Chapter 7: BIOS
Hardware Monitoring
Access the submenu to make changes to the following settings:
CPU Temperature Threshold
This option allows the user to set a CPU temperature threshold that will activate
the alarm system when the CPU temperature reaches this pre-set temperature
threshold. The options are 75
o
C, 80
o
C, 85
o
C and 90
o
C.
Highlight this and hit <Enter> to see the data for the following items:
Temperature: This item displays the temperature status of the processors and
the inside of the system.
Fan Speed
This item displays the speed of each onboard cooling fan:
Fan 1 Speed - FAN 6 Speed: Fan
Speed Control Modes
This feature allows the user to decide how the system controls the speeds of
the onboard fans. If the option is set to "3-pin fan", the fan speed is controlled
based upon the CPU die temperature. When the CPU die temperature is higher,
the fan speed will be higher as well. Select "Disable" to disable the fan speed
control function to allow the onboard fans to run at the full speed (12V) at all
time. The Options are: Disabled and 3-pin (Server).
Voltage: This item displays the voltage status of the following items:
VcoreA
1.5V
VIN0 (3.3)
VIN1 (5V)
VIN2 (-12V)
VIN3 (12v)
5Vsb (+5V Standby)
7-17
