Generac Power Systems iQ3600DF Owner's Manual page 17

Transporting/Tipping of the Unit
Personal injury. Excessive weight. Two person lift.
Use only appropriate techniques when lifting
equipment. Improper lifting techniques could result
in equipment damage, death or serious injury.
See 3-2. The handle has two (2) locked
Figure
positions, UP position (A) and DOWN position
(B). When lifting or lowering the handle, press
the handle push button (C) in the direction of
the indicating arrow on the handle push but-
ton. Rotate handle until it locks into desired
position. Verify it is securely locked into posi-
tion.
C
A
B
Figure 3-2.Handle Locking Position
• DO NOT store or transport the unit at an
angle greater than 15 degrees.
• Two (2) people are needed to lift the unit.
• Allow the unit to cool before transporting or
storing in an enclosed area.
• DO NOT move unit during operation.
Starting Pull Start Engines
Recoil Hazard. Recoil could retract unexpectedly.
Kickback could result in death or serious injury.
Equipment and property damage. Disconnect
electrical loads prior to starting or stopping unit.
Failure to do so could result in equipment and
property damage.
1. Unplug all electrical loads from the unit's
receptacles before starting the engine.
2. Place generator on a level surface.
3. See 3-4. Rotate the Fuel Selector
Figure
Knob to the desired fuel source (Gasoline
Owner's Manual for Portable Generator
WARNING
(000805)
WARNING
CAUTION
or LP). If using LP fuel source, connect LP
tank and turn LP tank on.
4. Switch Economy switch to OFF.
5. See
switch (A) is set to ON.
6. Firmly grasp recoil handle and pull slowly
until increased resistance is felt.
7. Pull rapidly up and away.
NOTE: Engine has an auto-choke system that
automatically adjusts the choke for starting.
No manual adjustment is necessary.
NOTE: If engine fires, but does not continue to
run, repeat step 6.
IMPORTANT NOTE: See
overload generator or individual panel
receptacles.
warning LED (A) will illuminate and AC out-
put ceases. To correct, see
Lights. Read
fully.
Starting Electric Start Engines
020029
Equipment and property damage. Disconnect
electrical loads prior to starting or stopping unit.
Failure to do so could result in equipment and
property damage.
1. Unplug all electrical loads from the unit's
receptacles before starting the engine.
2. Place generator on a level surface.
3. See
Knob to the desired fuel source (Gasoline
or LP). If using LP fuel source, connect LP
tank and turn LP tank on.
4. Switch Economy switch to OFF.
5. See
switch (A) is set to ON.
(000183)
(000136)
Figure 3-4. Ensure the main ON/OFF
If an overload occurs, the
Know Generator Limits
B A
Figure 3-3.Shutdown Fault
CAUTION
3-4. Rotate the Fuel Selector
Figure
3-4. Ensure the main ON/OFF
Figure
3-3. Do not
Figure
Generator Status
care-
015139
(000136)
