Summary of Contents for Supermicro SUPERSERVER 8016B-TF

  • Page 1 UPER ® UPER ERVER 8016B-6F 8016B-TF USER’S MANUAL Revision 1.0a...
  • Page 2 This product, including software and docu- mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

  • Page 3: About This Manual

    Chapter 2: Server Installation This chapter describes the steps necessary to install the SuperServer 8016B- 6F/8016B-TF into a rack and check out the server confi guration prior to powering up the system. If your server was ordered without the processor and memory components, this chapter will refer you to the appropriate sections of the manual for their installation.
  • Page 4 UPER ERVER 8016B-6F/8016B-TF User's Manual Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X8QB6-F/X8QBE-F serverboard, including the locations and functions of connectors, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfi...
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    UPER ERVER 8016B-6F/8016B-TF User's Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 SATA ......................1-2 SAS ........................ 1-2 Rear I/O Ports ....................1-2 ATI Graphics Controller ................... 1-3 IPMI .........................
  • Page 7 Table of Contents Installing the Server into the Rack ..............2-6 Checking the Serverboard Setup ..............2-7 Preparing to Power On ................... 2-9 Chapter 3 System Interface Overview ......................3-1 Control Panel Buttons ..................3-1 Control Panel LEDs ..................3-2 Drive Carrier LEDs ..................
  • Page 8 UPER ERVER 8016B-6F/8016B-TF User's Manual X8QB6-F/X8QBE-F Quick Reference ............5-12 Connector Defi nitions ................... 5-13 5-10 Jumper Settings .................... 5-19 5-11 Onboard Indicators ..................5-21 5-12 SAS and SATA Ports ..................5-23 5-13 Installing Software ..................5-24 SuperDoctor III ....................5-25 Chapter 6 Advanced Chassis Setup Static-Sensitive Devices ..................

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Overview The 8016B-6F/8016B-TF is a high-end server comprised of two main subsystems: the SC818A-1400B 1U server chassis and the X8QB6-F/X8QBE-F serverboard. Please refer to our web site for information on operating systems that have been certifi ed for use with the 8016B-6F/8016B-TF (www.supermicro.com).

  • Page 10: Serverboard Features

    ERVER 8016B-6F/8016B-TF User's Manual Serverboard Features At the heart of the SuperServer 8016B-6F/8016B-TF lies the X8QB6-F/X8QBE-F, a quad processor serverboard based on the Intel 7500/ICH10R chipset. Below are the main features of the X8QB6-F/X8QBE-F. (See Figure 1-1 for a block diagram of the chipset).

  • Page 11: Ati Graphics Controller

    IPMI IPMI (Intelligent Platform Management Interface) is a hardware-level interface speci- fi cation that provides remote access, monitoring and administration for Supermicro server platforms. IPMI allows server administrators to view a server’s hardware status remotely, receive an alarm automatically if a failure occurs, and power cycle a system that is non-responsive.

  • Page 12: Server Chassis Features

    Front Control Panel The control panel on the SuperServer 8016B-6F/8016B-TF provides you with system monitoring and control. LEDs indicate system power, HDD activity, network activity, system overheat and power supply failure. A main power button and a system reset button are also included.

  • Page 13: System Block Diagram

    Chapter 1: Introduction Figure 1-1. Intel 7500 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. 6.4GT/s 6.4GT/s FBD0 FBD0 SMI 6.4GT/s SMI 6.4GT/s FBD1 FBD1 SMI 6.4GT/s SMI 6.4GT/s FBD2 FBD2 SMI 6.4GT/s SMI 6.4GT/s FBD3...

  • Page 14: Contacting Supermicro

    UPER ERVER 8016B-6F/8016B-TF User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 15: Chapter 2 Server Installation

    Unpacking the System You should inspect the box the 8016B-6F/8016B-TF was shipped in and note if it was damaged in any way. If the server itself shows damage you should fi le a dam- age claim with the carrier who delivered it.

  • Page 16: Warnings And Precautions

    UPER ERVER 8016B-6F/8016B-TF User's Manual • This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display Units.

  • Page 17: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).

  • Page 18: Installing The System Into A Rack

    ERVER 8016B-6F/8016B-TF User's Manual Installing the System into a Rack This section provides information on installing the 8016B-6F/8016B-TF into a rack unit with the rack rails provided. If the system has already been mounted into a rack, you can skip ahead to Sections 2-5 and 2-6. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly.

  • Page 19: Installing The Outer Rails

    Chapter 2: Server Installation Installing the Outer Rails Begin by measuring the distance from the front rail to the rear rail of the rack. Attach a short bracket to the front side of the right outer rail and a long bracket to the rear side of the right outer rail.

  • Page 20: Installing The Server Into The Rack

    UPER ERVER 8016B-6F/8016B-TF User's Manual Installing the Server into the Rack You should now have rails attached to both the chassis and the rack unit. The next step is to install the server into the rack. Do this by lining up the rear of the chassis rails with the front of the rack rails.

  • Page 21: Checking The Serverboard Setup

    Chapter 2: Server Installation Checking the Serverboard Setup After you install the 8016B-6F/8016B-TF in the rack, you will need to open the top cover to make sure the serverboard is properly installed and all the connections have been made. Accessing the inside of the System (see Figure 2-4) 1.
  • Page 22 UPER ERVER 8016B-6F/8016B-TF User's Manual Figure 2-4. Accessing the Inside of the System...

  • Page 23: Preparing To Power On

    Chapter 2: Server Installation Preparing to Power On Next, you should check to make sure the peripheral drives and the SAS/SATA drives and backplane have been properly installed and all connections have been made. Checking the Drives 1. All drives are accessable from the front of the server. For servicing the DVD- ROM and fl...
  • Page 24 UPER ERVER 8016B-6F/8016B-TF User's Manual Notes 2-10...

  • Page 25: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the drive car- riers to keep you constantly informed of the overall status of the system as well as the activity and health of specifi...

  • Page 26: Control Panel Leds

    fl ashing or on as long as the overheat condition exists. NIC2 Indicates network activity on GLAN2 when fl ashing . NIC1 Indicates network activity on GLAN1 when fl ashing . On the 8016B-6F/8016B-TF this light indicates SAS, SATA and/or DVD-ROM drive activity when fl ashing.

  • Page 27: Drive Carrier Leds

    Chapter 3: System Interface Power Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. Drive Carrier LEDs • Green: Each drive carrier has a green LED. When illuminated, this green LED (on the front of the drive carrier) indicates drive activity.
  • Page 28 UPER ERVER 8016B-6F/8016B-TF User's Manual Notes...

  • Page 29: Chapter 4 Standardized Warning Statements For Ac Systems

    Only certifi ed technicians should attempt to install or confi gure components. Read this appendix in its entirety before installing or confi guring components in the Supermicro chassis. These warnings may also be found on our web site at http://www.supermicro.com/ about/policies/safety_information.cfm. Warning Defi nition Warning! This warning symbol means danger.
  • Page 30 UPER ERVER 8016B-6F/8016B-TF User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befi nden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 31 Warning Statements for AC Systems ‫ﺟﺴﺪﻳﺔ‬ ‫ﺍﺻﺎﺑﺔ‬ ‫ﺗﺘﺴﺒﺐ ﻓﻲ‬ ‫ﺣﺎﻟﺔ ﻳﻤﻜﻦ ﺃﻥ‬ ‫ﺍﻧﻚ ﻓﻲ‬ ‫ﺧﻄﺮ‬ ‫ﻳﻌﻨﻲ‬ ‫ﻫﺬﺍ ﺍﻟﺮﻣﺰ‬ !‫ﺗﺤﺬﻳﺮ‬ ‫ﺍﻟﺪﻭﺍﺋﺮ‬ ‫ﺑﺎﻟﻤﺨﺎﻁﺮ ﺍﻟﻨﺎﺟﻤﺔ ﻋﻦ‬ ‫ﻦ ﻋﻠﻰ ﻋﻠﻢ‬ ، ‫ﻛ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﺗﻌﻤﻞ ﻋﻠﻰ ﺃﻱ‬ ‫ﻗﺒﻞ ﺃﻥ‬ ‫ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬ ‫ﺣﻮﺍﺩﺙ‬ ‫ﺃﻱ‬ ‫ﻭﻗﻮﻉ‬ ‫ﻤﻨﻊ‬ ‫ﻟ‬ ‫ﺍﻟﻮﻗﺎﺋﻴﺔ‬...

  • Page 32: Installation Instructions

    UPER ERVER 8016B-6F/8016B-TF User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 33: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. 警告 此产品的短路(过载电流)保护由建筑物的供电系统提供,确保短路保护设备的额定电 流不大于250V,20A。 警告 此產品的短路(過載電流)保護由建築物的供電系統提供,確保短路保護設備的額定電 流不大於250V,20A。...

  • Page 34: Power Disconnection Warning

    UPER ERVER 8016B-6F/8016B-TF User's Manual Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A. Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components.
  • Page 35 Chapter 4: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 36: Equipment Installation

    UPER ERVER 8016B-6F/8016B-TF User's Manual Equipment Installation Warning! Only trained and qualifi ed personnel should be allowed to install, replace, or service this equipment. 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifi ziertem Personal gestattet werden.

  • Page 37: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalifi ceerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 38: Battery Handling

    UPER ERVER 8016B-6F/8016B-TF User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .('‫כלי אבטחה בלבד )מפתח, מנעול וכד‬ ‫ﻣﺤﻈﻮﺭﺓ‬ ‫ﻣﻨﺎﻁﻖ‬ ‫ﻟﺘﺮﻛﻴﺒﻬﺎ ﻓﻲ‬ ‫ﻫﺬﻩ ﺍﻟﻮﺣﺪﺓ‬ ‫ﺗﺨﺼﻴﺺ‬ ‫ﺗﻢ‬ ،‫ﺃﺩﺍﺓ ﺧﺎﺻﺔ‬ ‫ﻣﻦ ﺧﻼﻝ ﺍﺳﺘﺨﺪﺍﻡ‬...
  • Page 39 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 40: Redundant Power Supplies

    UPER ERVER 8016B-6F/8016B-TF User's Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 41: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫ﺍﻣﺪﺍﺩ ﺍﻟﻄﺎﻗﺔ‬ ‫ﺑﻮﺣﺪﺍﺕ‬ ‫ﻋﺪﺓ ﺍﺗﺼﺎﻻﺕ‬ ‫ﺠﻬﺎﺯ‬ ‫ﺍﻟ‬ ‫ﻳﻜﻮﻥ ﻟﻬﺬﺍ‬ ‫ﻗﺪ‬ ‫ﺍﻟﻜﻬﺮﺑﺎء‬ ‫ﻋﻦ‬ ‫ﻮﺣﺪﺓ‬ ‫ﺍﻟ‬ ‫ﻟﻌﺰﻝ‬ ‫ﻛﺎﻓﺔ ﺍﻻﺗﺼﺎﻻﺕ‬ ‫ﻳﺠﺐ ﺇﺯﺍﻟﺔ‬ Waarschuwing Deze eenheid kan meer dan één stroomtoevoeraansluiting bevatten. Alle aansluitingen dienen verwijderd te worden om het apparaat stroomloos te maken. Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is...

  • Page 42: Comply With Local And National Electrical Codes

    UPER ERVER 8016B-6F/8016B-TF User's Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫ﺍﻟﻠﻮﺣﺔ‬ ‫ﺃﻭﺍﻟﻄﺎﻗﺔ ﺍﻟﻤﻮﺟﻮﺩﺓ ﻋﻠﻰ‬ ‫ﺍﻟﺘﻴﺎﺭ ﺍﻟﻜﻬﺮﺑﺎﺋﻲ‬ ‫ﻣﻦ‬ ‫ﺧﻄﺮ‬ ‫ﻫﻨﺎﻙ‬ ‫ﻫﺬﺍ ﺍﻟﺠﻬﺎﺯ‬ ‫ﺧﺪﻣﺔ‬ ‫ﻛﻦ ﺣﺬﺭﺍ ﻋﻨﺪ‬ ‫ﻳﻌﻤﻞ‬ ‫ﺍﻟﻨﻈﺎﻡ‬ ‫ﻋﻨﺪﻣﺎ ﻳﻜﻮﻥ‬...

  • Page 43: Product Disposal

    Chapter 4: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫ﺍﻟﻤﺘﻌﻠﻘﺔ‬ ‫ﺍﻟﻤﺤﻠﻴﺔ ﻭﺍﻟﻮﻁﻨﻴﺔ‬ ‫ﻘﻮﺍﻧﻴﻦ‬ ‫ﻳﺠﺐ ﺃﻥ ﻳﻤﺘﺜﻞ ﻟﻠ‬ ‫ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬...

  • Page 44: Hot Swap Fan Warning

    UPER ERVER 8016B-6F/8016B-TF User's Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 45 Chapter 4: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 46: Power Cable And Ac Adapter

    fi re. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certifi ed cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 警告...
  • Page 47 Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifi és qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
  • Page 48 UPER ERVER 8016B-6F/8016B-TF User's Manual Notes 4-20...

  • Page 49: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install the X8QB6-F/X8QBE-F serverboard into the chassis, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick refer- ence chart are included in this chapter for your reference.

  • Page 50: Unpacking

    2. The X8QB6-F/X8QBE-F requires a chassis big enough to support a 16.4" x 16.8" serverboard, such as Supermicro's SC818A-1400B. 3. Make sure that the I/O ports on the serverboard align properly with their respective holes in the I/O shield at the back of the chassis.

  • Page 51: Connecting Cables

    (with their locations noted) should be connected. (See the layout on page 5-9 for connector locations.) • 8016B-6F: SAS drive data cable (SAS0 ~ 2) • 8016B-TF: SATA drive data cable (I-SATA0 ~ 2) • Control Panel cable (JF1) • DVD-ROM drive cable Important! Make sure the the cables do not come into contact with the fans.

  • Page 52: I/O Ports

    UPER ERVER 8016B-6F/8016B-TF User's Manual Figure 5-1. Control Panel Header Pins Ground x (Key) x (Key) Power LED 3.3V HDD LED 3.3V Stby NIC1 (Link) LED NIC1 (Activity) LED NIC2 (Link) LED NIC2 (Activity) LED Blue LED: UID Red LED: Pwr Fail/OH/Fan Fail Power Fail LED 3.3V...

  • Page 53: Installing The Processor And Heatsink

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro web site for updates on CPU support. Installation Procedure 1. Press the socket clip to release the load plate, which covers the CPU socket, from its locking position.
  • Page 54 UPER ERVER 8016B-6F/8016B-TF User's Manual Warning: Make sure you lift the lever completely when installing the CPU; otherwise, damage to the socket or CPU may occur. 5. Align the CPU key (a semi-circle cutout) against the socket key, which is the notch below the gold color dot on the side of the socket.
  • Page 55 Chapter 5: Advanced Serverboard Setup Installation and Removal of the Heat Sink Installing the Heat Sink Installation 1. Do not apply any thermal grease to the heat sink or the CPU die; the required amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the retention mechanism.

  • Page 56: Memory Support

    UPER ERVER 8016B-6F/8016B-TF User's Manual Installing Memory Caution: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The X8QB6-F/X8QBE-F supports up to 1024 GB of registered ECC DDR3-1066/800 memory in 32 DIMM slots. Please use memory modules of the same type, speed, timing and same on a serverboard.
  • Page 57 Chapter 5: Advanced Serverboard Setup Processor and Memory Module Population Number of CPU and Memory Population Confi guration Table CPUs+DIMMs (For memory to work proper, please install DIMMs in pairs) 1 CPU & CPU1 2 DIMMs P1-1A/P1-3A 1 CPU & CPU1 4 DIMMs P1-1A/P1-3A, P1-5A/P1-7A...

  • Page 58: Notes And Restrictions

    All channels in a system will run at the fastest common frequency. Adding PCI Add-On Cards The 8016B-6F/8016B-TF can accommodate one PCI-Express 2.0 x16 card with the use of the RSC-RR1U-E16 riser card inserted into the PCI-E x16 slot. Installing an Add-on Card 1.

  • Page 59: Serverboard Details

    Chapter 5: Advanced Serverboard Setup Serverboard Details Figure 5-4. X8QB6-F/X8QBE-F Layout (not drawn to scale) COM1 (Bottom) USB0/1 UID_LED LED26 LAN1 UID_SWITCH FAN10 FAN9 FAN8 Intel 82576 Winbond JPL1 LAN2 BMC CTRL IPMI_LAN LAN CTRL (Top) JPRST1 Firmware JBT1 Battery Intel ICH10R BIOS X8QB6/X8QBE...

  • Page 60: X8Qb6-F/X8Qbe-F Quick Reference

    UPER ERVER 8016B-6F/8016B-TF User's Manual X8QB6-F/X8QBE-F Quick Reference Jumper Description Default Setting JBT1 Clear CMOS See Section 5-10 JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1 GLAN1/2 Enable/Disable Pins 1-2 (Enabled) JPS1 (X8QB6-F only) SAS2 Enable/Disable Pins 1-2 (Enabled) JPT1 TPM Enable/Disable...

  • Page 61: Connector Defi Nitions

    Chapter 5: Advanced Serverboard Setup Connector Defi nitions ATX Power 24-pin Connector Pin Defi nitions Pin# Defi nition Pin # Defi nition Main ATX Power Supply +3.3V +3.3V Connector -12V +3.3V The primary power supply connector (JPW3) meets the SSI EPS 24-pin PS_ON specifi...
  • Page 62 UPER ERVER 8016B-6F/8016B-TF User's Manual Overheat/Fan/Pwr Fail/UID LED OH/Fan Fail/ Pwr Fail/UID LED Pin Defi nitions (JF1) Connect an LED to pins 7 and 8 of Pin# Defi nition JF1 to use the Overheat/Fan Fail/ Red_LED Cathode/OH/Fan Fail/ Power Fail/UID LED functions. The Power Fail5.5V.SB...
  • Page 63 Chapter 5: Advanced Serverboard Setup Power On LED The Power On LED connector is lo- Power LED cated on pins 15 and 16 of JF1 (use Pin Defi nitions (JF1) JLED for a 3-pin connector). This Pin# Defi nition connection is used to provide LED 3.3V indication of power being supplied to Control...
  • Page 64 UPER ERVER 8016B-6F/8016B-TF User's Manual Wake-On-Ring The Wake-On-Ring header is des- ignated JWOR. This function allows Wake-On-Ring Pin Defi nitions your computer to receive and be Pin# Defi nition "awakened" by an incoming call when Ground (Black) in the suspend state. See the table on Wake-up the right for pin defi...
  • Page 65 Chapter 5: Advanced Serverboard Setup Overheat LED/Fan Fail OH/Fan Fail LED Overheat LED The JOH1 header is used to connect States Pin Defi nitions an LED to provide warning of chassis State Message Pin# Defi nition overheating. This LED will blink to in- Solid Overheat 5vDC...
  • Page 66 UPER ERVER 8016B-6F/8016B-TF User's Manual LAN1/2 (Ethernet Ports) Two Ethernet ports (designated LAN1 and LAN2) are located on the I/O back- plane. A dedicated IPMI LAN port (above the USB0/1 ports) is also provided. These ports accept RJ45 type cables.

  • Page 67: 5-10 Jumper Settings

    Chapter 5: Advanced Serverboard Setup 5-10 Jumper Settings Explanation of Jumpers To m o d i f y t h e o p e r a t i o n o f t h e serverboard, jumpers can be used Connector to choose between optional settings.
  • Page 68 UPER ERVER 8016B-6F/8016B-TF User's Manual VGA Enable/Disable VGA Enable/Disable Jumper Settings (JPG1) JPG1 allows you to enable or disable the Jumper Setting Defi nition VGA port. The default position is on pins Pins 1-2 Enabled 1 and 2 to enable VGA. See the table on...

  • Page 69: 5-11 Onboard Indicators

    Chapter 5: Advanced Serverboard Setup SAS2 Enable (X8QB6-F only) SAS2 Enable Close pins 1-2 to enable SAS (Serial At- Jumper Settings tached SCSI) support on the 8016B-6F Jumper Setting Defi nition (X8QB6-F serverboard). See the table Enabled (Default) on the right for jumper settings. The Disabled default setting is enabled.
  • Page 70 UPER ERVER 8016B-6F/8016B-TF User's Manual Standby Power LED Stannby PWR LED A standby power LED is located at LED LED Color Defi nition 8 on the serverboard. When this LED System Off (PWR cable is lit, the system is on. Be sure to turn...

  • Page 71: 5-12 Sas And Sata Ports

    Chapter 5: Advanced Serverboard Setup 5-12 SAS and SATA Ports SATA Port Pin Defi nitions (I-SATA0 ~ I-SATA5) SATA Ports Pin # Defi nition Ground There are no jumpers to confi gure the onboard SATA connectors. These ports are supported by the Intel ICH10R South Bridge portion of the chipset.

  • Page 72: 5-13 Installing Software

    UPER ERVER 8016B-6F/8016B-TF User's Manual 5-13 Installing Software The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO fi...
  • Page 73 Chapter 5: Advanced Serverboard Setup SuperDoctor III The SuperDoctor® III program is a web-based management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The SuperDoctor III program allows you to monitor the environment and operations of your system.
  • Page 74 UPER ERVER 8016B-6F/8016B-TF User's Manual Figure 5-7. SuperDoctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User’s Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/accessories/soft- ware/SuperDoctorIII.cfm. For Linux, we recommend that you use the SuperDoctor II application instead.

  • Page 75: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform mainte- nance on the SC818A-1400B chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the next step.

  • Page 76: Control Panel

    UPER ERVER 8016B-6F/8016B-TF User's Manual Figure 6-1. Chassis: Front and Rear Views Slim DVD-ROM Drive System LEDs Control Panel SAS/SATA Drive Bays System Reset Main Power Power Supply Module USB Ports PCI Expansion Slot (w/ riser card) Mouse/Keyboard Ports COM1 Port...

  • Page 77: System Fans

    System Fans Seven 4-cm heavy duty counter-rotating fans provide the cooling for the 8016B- 6F/8016B-TF. Each fan unit is actually made up of two fans joined back-to-back, which rotate in opposite directions. This counter-rotating action generates excep- tional airfl ow and works to dampen vibration levels. It is very important that the chassis top cover is properly installed and making a good seal in order for the cooling air to circulate properly through the chassis and cool the components.

  • Page 78: Drive Bay Installation

    UPER ERVER 8016B-6F/8016B-TF User's Manual Figure 6-2. System Cooling Fans Drive Bay Installation Removing the Front Bezel If your system has a front bezel (optional) attached to the chassis, you must fi rst remove it to gain access to the drive bays. To remove the bezel, fi rst unlock the front of the chassis then press the release knob (see Figure 6-3).

  • Page 79: Accessing The Drive Bays

    DVD-ROM/Floppy Disk Drives: For installing/removing a DVD-ROM or fl oppy disk drive, you will need to gain access to the inside of the 8016B-6F/8016B-TF by re- moving the top cover of the chassis. Proceed to the "DVD-ROM and Floppy Drive Installation"...

  • Page 80: Sas/Sata Drive Installation

    Secure the drive to the carrier with six screws, as shown in Figure 6-4. Figure 6-4. Mounting a Drive in a Carrier Important: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro Web site at http://www.supermicro.com/products/nfo/fi...

  • Page 81: Installing/Removing Sas/Sata Drives

    Chapter 6: Advanced Chassis Setup Installing/Removing SAS/SATA Drives The drive carriers are all easily accessible at the front of the chassis. These hard drives are hot-pluggable, meaning they can be removed and installed without powering down the system. To remove a carrier, push the release button located beside the drive LEDs. Then swing the colored handle fully out and use it to pull the unit straight out (see Figure 6-5).

  • Page 82: Dvd-Rom And Floppy Drive Installation

    DVD-ROM and Floppy Drive Installation The top cover of the chassis must be opened to gain full access to the DVD-ROM and fl oppy drive bays. The 8016B-6F/8016B-TF accomodates only slim-line DVD- ROM drives. Side mounting brackets are needed to mount a slim-line DVD-ROM drive in the 8016B-6F/8016B-TF server.

  • Page 83: Power Supply

    Chapter 6: Advanced Chassis Setup Power Supply The SuperServer 8016B-6F/8016B-TF has a single 1400 watt power supply, which is auto-switching capable. This enables it to automatically sense and operate at a 100v to 240v input voltage. An amber light will be illuminated on the power supply when the power is off.
  • Page 84 UPER ERVER 8016B-6F/8016B-TF User's Manual Figure 6-6. Removing/Replacing the Power Supply 6-10...

  • Page 85: Chapter 7 Bios

    When an option is selected in the left frame, it is highlighted in white. Often a text message will accompany it. (Note: AMI BIOS has default text messages built in. Supermicro retains the option to include, omit, or change any of these text messages.) The AMI BIOS Setup Utility uses a key-based navigation system called "hot keys."...

  • Page 86: Main Setup

    Warning! Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. If you have to update the BIOS, do not shut down or reset the system while the BIOS is updating to avoid possible boot failure.
  • Page 87 Day MM/DD/YY format. The time is entered in HH:MM:SS format. (Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00.) Supermicro X8QB6/E • BIOS Version: This item displays the BIOS vision used in your system.

  • Page 88: Advanced Setup Confi Gurations

    UPER ERVER 8016B-6F/8016B-TF User's Manual Advanced Setup Confi gurations Use the arrow keys to select Advanced Settings and press <Enter> to access the submenu items. Warning: Be sure to select the correct setting for each item in this section. A wrong setting selected may cause the system to malfunction.

  • Page 89: Processor And Clock Options

    Chapter 7: BIOS PS/2 Mouse Support Select Enabled to enable PS/2 Mouse support. Select Auto to enable the onboard PS/2 mouse when a PS/2 mouse is detected. The options are Enable, Disabled, and Auto. Wait For 'F1' If Error This forces the system to wait until the 'F1' key is pressed when an error occurs. The options are Disabled and Enabled.
  • Page 90 UPER ERVER 8016B-6F/8016B-TF User's Manual Sever Class Use this item to identify the server class for your system so that the prefectcher settings listed below can be correctly confi gured. The options are Enterprise, HPC (High Performance Cluster) and Custom (for customized servers).
  • Page 91 Chapter 7: BIOS CPU Multi-Core Enable/Disable (Available when supported by the CPU) Select Enabled to enable multi-core CPU support to enhance CPU performance. The options are Disabled and Enabled. A20M When the A20M# pin is enabled, it will force address bit 20 to zero (to be masked) to emulate the address wraparound for the real-address mode at 1 MB.

  • Page 92: Advanced Chipset Control

    UPER ERVER 8016B-6F/8016B-TF User's Manual ACPI T State When this feature is enabled, CPU Throttling state will be reported in the ACPI (Advanced Confi guration and Power Interface) protocol. The options are Enabled and Disabled. Advanced Chipset Control The items included in the Advanced Settings submenu are listed below.
  • Page 93 Chapter 7: BIOS QPI (Quick Path Interconnect) Links Speed Use this feature to set data transfer speed for QPI Link connections. The options are Slow and Fast. QPI Frequency Select (Available if the item - QPI Link Speed is set to Fast) This feature is used to set desired QPI frequency.
  • Page 94 UPER ERVER 8016B-6F/8016B-TF User's Manual • Inter-Socket Mirrored S0 (Socket 0) to S2 (Socket 2) and S1 (Socket 1) to S3 (Socket 3), • Inter-Socket Mirrored S0 (Socket 0) to S3 (Socket 3) and S1 (Socket 1) to S2 (Socket 2).
  • Page 95 Chapter 7: BIOS Scheduler Policy Use this feature to confi gure Scheduler_Policy settings. The scheduler is used to translate memory read/write commands into memory sub-commands for easy execution. Select Static Trade_Off to balance read/write priority. Select Static Read_Priority to optimize read latency and bandwidth. Select Static Write_Pri- ority to optimize write bandwidth to expedite command writing and execution.
  • Page 96 UPER ERVER 8016B-6F/8016B-TF User's Manual Active State Power Management Select Enabled to use the power management for signal transactions between the PCI Express L0 and L1 Links. Select Enabled to confi gure PCI-Exp. L0 and L1 Link power states. The options are Disabled and Enabled.
  • Page 97 Chapter 7: BIOS SMBUS Controller Select Enabled to enable the System_Management Bus Controller. The settings are Enabled and Disabled. SLP_S4# Min. Assertion Width This feature allows the user to set the minimum SLP_S4# Assertion Width to make sure that DRAMs have safe power cycles. The settings are 4 to 5 seconds, 3 to 4 Seconds, 2 to 3 Seconds, and 1 to 2 Seconds.
  • Page 98 UPER ERVER 8016B-6F/8016B-TF User's Manual SATA#1 Confi guration If Compatible is selected, it sets SATA#1 to the legacy_compatible mode. Select- ing Enhanced sets SATA#1 to the native SATA mode. The options are Disabled, Compatible and Enhanced. Confi gure SATA#1 as (Not available when SATA#1 Confi guration is disabled) Use this feature to select the drive type for SATA#1.
  • Page 99 Chapter 7: BIOS Block (Multi-Sector Transfer) Block Mode boosts the IDE drive performance by increasing the amount of data transferred. Only 512 bytes of data can be transferred per interrupt if Block Mode is not used. Block Mode supports transfers of up to 64 KB per interrupt. Select Disabled to allow data to be transferred from and to a device one sector at a time.
  • Page 100 UPER ERVER 8016B-6F/8016B-TF User's Manual Select MWDMA0 to allow BIOS to use Multi-Word DMA mode 0. It has a data transfer rate of 4.2 MB/s. Select MWDMA1 to allow BIOS to use Multi-Word DMA mode 1. It has a data transfer rate of 13.3 MB/s.
  • Page 101 Chapter 7: BIOS PCI/PnP Confi guration Clear NVRAM Select Yes to clear Non-Volatile Random Access (Flash) Memory (NVRAM) during system boot. The options are No and Yes. Plug & Play OS Select Yes to allow the OS to confi gure Plug & Play devices. (This is not required for system boot if your system has an OS that supports Plug &...
  • Page 102 UPER ERVER 8016B-6F/8016B-TF User's Manual LAN1 Option ROM/LAN2 Option ROM Select Enabled to enable the onboard LAN1/LAN2 Option ROMs to boot the com- puter using a network interface. The options are Enabled and Disabled.  Super IO Device Confi guration Serial Port1 Address/IRQ, Serial Port2 Address/IRQ This option specifi...
  • Page 103 Chapter 7: BIOS Hot-Plug USB FDD Support When this item is set to Enabled, a dummy Floppy Device Drive will be created as a Hot-Plug Floppy device in the system. When this item is set to Auto, a dummy fl oppy device will not be created if no USB FDD device is detected. The options are Disabled, Enabled and Auto.
  • Page 104 UPER ERVER 8016B-6F/8016B-TF User's Manual Energy Lake Feature Select Enabled to use Intel Energy Lake technology to enhance power effi ciency. The options are Disabled and Enabled. APIC ACPI SCI IRQ When this item is set to Enabled, APIC ACPI SCI IRQ is supported by the system.
  • Page 105 Chapter 7: BIOS  Hardware Health Event Monitoring This feature is used to monitor system health and review the status of each item as displayed. CPU Overheat Alarm This option allows the user to select the CPU Overheat Alarm setting which de- termines when the CPU OH alarm will be activated to provide warning of possible CPU overheat.
  • Page 106 ‘Temperature Tolerance’ is, and not the other way around. This results in better CPU thermal management. Supermicro has leveraged this feature by assigning a temperature status to certain thermal conditions in the processor (Low, Medium and High). This makes it easier for the user to understand the CPU’s temperature status, rather than by just simply...

  • Page 107: View Bmc System Event Log

    Chapter 7: BIOS Fan Speed Control Modes This feature allows the user to decide how the system controls the speeds of the onboard fans. The CPU temperature and the fan speed are correlative. When the CPU on-die temperature increases, the fan speed will also increase for effective system cooling.
  • Page 108 UPER ERVER 8016B-6F/8016B-TF User's Manual • Event Timestamp • Generator ID • Event Message Format Ver. • Event Sensor Type • Event Sensor Number • Event Dir Type • Event Data. Clear BMC System Event Log Clear BMC System Log now Select OK and press <Enter>...
  • Page 109 Chapter 7: BIOS a "request and grant" basis. Upon timeout (or lease expiration), the IP address assigned to the client can be reassigned to a new client. Select Static (Static Allocation) to allow the host server to allocate an IP address based on a table containing MAC Address/IP Address pairs that are manually entered (probably by a network administrator).

  • Page 110: Gateway Address

    UPER ERVER 8016B-6F/8016B-TF User's Manual Current Subnet Mask in BMC The BIOS will automatically enter the current subnet mask in BMC for this machine; however it may be overwritten. The value of each three-digit number separated by dots should not exceed 255.
  • Page 111 Chapter 7: BIOS Redirection After BIOS POST Select Disabled to turn off Console Redirection after Power-On Self-Test (POST). Select Always to keep Console Redirection active all the time after POST. (Note: This setting may not be supported by some operating systems.) Select Boot Loader to keep Console Redirection active during POST and Boot Loader.
  • Page 112 UPER ERVER 8016B-6F/8016B-TF User's Manual Execute TPM Command (Available when TCG/TPM Support = 'Yes') Select Enabled to execute TPM commands you've selected. Select Don't Change to keep the current TPM commands without making any changes. Select Dis- abled to abandon the changes you have made on TPM commands. The options are Enabled, Disabled and Don't Change.

  • Page 113: Boot Confi Guration

    Chapter 7: BIOS Boot Confi guration Use this feature to confi gure boot settings. Boot Device Priority This feature allows the user to specify the sequence of priority for the Boot Device. The settings are 1st boot device, 2nd boot device, 3rd boot device, 4th boot device, 5th boot device and Disabled.

  • Page 114: Security Settings

    UPER ERVER 8016B-6F/8016B-TF User's Manual Security Settings The AMI BIOS provides a Supervisor and a User password. If you use both pass- words, the Supervisor password must be set fi rst. Supervisor Password This item indicates if a Supervisor password has been entered for the system. "Not Installed"...

  • Page 115: Exit Options

    Chapter 7: BIOS Password Check Select Setup for the system to check for a password at Setup. Select Always for the system to check for a password at bootup. The options are Setup and Always. Boot Sector Virus Protection If this item is enabled, AMI BIOS displays a warning if any program (or virus) issues a Disk Format command or attempts to write to the boot sector of the hard disk drive.
  • Page 116 UPER ERVER 8016B-6F/8016B-TF User's Manual Load Optimal Defaults To set this feature, select Load Optimal Defaults from the Exit menu and press <Enter>. Then, select OK to allow the AMI BIOS to automatically load Optimal De- faults to the BIOS Settings. The Optimal settings are designed for maximum system performance but may not work best for all computer applications.

  • Page 117: Appendix A Bios Error Beep Codes

    Appendix A: BIOS POST Error Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 118 UPER ERVER 8016B-6F/8016B-TF User's Manual Notes...

  • Page 119: Appendix B System Specifi Cations

    Appendix B: System Specifi cations Appendix B System Specifi cations Processors Four Intel Xeon MP 7500 Series processors in LGA1567 sockets Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel 7500/ICH10R BIOS 64 Mb SPI AMI BIOS ®...
  • Page 120 UPER ERVER 8016B-6F/8016B-TF User's Manual Serverboard 8016B-6F: X8QB6-F (extended ATX form factor) 8016B-TF: X8QBE-F (extended ATX form factor) Dimensions (both): 16.4" x 16.8" (416.6 x 426.7 mm) Chassis SC818A-1400B (1U rackmount) Dimensions: (WxHxD) 17.2 x 1.7 x 27.75 in. (473 x 43 x 705 mm) Weight Gross (Bare Bone): 43 lbs.
  • Page 121 Appendix B: System Specifi cations Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3-3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
  • Page 122 ERVER 8016B-6F/8016B-TF User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...

This manual is also suitable for:

Superserver 8016b-6f

Table of Contents
