TTC Trusted Wireless Repeater
TEF 8150 2350
Document properties (TUM7148)
Revision
Comment
1
First issue
Installation and operating manual
TTC Trusted Wireless Repeater
Revision date
Approved
2022-05-04
FO
TUM7149
Advertisement
Table of Contents
Related Manuals for Stahl TRANBERG TUM7149
Summary of Contents for Stahl TRANBERG TUM7149
-
Page 1: Document Properties (Tum7148)
Installation and operating manual TTC Trusted Wireless Repeater TEF 8150 2350 TUM7149 __________________________________________________________________________________ TTC Trusted Wireless Repeater TEF 8150 2350 Document properties (TUM7148) Revision Comment Revision date Approved First issue 2022-05-04... -
Page 2: Table Of Contents
Installation and operating manual Installation and operating manual TTC Trusted Wireless Repeater TEF 8150 2350 TUM7149 __________________________________________________________________________________ Contents Document properties (TUM7148) ......................1 Warnings and risk levels .......................... 3 General information ..........................3 Marking and intended use ........................4 Special conditions for safe use ........................ 5 Technical data ............................ -
Page 3: Warnings And Risk Levels
Installation and operating manual TTC Trusted Wireless Repeater TEF 8150 2350 TUM7149 __________________________________________________________________________________ Warnings and risk levels DANGER Non-compliance with the instruction results in risk of severe or fatal injuries to persons WARNING Non-compliance with the instruction may result in risk of severe or fatal injuries to persons CAUTION Non-compliance with the instruction may result in risk of injuries or damage to equipment NOTICE... -
Page 4: Marking And Intended Use
Installation and operating manual TTC Trusted Wireless Repeater TEF 8150 2350 TUM7149 __________________________________________________________________________________ Marking and intended use DANGER Do not open when energized. • • PTB 09 ATEX 1109 II 2 G Ex db eb mb [ia Ga] IIC T5Gb •... -
Page 5: Special Conditions For Safe Use
Installation and operating manual TTC Trusted Wireless Repeater TEF 8150 2350 TUM7149 __________________________________________________________________________________ Special conditions for safe use DANGER Special conditions for safe use are critical conditions to maintain the explosion protection of the equipment. These shall be adhered to in all cases and under all circumstances. The supply circuit shall include an electrical protection device in conformity with EN 60079- •... -
Page 6: Mounting And Installation
Installation and operating manual TTC Trusted Wireless Repeater TEF 8150 2350 TUM7149 __________________________________________________________________________________ Mounting and installation DANGER Incorrect mounting and installation may lead to explosion risks, risk of falling objects, risk for electric shock and risk for equipment malfunction. In turn, this can lead to severe damage and/or injuries. -
Page 7: Operation
Installation and operating manual TTC Trusted Wireless Repeater TEF 8150 2350 TUM7149 __________________________________________________________________________________ Operation To establish Modbus data transfer from TTC Thermostat to TTC Trusted Wireless connect Modbus cable from TTC Thermostat to TTC Trusted Wireless X2:1 (positive) and X2:2(negative). See wiring diagram of the specific TTC Thermostat for Modbus connection. -
Page 8: Trusted Wireless Information
Installation and operating manual TTC Trusted Wireless Repeater TEF 8150 2350 TUM7149 __________________________________________________________________________________ Trusted Wireless Information Key Facts Trusted Wireless Network structure Mesh network 1 master up to 249 slaves Standard Proprietary by Phoenix Contact Transmission method Frequency hopping (FHSS) Application Low/medium data rate, large networks, best for infrastructure... -
Page 9: Maintenance And Cleaning
Installation and operating manual TTC Trusted Wireless Repeater TEF 8150 2350 TUM7149 __________________________________________________________________________________ Maintenance and cleaning As stated above, regular inspections and maintenance shall be performed according to IEC/EN 60079-17 or equivalent. Clean only with a damp cloth, and mild detergents. Do not use running water. Avoid chemicals with high or low pH, abrasives, high pressure washer, strong detergents, solvents, petroleum- or alcohol based cleaning agents and similar.
