  • Page 1 Version 1.0 INS8325A Thin-mini ITX with Intel Alder Lake-N SoC ®...

  • Page 2: Safety Information

    INS8325A MiniITX User’s Manual V1.0 Safety Information Electrical safety  To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.  When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.

  • Page 3: Revision History

    INS8325A MiniITX User’s Manual V1.0 Revision History Revision Date (mm.dd.yyyy) Changes V1.0 02.10.2025 First release Packing list Item Description Q’ty INS8325A Thin-mini itx CD(Drivier + User’s manual) If any of the above items is damaged or missing, please contact your local...

  • Page 4: Table Of Contents

    INS8325A MiniITX User’s Manual V1.0 Table of Contents Safety Information ................................1 Electrical safety ................................. 1 Operation safety ................................1 Statement ..................................1 Revision History .................................. 2 Packing list ..................................2 Chapter 1: Product Information ............................5 1.1 Block Diagram ................................5 1.2 Key Feature ..................................
  • Page 5 INS8325A MiniITX User’s Manual V1.0 3.4.1 (List Boot Device Type) Drive BBS Priorities ....................43 3.5 Save & Exit Page ................................. 44...

  • Page 6: Chapter 1: Product Information

    INS8325A MiniITX User’s Manual V1.0 Chapter 1: Product Information 1.1 Block Diagram...

  • Page 7: Key Feature

    INS8325A MiniITX User’s Manual V1.0 1.2 Key Feature System Intel® Alder Lake-N : N50 (2C/6M Cache, up to 3.40 GHz , TDP 6W) Core i3-N305(8C/6M Cache, up to 3.80 GHz, TDP 15W) Atom x7425E(4C/6M Cache, up to 3.40 GHz, TDP 12W) Memory type DDR5 4800 MHz / 1 x 260-pin SO-DIMM / Max.
  • Page 8 INS8325A MiniITX User’s Manual V1.0 / 1 x Chassis Front Panel Header (2 x 5-pin) / 1 x Front Audio Header (Mic-in & Line-out) / 1 x Buzzer / 1 x Panel power select header (default 3.3V, option to 5V, 12...

  • Page 9: I/O Placement

    INS8325A MiniITX User’s Manual V1.0 1.3 I/O Placement...

  • Page 10: Chapter 2: Jumper Setting And Pin Definition

    INS8325A MiniITX User’s Manual V1.0 Chapter 2: JUMPER SETTING AND PIN DEFINITION 2.1 Jumper and Internal Connector List...
  • Page 11 INS8325A MiniITX User’s Manual V1.0 Label Function Front panel audio header Internal speaker header PCIEx1 eSPI interface CMOS clear jumper RS232/422/485 Serial port header (SIO4) *N50 sku NoPOP RS232 Serial port header (SIO1) RS232 Serial port header (SIO3) LVDS inverter power header for BKL...

  • Page 12: Internal Connector Pin Define & Jumper Setting

    INS8325A MiniITX User’s Manual V1.0 2.2 Internal Connector Pin Define & Jumper Setting 1. Front Panel Connector DEFINITION DEFINITION FP_MIC_L_CONN AGND FP_MIC_R_CONN FIO_AUD_DET_N FP_HPOUT_R AUD_SENSE_MIC_FP FIO_SENSE No pin FP_HPOUT_L AUD_SENSE_HP 4. eSPI interface DEFINITION ESPI_RESET_N_R ESPI_CLK_R ESPI_CS0_N_R ESPI_IO3_R ESPI_IO2_R ESPI_IO1_R...
  • Page 13 INS8325A MiniITX User’s Manual V1.0 7. RS232 Serial port header (SIO1) DEFINITION MDCD3_F_N (DCD) MSIN3_F_N (RX) MSO3_F_N (TX) MDTR3_F_N (DTR) MDSR3_F_N (DSR) MRTS3_F_N (RTS) MCTS3_F_N (CTS) MRI3_F_N (RI) 8. RS232 Serial port header (SIO2) DEFINITION MDCD4_F_N (DCD) MSIN4_F_N (RX) MSO4_F_N (TX)
  • Page 14 INS8325A MiniITX User’s Manual V1.0 11. Chassis Main Panel Header DEFINITION PWR_LED_N_20mils GRN_BLNK_HRD HDD_LED_N YLW_BLNK_HRD PS_ON_SW_FIO_N SYS_RESET_FIO_N V_5P No pin 12. Panel power Header as Jumper DEFINITION V_3P3 +12V LCD_VCC_PWR V_5P 13. LVDS connector PIN DEFINITION DEFINITION LVDS0_LINK3_CON_DP LVDS0_LINK3_CON_DN V_3P3...
  • Page 15 INS8325A MiniITX User’s Manual V1.0 14. TPM Header DEFINITION DEFINITION TPM_3V3_Power SPI0_CS2_TPM_N TPM_SPI_MISO_IO1 TPM_SPI_MOSI_IO0 PCH_PLTRST_N TPM_IRQ PCH_PLTRST_N TPM_DET_1_N V_3P3_SB 15. FPD Brightness Header DEFINITION PNL_BKLT_PWR_EN PNL_BKLT_CTRL_PWM BKLT_PWR BKLT_PWR PNL_BRIGHTNESS_UP PNL_BRIGHTNESS_DOWN 16. MIAPI Header DEFINITION DEFINITION MAPI_GPIO1 V_5P MAPI_GPIO2 MAPI_GPIO6 MAPI_GPIO3...
  • Page 16 INS8325A MiniITX User’s Manual V1.0 20. USB2.0 HR2 DEFINITION DEFINITION USB2B_5V USB2B_5V USB2_HR2_1N USB2_HR2_2N USB2_HR2_1P USB2_HR2_2P No pin 25. ATX 4pin power header DEFINITION VIN_9V_24V VIN_9V_24V...

  • Page 17: Chapter 3: Bios Setup

    INS8325A MiniITX User’s Manual V1.0 Chapter 3: BIOS SETUP This chapter provides information about how to set up BIOS and use BIOS menu items to adjust basic function settings. 3.1 Main Page Field Name BIOS Vender Default Value American Megatrends Comment This field is not selectable.
  • Page 18 INS8325A MiniITX User’s Manual V1.0 Default Value Display build date of the BIOS Comment This field is not selectable. There is no help text associated with it. Field Name Processor Information Default Value Display the installed CPU brand. Comment This field is not selectable. There is no help text associated with it.

  • Page 19: Advanced Page

    INS8325A MiniITX User’s Manual V1.0 3.2 Advanced Page Field Name Onboard Device Help Onboard Device Configuration Comment Press Enter when selected to go into the associated Sub-Menu. Field Name CPU Configuration Help CPU Configuration Parameters Comment Press Enter when selected to go into the associated Sub-Menu.
  • Page 20 INS8325A MiniITX User’s Manual V1.0 Field Name S5 RTC Wake Settings Help Enable system to wake from S5 using RTC alarm Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Network Stack Configuration Help Network Stack Settings.

  • Page 21: Onboard Device

    INS8325A MiniITX User’s Manual V1.0 3.2.1 Onboard Device Field Name State After G3 Default Value [S5 State] Possible Value S0 State S5 State Help Specify what state to go to when power is re-applied after a power failure (G3 state).
  • Page 22 INS8325A MiniITX User’s Manual V1.0 Field Name Output Panel Type Default Value [Disabled] Possible Value LVDS Disabled Help Select Output Panel Type. Field Name LVDS Panel Type(show when Output Panel Type is LVDS) Default Value [1920x1080 24bit Dual Channel] Possible Value...

  • Page 23: Cpu Configuration

    INS8325A MiniITX User’s Manual V1.0 3.2.2 CPU Configuration Field Name Brand String Default Value Displays the CPU brand string Comment This field is not selectable. There is no help text associated with it. Field Name Default Value Displays CPU Signature Comment This field is not selectable.

  • Page 24: Trusted Computing

    INS8325A MiniITX User’s Manual V1.0 Help When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. 3.2.3 Trusted Computing Field Name Firmware Version Default Value TPM module version. Comment This field is not selectable. There is no help text associated with it.

  • Page 25: Nct6126D Super Io Configuration

    INS8325A MiniITX User’s Manual V1.0 Possible Value None TPM Clear Help Schedule an Operation for the Security Device. NOTE: Your Computer will reboot during restart in order to change State of Security Device. 3.2.4 NCT6126D Super IO Configuration Field Name...

  • Page 26: Serial Port 1 Configuration

    INS8325A MiniITX User’s Manual V1.0 3.2.4.1 Serial Port 1 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Help Enable or Disable Serial Port(COM) Field Name Device Settings Default Value Device Super IO COM1 Address and IRQ.

  • Page 27: Serial Port 2 Configuration

    INS8325A MiniITX User’s Manual V1.0 3.2.4.2 Serial Port 2 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Help Enable or Disable Serial Port(COM) Field Name Device Settings Default Value Device Super IO COM2 Address and IRQ.

  • Page 28: Serial Port 3 Configuration

    INS8325A MiniITX User’s Manual V1.0 3.2.4.3 Serial Port 3 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Help Enable or Disable Serial Port(COM) Field Name Device Settings Default Value Device Super IO COM3 Address and IRQ.

  • Page 29: Serial Port 4 Configuration(Option)

    INS8325A MiniITX User’s Manual V1.0 3.2.4.4 Serial Port 4 Configuration(Option) Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Help Enable or Disable Serial Port(COM) Field Name Device Settings Default Value Device Super IO COM4 Address and IRQ.

  • Page 30: Hardware Monitor

    INS8325A MiniITX User’s Manual V1.0 Field Name Slew Configuration Default Value [1.5Mbps] Possible Value 256Kbps 1.5Mbps Help Configure serial port slew. 3.2.5 Hardware Monitor Field Name Range CPU Temperature Depend on CPU System Temperature1 -20 ~ 120 °C System Temperature2 -20 ~ 120 °C...

  • Page 31: S5 Rtc Wake Settings

    INS8325A MiniITX User’s Manual V1.0 3.2.6 S5 RTC Wake Settings Field Name Wake system from S5 Default Value [Disabled] Possible Value Disabled Fixed Time Help Enable or disable System wake on alarm event, Select FixedTime, system will wake on the hr::min::sec specified.

  • Page 32: Network Stack Configuration

    INS8325A MiniITX User’s Manual V1.0 Field Name Wake up second(Show when Wake system from S5 set to Fixed Time) Default Value Possible Value 0-59 Help Select 0-59 For Second 3.2.7 Network Stack Configuration Field Name Network stack Default Value [Disabled]...

  • Page 33: Nvme Configuration

    INS8325A MiniITX User’s Manual V1.0 Field Name Ipv6 PXE Support (Available when Network stack Enabled) Default Value [Disabled] Possible Value Disabled Enabled Help Enable/Disable Ipv6 PXE Boot Support. If disabled IPV6 PXE boot support will not be available. 3.2.8 NVMe Configuration...

  • Page 34: Security Page

    INS8325A MiniITX User’s Manual V1.0 3.3 Security Page Field Name Administrator Password Help Set Administrator Password Field Name User Password Help Set User Password. Field Name HDD Security drive Help HDD Security Configuration for selected drive Comment Press Enter when selected to go into the associated Sub-Menu.

  • Page 35: Hdd Security

    INS8325A MiniITX User’s Manual V1.0 3.3.1 HDD Security Field Name Set User Password Help Set HDD User Password. *** Advisable to Power Cycle System after Setting Hard Disk Passwords ***.Discard or Save changes option in setup does not have any impact on HDD when password is set or removed. If...

  • Page 36: Secure Boot

    INS8325A MiniITX User’s Manual V1.0 3.3.2 Secure Boot Field Name Secure Boot Default Value [Enabled] Possible Value Enabled Disabled Help Secure Boot feature is Active if Secure Boot is Enabled,Platform Key(PK) is enrolled and the System is in User mode.The mode change...

  • Page 37: Key Management

    INS8325A MiniITX User’s Manual V1.0 Help Delete all Secure Boot key databases from NVRAM Field Name Key Management Help Enables expert users to modify Secure Boot Policy variables without full authentication Comment Enables expert users to modify Secure Boot Policy variables without full authentication 3.3.3 Key Management...
  • Page 38 INS8325A MiniITX User’s Manual V1.0 Field Name Export Secure Boot variables Help Copy NVRAM content of Secure Boot variables to files in a root folder on a file system device Field Name Enroll Efi Image Help Allow the image to run in Secure Boot mode. Enroll SHA256 Hash...
  • Page 39 INS8325A MiniITX User’s Manual V1.0 Key Source: Factory,External,Mixed Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Forbidden Signatures(dbx) Default Value Size:0, Keys:0, Key source: No Keys Help Enroll Factory Defaults or load certificates from a file: 1.Public Key Certificate:...

  • Page 40: Bios Update

    INS8325A MiniITX User’s Manual V1.0 3.3.4 BIOS Update Field Name Path for ROM Image Help Enter the path to the Secure flash option...

  • Page 41: Boot Page

    INS8325A MiniITX User’s Manual V1.0 3.4 Boot Page Field Name Setup Prompt Timeout Default Value Possible Value 1~65535 Comment Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. Field Name Bootup NumLock State Default Value [On]...
  • Page 42 INS8325A MiniITX User’s Manual V1.0 Field Name Boot Option #2 Default Value [USB CD/DVD] Possible Value USB Floppy, CD/DVD, USB CD/DVD, Hard Disk , USB Key, USB Hard Disk , NVME, Network, Disabled Comment Sets the system boot order Field Name...
  • Page 43 INS8325A MiniITX User’s Manual V1.0 Comment Press Enter when selected to go into the associated Sub-Menu. Field Name (UEFI) CDROM/DVD ROM Drive BBS Priorities Help Specifies the Boot Device Priority sequence from available UEFI CDROM/DVD Drives. Comment Press Enter when selected to go into the associated Sub-Menu.
  • Page 44 INS8325A MiniITX User’s Manual V1.0 3.4.1 (List Boot Device Type) Drive BBS Priorities Field Name Boot Option #1 Default Value Possible Value Boot Device Name 1 of this type, Disable Help Sets the system boot order...
  • Page 45 INS8325A MiniITX User’s Manual V1.0 3.5 Save & Exit Page Field Name Save Changes and Reset Help Reset the system after saving the changes. Field Name Discard Changes and Rest Help Reset system setup without saving any changes. Field Name...
