UPER ERVER 8045C-3R User's Manual
5-9 Connector Defi nitions
Main ATX Power Supply
Connector
The primary power supply connector
(JPW1) meets the SSI (Superset ATX)
24-pin specifi cation. Refer to the table
on the right for the pin defi nitions of
the ATX 24-pin power connector. You
must also connect the 8-pin (JPW2/
JPW3) processor power connectors to
your power supply (see below).
Processor Power Connector
JPW2 and JPW3 must also be con-
nected to the power supply to provide
power for the processors. See the
table on the right for pin defi nitions.
PW_ON Connector
The PW_ON connector is on pins 1
and 2 of JF1. This header should be
connected to the chassis power but-
ton. See the table on the right for pin
defi nitions.
Reset Connector
The reset connector is located on pins
3 and 4 of JF1 and attaches to the
reset switch on the computer chas-
sis. See the table on the right for pin
defi nitions.
ATX Power 24-pin Connector
Pin Defi nitions (JPW1)
Pin# Defi nition
13 +3.3V
14 -12V
15 COM
16 PS_ON
17 COM
18 COM
19 COM
20 Res (NC)
21 +5V
22 +5V
23 +5V
24 COM
+12V 8-pin Power
Pin Defi nitions (JPW2/JPW3)
Pins Defi nition
1 - 4 Ground
5 - 8 +12V
Required Connection
Power Button
Pin Defi nitions (JF1)
Pin# Defi nition
1 PW_ON
2 Ground
Reset Button
Pin Defi nitions (JF1)
Pin# Defi nition
3 Reset
4 Ground
5-12
Pin # Defi nition
1 +3.3V
2 +3.3V
3 COM
4 +5V
5 COM
6 +5V
7 COM
8 PWR_OK
9 5VSB
10 +12V
11 +12V
12 +3.3V
