  • Page 1 Version 1.0 OXY5363A 3.5" SBC with Intel® Tiger Lake-UP3 SoC www.perfectron.com...

  • Page 2: Operation Safety

    OXY5363A 3.5" SBC User’s Manual V1.0 Safety Information Electrical safety  To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.  When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.

  • Page 3: Revision History

    OXY5363A 3.5" SBC User’s Manual V1.0 Revision History Revision Date (mm.dd.yyyy) Changes V1.0 12.22.2021 First release Packing list Item Description Q’ty OXY5363A 3.5” SBC CD(Drivier + User’s manual) If any of the above items is damaged or missing, please contact your local distributor.

  • Page 4: Table Of Contents

    OXY5363A 3.5" SBC User’s Manual V1.0 Table of Contents Safety Information ................................. 1 Electrical safety ..................................1 Operation safety ..................................1 Statement ....................................1 Revision History ..................................2 Packing list ....................................2 Chapter 1: Product Information ............................5 1.1 Block Diagram ..................................
  • Page 5 OXY5363A 3.5" SBC User’s Manual V1.0 3.4 Security Page ..................................39 3.4.1 HDD Security……………………………………………………………………………………………………………………………………………………………...41 3.4.2 Secure Boot ................................... 41 3.4.3 Key Management (Secure Boot Mode set to Custom)………………………………………………………………………..……………………….41 3.4.4 BIOS Update…………………..…………..………………………………………………………………………………………………………………………………41 3.5 Boot Page ..................................46 ………….……………………………………………..…………… ……………………..……… 3.5.1 (List Boot Device Type) Drive BBS Priorities 3.6 Save &...

  • Page 6: Chapter 1: Product Information

    OXY5363A 3.5" SBC User’s Manual V1.0 Chapter 1: Product Information 1.1 Block Diagram www.perfectron.com...

  • Page 7: Key Feature

    OXY5363A 3.5" SBC User’s Manual V1.0 1.2 Key Feature System Intel® Core™ i7-1185G7E Processor (4 Cores / 8 Threads, 12M Cache, up to 4.40 GHz),15W/28W Intel® Core™ i5-1145G7E Processor (4 Cores / 8 Threads, 8M Cache, up to 4.10 GHz),15W/28W Intel®...
  • Page 8 OXY5363A 3.5" SBC User’s Manual V1.0 1 x Front IO Header (PWR ON/RESET/PWR LED/HDD LED) Front Panel Control Mechanical and Environment Form Factor 3.5" Power Type DC-IN 8~24V Dimension 102mm x 147mm Operating Temp. -20 to 70°C (Optional -40 to 85°C) Storage Temp -40 to 85°C...

  • Page 9: I/O Placement

    OXY5363A 3.5" SBC User’s Manual V1.0 1.3 I/O Placement www.perfectron.com...

  • Page 10: Chapter 2: Jumper Setting And Pin Definition

    OXY5363A 3.5" SBC User’s Manual V1.0 Chapter 2: JUMPER SETTING AND PIN DEFINITION 2.1 Jumper and Internal Connector List www.perfectron.com...
  • Page 11 OXY5363A 3.5" SBC User’s Manual V1.0 Label Function DDR4 SO-DIMM Slot M.2 E-Key Slot Nano SIM Socket M.2 B-Key Slot SATA 7P Connector FAN Header RTC Battery Socket Audio Socket Speaker Socket Front I/O Header Panel Backlight Power Socket DC Input Socket...

  • Page 12: Jumper Setting

    OXY5363A 3.5" SBC User’s Manual V1.0 2.2 Jumper Setting AT/ATX Mode DEFINITION Pin1/Pin2 (default) : ATX Mode Pin2/Pin3 : AT Mode BIOS Clear DEFINITION Pin1/Pin2 (default) : Keep current BIOS setting Pin2/Pin3 : BIOS will be cleared to the default setting...
  • Page 13 OXY5363A 3.5" SBC User’s Manual V1.0 ME Clear DEFINITION Pin1/Pin2 (default) : Keep current ME setting Pin2/Pin3 : Intel ME will be cleared to the default setting LVDS/eDP Backlight Power Selection Header DEFINITION Pin1-Pin2(default) : Backlight power 5V support Pin2-Pin3 : Backlight power 12V support www.perfectron.com...

  • Page 14: Internal Connector Pin Define

    OXY5363A 3.5" SBC User’s Manual V1.0 LVDS/eDP Panel Power Selection Header DEFINITION Pin4-Pin6(default) Panel power 5V support Pin2-Pin4 Panel power 3.3V support Pin3-Pin4 Panel power 12V support 2.3 Internal Connector Pin Define RTC Battery Socket DEFINITION VBAT Audio Socket DEFINITION...
  • Page 15 OXY5363A 3.5" SBC User’s Manual V1.0 Front I/O Header DEFINITION HDD LED+ Power LED+(S0) HDD LED- Power LED-(S3) PWRBT_N PWSET_N VCC(5V) Panel Backlight Power Socket (Support 5V) DEFINITION LVDS_BKTEN BKLT_CTRL BKLT_PWR(5V or 12V) BKLT_PWR(5V or 12V) DC Input Socket DEFINITION...
  • Page 16 OXY5363A 3.5" SBC User’s Manual V1.0 Dual COM Port Connector DCOM1 DEFINITION RS232 RS422 RS485 NDCD1(TX-)(D-) NRX1(TX+)(D+) NTX1(RX+) NDTR1(RX-) NDSR1 NRTS1 NCTS1 NRI1 NDCD2 NRX2 NTX2 NDTR2 NDSR2 NRTS2 NCTS2 NRI2 Dual COM Port Connector DCOM2 DEFINITION RS232 NDCD3 NRX3...

  • Page 17: External Connector Pin Define

    OXY5363A 3.5" SBC User’s Manual V1.0 2.4 External Connector Pin Define Dual COM Port Connector DCOM2 DEFINITION PWRBT_N www.perfectron.com...

  • Page 18: Chapter 3: Bios Setup

    OXY5363A 3.5" SBC User’s Manual V1.0 Chapter 3: BIOS SETUP This chapter provides information about how to set up BIOS and use BIOS menu items to adjust basic function settings. 3.1 Main Page Field Name BIOS Vendr Default Value American Megatrends Comment This field is not selectable.
  • Page 19 OXY5363A 3.5" SBC User’s Manual V1.0 Field Name Processor Information Default Value Display the installed CPU brand. Comment This field is not selectable. There is no help text associated with it. Field Name Microcode Version Default Value Display the CPU microcode revision.

  • Page 20: Advanced Page

    OXY5363A 3.5" SBC User’s Manual V1.0 Field Name System Time Default Value [hh :mm :ss] Possible Value hh : 0-23 mm : 0-59 ss : 0-59 Help Set the Time. Use Tab to switch between Time elements. 3.2 Advanced Page...

  • Page 21: Trusted Computing

    OXY5363A 3.5" SBC User’s Manual V1.0 Field Name Power & Performance Help Power & Performance Options. Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Trusted Computing Help Trusted Computing Settings Comment Press Enter when selected to go into the associated Sub-Menu.
  • Page 22 OXY5363A 3.5" SBC User’s Manual V1.0 3.2.1 Onboard Device Field Name Turbo Mode Default Value [Enabled] Possible Value Enabled Disabled Help Enable/Disable processor Turbo Mode (requires EMTTM enabled too) Field Name State After G3 Default Value [S5 State] Possible Value...
  • Page 23 OXY5363A 3.5" SBC User’s Manual V1.0 Internal Graphics Device. Field Name DVMT Total Gfx Mem Default Value [256M] Possible Value 128M 256M Help Select DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device. Field Name Wake on LAN Enable...
  • Page 24 OXY5363A 3.5" SBC User’s Manual V1.0 Note: Visible when LVDS Interface Type not set to disable Field Name LVDS Interface Type Default Value [1920x1080 LVDS] Possible Value 1024x768 LVDS 1366x768 LVDS 1920x1080 LVDS Help Select LVDS panel used by Internal Graphics Device by selecting the appropriate setup item.
  • Page 25 OXY5363A 3.5" SBC User’s Manual V1.0 3.2.2 CPU Configuration Field Name Type Default Value [Intel CPU Brand String] Comment This field is not selectable. There is no help text associated with it. Field Name Default Value Displays CPU Signature Comment This field is not selectable.
  • Page 26 OXY5363A 3.5" SBC User’s Manual V1.0 Field Name L2 Cache Default Value L2 Cache Size Comment This field is not selectable. There is no help text associated with it. Field Name L3 Cache Default Value L3 Cache Size Comment This field is not selectable. There is no help text associated with it.
  • Page 27 OXY5363A 3.5" SBC User’s Manual V1.0 Field Name Firmware Version Default Value TPM module version. Comment This field is not selectable. There is no help text associated with it. Field Name Vendor Default Value TPM module vendor name. Comment This field is not selectable. There is no help text associated with it.

  • Page 28: Serial Port 1 Configuration

    OXY5363A 3.5" SBC User’s Manual V1.0 3.2.4 NCT6126D Super IO Configuration Field Name Serial Port 1 Configuration Help Set Parameters of Serial Port 1 (COMC) Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Serial Port 2 Configuration...
  • Page 29 OXY5363A 3.5" SBC User’s Manual V1.0 3.2.5 Serial Port 1 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Help Enable or Disable Serial Port(COM) Field Name Device Settings Default Value Device Super IO COM1 Address and IRQ.
  • Page 30 OXY5363A 3.5" SBC User’s Manual V1.0 3.2.6 Serial Port 2 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Help Enable or Disable Serial Port(COM) Field Name Device Settings Default Value Device Super IO COM2 Address and IRQ.
  • Page 31 OXY5363A 3.5" SBC User’s Manual V1.0 3.2.7 Serial Port 3 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Help Enable or Disable Serial Port(COM) Field Name Device Settings Default Value Device Super IO COM3 Address and IRQ.
  • Page 32 OXY5363A 3.5" SBC User’s Manual V1.0 3.2.8 Serial Port 4 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Help Enable or Disable Serial Port(COM) Field Name Device Settings Default Value Device Super IO COM4 Address and IRQ.

  • Page 33: Hardware Monitor

    OXY5363A 3.5" SBC User’s Manual V1.0 3.2.9 Hardware Monitor Field Name Serial Port DIMM Temperature +70~-40 ℃ CPU VR Temperature +70~-40 ℃ Fan Speed There are many kinds of the fan could be installed into the system, so we could only set 0 RPM for the failed fan speed, and there is also no high RPM limitation.

  • Page 34: Rtc Wake Settings

    OXY5363A 3.5" SBC User’s Manual V1.0 3.2.10 RTC Wake Settings Field Name Wake system from S5 Default Value [Disabled] Possible Value Disabled Fixed Time Help Enable or disable System wake on alarm event, Select FixedTime, system will wake on the hr::min::sec specified.
  • Page 35 OXY5363A 3.5" SBC User’s Manual V1.0 Field Name Wake up hour(Show when Wake system from S5 set to Fixed Time) Default Value Possible Value Help Select 0-59 For Second 3.2.11 Network Stack Configuration Field Name Network stack Default Value [Disabled]...
  • Page 36 OXY5363A 3.5" SBC User’s Manual V1.0 Field Name Ipv6 PXE Support (Available when Network stack Enabled) Default Value [Enabled] Possible Value Disabled Fixed Time Help Enable/Disable Ipv6 PXE Boot Support. If disabled IPV6 PXE boot support will not be available.

  • Page 37: Event Logs

    OXY5363A 3.5" SBC User’s Manual V1.0 3.3 Event Logs Field Name Change Smbios Event Log Settings Help Press to change the Smbios Event Log configuration. Comment Press Enter when selected to go into the associated Sub-Menu. Field Name View Smbios Event Log Help Press to view the Smbios Event Log records.

  • Page 38: Enabling/Disabling Options

    OXY5363A 3.5" SBC User’s Manual V1.0 3.3.1 Enabling/Disabling Options Field Name Ipv6 PXE Support (Available when Network stack Enabled) Default Value [Enabled] Possible Value Disabled Fixed Time Help Change this to enable or disable all features of Smbios Event Logging during boot.

  • Page 39: View Smbios Event Logs

    OXY5363A 3.5" SBC User’s Manual V1.0 3.3.2 View Smbios Event logs Field Name DATE / TIME / ERROR CODE / SEVERITY / COUNT Default Value MM/DD/YY HH:MM:SS Smbios 0x16 N/A N/A Possible Value By Events. Help By Events. www.perfectron.com...

  • Page 40: Security Page

    OXY5363A 3.5" SBC User’s Manual V1.0 3.4 Security Page Field Name Administrator Password Help Set Administrator Password Field Name User Password Help Set User Password. Field Name HDD Security drive Help HDD Security Configuration for selected drive Comment Press Enter when selected to go into the associated Sub-Menu.

  • Page 41: Hdd Security

    OXY5363A 3.5" SBC User’s Manual V1.0 3.4.1 HDD Security Field Name Set User Password Help Set HDD User Password. *** Advisable to Power Cycle System after Setting Hard Disk Passwords ***.Discard or Save changes option in setup does not have any impact on HDD when password is set or removed. If...

  • Page 42: Secure Boot

    OXY5363A 3.5" SBC User’s Manual V1.0 3.4.2 Secure Boot Field Name Secure Boot Default Value [Enabled] Possible Value Enabled Disabled Help Secure Boot feature is Active if Secure Boot is Enabled,Platform Key(PK) is enrolled and the System is in User mode.The mode change...

  • Page 43: Key Management (Secure Boot Mode Set To Custom)

    OXY5363A 3.5" SBC User’s Manual V1.0 Field Name Reset to Setup Mode(After Restore Factory keys Provision) Help Delete all Secure Boot key databases from NVRAM Field Name Key Management Help Enables expert users to modify Secure Boot Policy variables without...
  • Page 44 OXY5363A 3.5" SBC User’s Manual V1.0 Field Name Reset to Setup Mode Help Delete all Secure Boot key databases from NVRAM Field Name Export Secure Boot variables Help Copy NVRAM content of Secure Boot variables to files in a root folder...
  • Page 45 OXY5363A 3.5" SBC User’s Manual V1.0 Field Name Authorized Signatures Default Value Size:0, Keys:0, Key source: No Keys Help Enroll Factory Defaults or load certificates from a file: 1.Public Key Certificate: a)EFI_SIGNATURE_LIST b)EFI_CERT_X509 (DER) c)EFI_CERT_RSA2048 (bin) d)EFI_CERT_SHAXXX 2.Authenticated UEFI Variable 3.EFI PE/COFF Image(SHA256)

  • Page 46: Bios Update

    OXY5363A 3.5" SBC User’s Manual V1.0 Field Name OsRecovery Signatures Default Value Size:0, Keys:0, Key source: No Keys Help Enroll Factory Defaults or load certificates from a file: 1.Public Key Certificate: a)EFI_SIGNATURE_LIST b)EFI_CERT_X509 (DER) c)EFI_CERT_RSA2048 (bin) d)EFI_CERT_SHAXXX 2.Authenticated UEFI Variable 3.EFI PE/COFF Image(SHA256)

  • Page 47: Boot Page

    OXY5363A 3.5" SBC User’s Manual V1.0 3.5 Boot Page Field Name Setup Prompt Timeout Default Value Possible Value 1~65535 Comment Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. Field Name Bootup NumLock State Default Value...
  • Page 48 OXY5363A 3.5" SBC User’s Manual V1.0 Field Name Boot Option #2 Default Value [USB CD/DVD] Possible Value USB Floppy, CD/DVD, USB CD/DVD, Hard Disk , USB Key, USB Hard Disk , NVME, Network, Disabled Comment Sets the system boot order...
  • Page 49 OXY5363A 3.5" SBC User’s Manual V1.0 Field Name (UEFI) USB CDROM/DVD ROM Drive BBS Priorities Help Specifies the Boot Device Priority sequence from available USB CDROM/DVD Drives. Comment Press Enter when selected to go into the associated Sub-Menu. Field Name...

  • Page 50: List Boot Device Type) Drive Bbs Priorities

    OXY5363A 3.5" SBC User’s Manual V1.0 3.5.1 (List Boot Device Type) Drive BBS Priorities Field Name Boot Option #1 Default Value Possible Value Boot Device Name 1 of this type, Disable Help Sets the system boot order www.perfectron.com...

  • Page 51: Save & Exit Page

    OXY5363A 3.5" SBC User’s Manual V1.0 3.6 Save & Exit Page Field Name Save Changes and Reset Help Reset the system after saving the changes. Field Name Discard Changes and Rest Help Reset system setup without saving any changes. Field Name...
