel 12&13 using screw E as shown. Please pay attention to the holes where the accessories are inserted. 11/14...
- Page 12 M x 4 N x 4 3 x 14 mm Use part M to fix panel 5 using bolts N as shown. 3 x 14 mm 3 x 12 mm 12/14...
- Page 13 WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part.
- Page 14 RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please call us.
