SSV WORKS, 2610 Calle Quetzal, Camarillo, CA 93012
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or
workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against defects in
material or workmanship. Labor for replacement of defective components is not covered. All SSV
Works Speakers are covered by a limited 1 year warranty against defects in material or workmanship.
Contact SSV Works for further warranty information.
For 2015 to 2021 Models
TOOLS NEEDED
PARTS LIST IMAGES
Driver & Passenger Side
Kick pods (x)1
DRIVER SIDE POD
BRACKETS
PASSENGER SIDE
POD BRACKETS
- 8mm Wrench
- Phillips Screw Driver
M6 x 16mm Screw (x12)
(for brackets) [B-S1457]
Bracket "D" x1
Bracket "P" x1
2015-Up Polaris Slingshot
Front Kick 8"/6.75" Panel Speaker Pods
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
M6 Washer (x18)
[B-W1288
Bracket "DD" x1
Bracket "PP" x1
SS-F68U
Triangular
end
M6 x 25mm Thread Rolling
Screw x6 (for car)
Bracket "DDD" x1
Bracket "PPP" x1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SSV Works SS-F68U
Summary of Contents for SSV Works SS-F68U
- Page 1 WARRANTY INFORMATION: Please read and understand these All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or instructions completely before workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against defects in installation to avoid possible injury, or material or workmanship.
- Page 2 For 2022 and Newer Models PARTS LIST IMAGES Universal 8” to 6.75” #7x1.25” Screws (x2) M6 x 16mm Hex Head Universal 8” to 6.75” Speaker Adapter Gasket [B-HP#7-8] Screw & SS Washer (x2) Speaker adapter (x2) (x2) [B-G3475] [B-HP3602] [B-SE3474] DRIVER SIDE POD BRACKETS Bracket “A”...
- Page 3 If your vehicle did not come with a factory speaker you will need to remove (1) T40 torx screw on both driver and passenger side of the vehicle. The screw secures the vehicle factory plastic side panel to a bracket welded to the chassis tube. See figure C. SS-F68U...
- Page 4 D. Installing the passenger kick pod will require the temporary removal of the factory glove box. Open the glove box door and release the tabs that are located at the back of the compartment. Lift and remove the glove box. E.
-
Page 5: Mounting Bracket Locations
C. If your vehicle came with factory speakers, remove the driver and passenger factory speaker enclosures by unhooking the rubber clamp securing each speaker enclosure to the tube chassis and pop out the peg from the rubber grommets (figure C). Disconnect the factory connector and remove the speaker enclosure. SS-F68U... - Page 6 D. Installing the passenger kick pod will require the temporary removal of the factory glove box. Open the glove box door and release the tabs that are located at the back of the compartment. Lift and remove the glove box. E.
-
Page 7: Wiring Instructions
USING A SSV WORKS HARNESS Connecting the SS-F68U using the pre-installed, two-pin connector will require an optional SSV Works harness (B-H1909). If you are not using the SS-F68U plug-&-play harness, simply cut off the two-pin connector and follow the wiring instruction below.
