- Page 1 Version 1.4 OXY5362A 3.5" SBC with Intel® Kabylake-U SoC www.perfectron.com...
-
Page 2: Safety Information
OXY5362A 3.5" SBC User’s Manual V1.4 Safety Information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. -
Page 3: Revision History
OXY5362A 3.5" SBC User’s Manual V1.4 Revision History Revision Date (dd.mm.yyyy) Changes Version 0.9 01.06.2017 Draft Version 1.0 13.06.2017 Initial Release Version 1.1 15.06.2017 Update latest product photo Change JP13.JP14,JP15 default setting Change LVDS and CN18 pin define. Version 1.2 20.06.2017... -
Page 4: Table Of Contents
OXY5362A 3.5" SBC User’s Manual V1.4 Table of Contents Safety Information ................................1 Electrical safety ................................1 Operation safety ................................1 Statement ..................................1 Revision History ................................2 Packing list ..................................2 Chapter 1: Product Information ............................5 1.1 Block Diagram ................................5 1.2 Key Features ................................ - Page 5 OXY5362A 3.5" SBC User’s Manual V1.4 4.4.1 Trust Computing ..............................17 4.4.2 IT8786 Super IO Configuration ..........................18 4.4.2.1 Serial Port 1 Configuration ........................... 18 4.4.2.2 Serial Port 2 Configuration ........................... 19 4.4.3 Hardware Monitor ..............................20 4.4.4 CPU Configuration ............................... 20 4.4.5 SATA Configuration .............................
-
Page 6: Chapter 1: Product Information
OXY5362A 3.5" SBC User’s Manual V1.4 Chapter 1: Product Information 1.1 Block Diagram www.perfectron.com... -
Page 7: Key Features
OXY5362A 3.5" SBC User’s Manual V1.4 1.2 Key Features Processor & System CPU Type Intel® Kabylake-U series, BGA type Intel® Core™ i7-7600U Processor (4M Cache, up to 3.9GHz) Intel® Core™ i5-7300U Processor (3M Cache, up to 3.5GHz) Intel® Core™ i3-7100U Processor (3M Cache, 2.4GHz) -
Page 8: Board Placement
OXY5362A 3.5" SBC User’s Manual V1.4 1.3 Board Placement CN11 www.perfectron.com... -
Page 9: Chapter 2: Jumpers And Connectors
OXY5362A 3.5" SBC User’s Manual V1.4 Chapter 2: Jumpers and Connectors 2.1 Onboard connector and jumper list Label Function COM1 (Rear) RS232, DB9 connector DP1 (Rear) DisplayPort DP2 (Rear) DisplayPort LAN1 (Rear) RJ45 connector LAN2 (Rear) RJ45 connector USB1/2 (Rear) 2 x USB3.0... -
Page 10: Connector And Jumper Pin Definition
OXY5362A 3.5" SBC User’s Manual V1.4 2.2 Connector and jumper pin definition 2.2.1 Jumper JP1: Clear CMOS Jumper Function description Setting Normal Clear CMOS Default setting: 1-2 JP2: COM1 RI/+5V/+12V Jumper Function description Setting Ring Default setting: 1-2 JP13: AT/ATX Mode... -
Page 11: Jp15: Mpcie2 Signal Select
OXY5362A 3.5" SBC User’s Manual V1.4 JP15: mPCIe2 signal select Jumper Function description Setting SATA PCIe Default setting: 2-3 JP24 LVDS Signal Power SW1: LVDS Resolution Setting Color Drawing Resolution Channel Switch Switch Switch depth Switch2 800 x 600 18-bit... -
Page 12: Cn11: Atx Power
OXY5362A 3.5" SBC User’s Manual V1.4 LVDS_SCLK LVDSA0- LVDS_SDATA 28 CN11: ATX Power DEFINITION DC in DC in CN18: LVDS Control connector DEFINITION 1 +12V 2 +12V 3 +12V 4 5V 5 5V 6 GND 7 GND 8 Backlight Enable... -
Page 13: J6: Sata Power
OXY5362A 3.5" SBC User’s Manual V1.4 J6: SATA Power DEFINITION J9: Front Panel PIN DEFINITION PIN DEFINITION FP_HDLED+ 2 FP_PLED+ SATALED# 4 EC_PWR_BTN RESET- J10: LPC DEFINITION +3.3VSB LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3 LPC_FRAME# PLTRST#_BUF1 10 LPC_CLK_1 J11: Audio PIN DEFINITION... -
Page 14: J14: Usb2.0 X2
OXY5362A 3.5" SBC User’s Manual V1.4 RS232 mode (Default) RS422 mode RS485 mode DATA- DATA+ J14: USB2.0 x2 PIN DEFINITION 1 +5V 2 USB5- 3 USB5+ 4 GND 5 GND 6 +5V 7 USB6- 8 USB6+ 9 GND 10 GND... -
Page 15: Chapter 3: Quick Installation Guide
OXY5362A 3.5" SBC User’s Manual V1.4 Chapter 3: Quick Installation Guide Chapter 4: AMI BIOS UTILITY This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMI BIOS setup utility. www.perfectron.com... -
Page 16: Starting
OXY5362A 3.5" SBC User’s Manual V1.4 4.1 Starting To enter the setup screens, perform the following steps: Turn on the computer and press the <Del> key immediately. After the <Del> key is pressed, the main BIOS setup menu displays. Other setup screens can be accessed from the ... -
Page 17: Main Menu
OXY5362A 3.5" SBC User’s Manual V1.4 4.3 Main Menu The Main menu is the first screen that you will see when you enter the BIOS Setup Utility. 4.4 Advanced Menu The Advanced Menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference. -
Page 18: Trust Computing
OXY5362A 3.5" SBC User’s Manual V1.4 4.4.1 Trust Computing www.perfectron.com... -
Page 19: It8786 Super Io Configuration
OXY5362A 3.5" SBC User’s Manual V1.4 4.4.2 IT8786 Super IO Configuration 4.4.2.1 Serial Port 1 Configuration www.perfectron.com... -
Page 20: Serial Port 2 Configuration
OXY5362A 3.5" SBC User’s Manual V1.4 4.4.2.2 Serial Port 2 Configuration www.perfectron.com... -
Page 21: Hardware Monitor
OXY5362A 3.5" SBC User’s Manual V1.4 4.4.3 Hardware Monitor 4.4.4 CPU Configuration www.perfectron.com... -
Page 22: Sata Configuration
OXY5362A 3.5" SBC User’s Manual V1.4 4.4.5 SATA Configuration www.perfectron.com... -
Page 23: Cms Configuration
OXY5362A 3.5" SBC User’s Manual V1.4 4.4.6 CMS Configuration 4.4.7 USB Configuration 4.5 Chipset www.perfectron.com... -
Page 24: System Agent (Sa) Configuration
OXY5362A 3.5" SBC User’s Manual V1.4 4.5.1 System Agent (SA) Configuration www.perfectron.com... -
Page 25: Graphic Configuration
OXY5362A 3.5" SBC User’s Manual V1.4 4.5.1.1 Graphic Configuration 4.5.1.1.1 LCD Control www.perfectron.com... -
Page 26: Memory Configuration
OXY5362A 3.5" SBC User’s Manual V1.4 4.5.1.2 Memory Configuration 4.5.2 PCH-IO Configuration www.perfectron.com... -
Page 27: Security
OXY5362A 3.5" SBC User’s Manual V1.4 4.6 Security Administrator Password Set administrator password. User Password Set user Password. www.perfectron.com... -
Page 28: Boot Menu
OXY5362A 3.5" SBC User’s Manual V1.4 4.7 Boot Menu This section is used to configure the boot features. 4.8 Save & Exit www.perfectron.com...
