- Page 1 Version 1.0 Revision Date: June. 14. 2017 User’s Manual SK220 PCIe/104(StackPC) MXM Carrier Module www.perfectron.com...
-
Page 2: Safety Information
SK220 PCIe/104 MXM Carrier Module User’s Manual Safety information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. -
Page 3: Revision History
SK220 PCIe/104 MXM Carrier Module User’s Manual Revision History Revision Date (dd.mm.yyyy) Changes Version 0.9 23.03.2017 Draft Version 1.0 14.06.2017 Initial Release Packing list □ SK220 □ SK220-P □ Manual CD □ Screw Package If any of the above items is damaged or missing, please contact your local distributor. -
Page 4: Table Of Contents
SK220 PCIe/104 MXM Carrier Module User’s Manual Table of content SAFETY INFORMATION ................................1 ....................................1 LECTRICAL SAFETY ....................................1 PERATION SAFETY STATEMENT ....................................1 REVISION HISTORY ..................................2 PACKING LIST ....................................2 TABLE OF CONTENT ..................................3 CHAPTER 1: PRODUCT INFORMATION ............................4 1.1 B... -
Page 5: Chapter 1: Product Information
SK220 PCIe/104 MXM Carrier Module User’s Manual Chapter 1: Product Information 1.1 Block Diagram www.perfectron.com... -
Page 6: Key Features
SK220 PCIe/104 MXM Carrier Module User’s Manual 1.2 Key Features Specification Function PCIe104-FPE MXM Graphic Card Carrier Signal Interface PCIe Gen.3 x16/ x8/ x4/ x1 MXM version Support MXM 3.0/3.1 PCIe104 Connector (Top) MXM Slot Top Side I/O 1 x VGA (Pin Header) -
Page 7: Board Placement
SK220 PCIe/104 MXM Carrier Module User’s Manual 1.3 Board Placement 1.3.1 SK220 Top Side 1.3.2 SK220 Bottom Side www.perfectron.com... -
Page 8: Chapter 2: Onboard Connector And Switch
SK220 PCIe/104 MXM Carrier Module User’s Manual Chapter 2: Onboard Connector and Switch 2.1 Connector 2.1.1 MVGA Connector 2*5P 180D P:2.0mm [E.I.C. 0110-02-163-100] Definition Definition GREEN BLUE HSYNC VSYNC DDC_CLK DDC_DAT 2.1.2 MDP1 Connector (DP1 & DP2) 2.1.3 MDP2 Connector (DP3 & DP4) 2.1.4 MDP3 Connector (DP5 &... -
Page 9: Fan1
SK220 PCIe/104 MXM Carrier Module User’s Manual 2.1.5 FAN1 Pin Definition +12V 2.1.6 MXM_SEL MXM_SEL[1:3] MXM PCIe Bus CONN. PCIE104_TOP OFF-OFF-OFF ON-OFF-OFF x1 and x4 OFF-OFF-ON x1 and x4 ON-OFF-ON OFF-ON-ON PCIe/104 x1 and x4 ON-ON-ON PCIe/104 MXM_SEL[4] MXM Version v3.0... -
Page 10: Stackpc
SK220 PCIe/104 MXM Carrier Module User’s Manual 2.1.7 StackPC Bottom: Samtec [ASP-129646-03] Top: Samtec [ASP-129637-03] DEFINITION DEFINITION DEFINITION DEFINITION USB_OC#_4_5 RST_HEADER# STK0_WAKE- STK1_SATA_ACT- +V3.3S +V3.3S -TYPE_DETECT USBD1+ USBD0+ LAN0_MDI0P PCIEX4_TXP0 USBD1- USBD0- LAN0_MDI0P PCIEX4_TXN0 PCIE_TXP1_1 PCIE_TXP0 LAN1_MDIP0 PCIEX4_TXP1 PCIE_TXN1_1 PCIE_TXN0... - Page 11 SK220 PCIe/104 MXM Carrier Module User’s Manual DEFINITION DEFINITION 0RTSSTK2_SPISCK LPC_CLK SPI_SS2 LAN0_MDI2P PCIEX4_RXP0 LAN0_MDI2N PCIEX4_RXN0 LAN1_MDI2P PCIEX4_RXP1 LAN1_MDI2N PCIEX4_RXN1 LAN0_MDI3P PCIEX4_RXP2 LAN0_MDI3N PCIEX4_RXN2 LAN1_MDI3P PCIEX4_RXP3 LAN1_MDI3N PCIEX4_RXN3 PE_PRSNT1_A- PE_PRSNT0_A SATARXP1 SATARXP0 SATARXN1 SATARXN0 FBUS_1P FBUS_P0 FBUS_1N FBUS_N0 LPC_AD0 LPC_DRQ#...
-
Page 12: Fpe
SK220 PCIe/104 MXM Carrier Module User’s Manual 2.1.8 FPE Bottom: Samtec [SEAM-20-09.0-L-10-2-A-K-TR] (ONLY on SK220) DEFINITION DEFINITION DEFINITION DEFINITION DEFINITION DEFINITION DPC_HPD DPC_AUX_P DPC_AUX_N DPC_LANE1_P +VDP_PWR USB3_TX0P USB3_TX1P DPC_LANE1_N DPC_LANE3_P USB3_TX0N USB3_RX0P USB3_TX1N USB3_RX1P DPC_LANE3_N USB3_RX0N USB3_RX1N DPC_LANE0_P USB3_TX5P USB3_TX4P... - Page 13 SK220 PCIe/104 MXM Carrier Module User’s Manual DEFINITION DEFINITION DEFINITION DEFINITION USB3_TX2P USB3_TX2N USB3_RX2P USB3_RX2N USB3_TX3P USB3_TX3N USB3_RX3P USB3_RX3N PEG_TXP6 PEG_TXN6 PEG_TXP7 PEG_TXN7 PE_RST_FPE# PEG_RXP_6 PEx16_x8_x4_0Clkp PEG_RXN_6 PEG_RXP_7 PEx16_x8_x4_0Clkn FPE_Bus_Err PEG_RXN_7 Config_Type0 PEG_TXP14 PEx16_x8_x4_1Clkp Config_Type1 PEG_TXN14 PEG_TXP15 PEx16_x8_x4_1Clkn Config_Type2 PEG_TXN15...
-
Page 14: Switch
SK220 PCIe/104 MXM Carrier Module User’s Manual 2.2 Switch 2.2.1 SW1 MXM_SEL[1:3] MXM PCIe Bus CONN. PCIE104_TOP OFF-OFF-OFF ON-OFF-OFF x1 and x4 OFF-OFF-ON x1 and x4 ON-OFF-ON OFF-ON-ON PCIe/104 x1 and x4 ON-ON-ON PCIe/104 MXM_SEL[4] MXM Version v3.0 v3.1 www.perfectron.com...
