SSV Works RG4-Q5VRC Manual

5 speaker rgb led audio kit for 2018-up polaris ranger xp1000 with ride command
Hide thumbs

Advertisement

Quick Links

Download this manual
SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com
|
Phone: 818-991-1778
3
pg
Panels and Dash
Disassembly
5
pg
Amp Tray
Installation
8
pg
LIT-CC RGB Controller
Installation
9
pg
Subwoofer
Installation
12
pg
RGB Kick Panel Speakers
Installation
14
pg
Rear RGB Cage Pod Speakers
Installation
|
Fax: 866-293-6751
Ranger XP1000
RG4-Q5VRC
2018-Up Polaris Ranger XP1000
with Ride Command
5 Speaker RGB LED Audio Kit

Advertisement

loading
Need help?

Need help?

Do you have a question about the RG4-Q5VRC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SSV Works RG4-Q5VRC

Summary of Contents for SSV Works RG4-Q5VRC

  • Page 1 RG4-Q5VRC 2018-Up Polaris Ranger XP1000 with Ride Command SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030 5 Speaker RGB LED Audio Kit www.SSVworks.com Phone: 818-991-1778 Fax: 866-293-6751 Ranger XP1000 Panels and Dash Disassembly Amp Tray Installation LIT-CC RGB Controller...
  • Page 2 WIRING DIAGRAM OF COMPLETE KIT Figure 1 Figure 1 is designed to show the installer a reference overview of the complete 5 speaker RGB LED wiring diagram. Each installation section will have its own detailed wiring diagram. Description Part # Ranger Ride Command Harness B-H3076 Ranger Amplifier Anti-POP Circuit...

  • Page 3: Tools Needed For Installation

    All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or workmanship. instructions completely before All SSV Works Electronics are covered by a limited 1 year warranty against defects in material or workmanship. installation to avoid possible injury, or Labor for replacement of defective components is not covered.
  • Page 4 G. Extract push pins exposed from cup holder removal. H. Extract push pins exposed from gauge cluster removal. I. Extract push pins located above driver and passenger side cup J. Lift to remove the dash. holders. K. Extract push pins located beneath 12v sockets. L.
  • Page 5 WARRANTY INFORMATION: Please read and understand these All SSV Works enclosures are covered by a limited lifetime warranty against defects in material instructions completely before or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against installation to avoid possible injury, or defects in material or workmanship.
  • Page 6 A. Unscrew the two (2) torx screws connecting the dash bracket at the rear B. Move the factory wiring to the rear of the dash cavity. Place the of the dash cavity. Remove the under dash bracket. RG4 Amp mounting plate in the former location of the factory NOTE: IT WILL NOT BE RE-INSTALLED.
  • Page 7 I. Route the (B-H2935) Audio/RGB front harness towards the driver and passenger side of the dash. Secure the harness with zip ties away from any moving parts and sharp edges. RZR PRO XP RIDE COMMAND WIRING CONNECTION Not used Not used Not used Not used Not used...
  • Page 8 WARRANTY INFORMATION: All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against defects in material or workmanship. Labor for replacement of defective components is not covered. Contact SSV Works for further warranty information.
  • Page 9 RGB LED CONTROLLER COMMAND CENTER WIRING DIAGRAM Detail Description Description Part # RGB LED Controller Rocker Switch for LIT-CC B-H2367 Connect RGB LED Rocker Switch to LIT-CC LIT-CC RGB LED Controller Command Center 230-LIT-CC Connect Outputs to Front Speaker and Rear Extension Harnesses LIT-CC Power Harness Connect LIT-CC Power Harness to Battery or ACC Battery...
  • Page 10 SUBWOOFER ENCLOSURE INSTALLATION TOOLS NEEDED FOR INSTALLATION - Panel Removal Tool - Drill - 13/64” Drill Bit - T-30 & T-40 Torx Driver - 4mm Allen Key B. Flip up passenger seat and remove center tray to access A. Align bracket A’s holes with the dimples/recess’ circled in pink on the bottom of the enclosure.
  • Page 11 H. Once marked, remove the enclosure. Using a I. . Re-install the sub-enclosure. Secure the front G. With the brackets seated into one another, 13/64” drill bit, drill pilot holes at your marked mounting tabs with the kit provide T30 torx use the front mounting tabs as a template points.
  • Page 12 FRONT RGB LED KICK PODS PARTS LIST PARTS LIST IMAGES 1. RG4-F65V Enclosures 2. Enclosure Brackets x 4 3. M6 x 16mm Screws 4. M6 Washers x 8 (small) 4. M6 Washers x 2 (large) (1 pair) x 10 RGB LED FRONT KICK PODS ASSEMBLY TOOLS NEEDED FOR INSTALLATION - T-30 Torx Driver - Panel Removal Tool...
  • Page 13 E. Place the speaker pod in location and resecure the factory screws through the pod brackets on the front and underneath the dash. P. From the inside-top of the dash, secure the top mounting M6 screw and large washer to the pod through the smaller hole next to the routed speaker wire (figure F1).
  • Page 14 REAR RGB LED CAGE POD PARTS LIST Placement of the speaker pods depends on what type of roll cage you have (factory or aftermarket) and your preference of where you want the pods to be installed. In these instructions, we have installed them on the outside vertical bars at the back of the roll cage. PARTS LIST IMAGES 3.
  • Page 15 A. Find the best orientation for the speaker on your bar and B. Loosely install the clamp base to the cage mount pod with the screw in the Set Screws in the OPPOSITE holes of where the two (2) M6 Hex head bolts and washers, place the cage mount clamp will install into.
  • Page 16 G. Take the B-H2936 rear speaker harness and plug into the H. Route the rear speaker and RGB extension harnesses B-H1913 & B-H1912 rear audio extension and RGB extension (B-H1913, B-H1912, B-H2934 & B-H2933) along the factory harnesses. wires towards the amplifier and LIT-CC location. REAR RGB LED SPEAKER PODS WIRING DIAGRAM Description Part #...
  • Page 17 CONNECTING POWER & GROUND CABLE TO BATTERY Battery Terminal Cable Power Wire Break Break off tab off tab A1. Remove the bottom cover of the fuse holder A2. Extract both fuse holder screws and fasten A3. Attach both the Power Wire and Battery by extracting the 2 screws.

  • Page 18: Amp Wiring Diagram

    Install fuseholder between B-H1587 & battery terminal cable. Connect ground ring terminal to chassis ground. THIS CONCLUDES THE INSTALLATION PROCESS. REPLACE THE FACTORY PANELS AND SEATS. QUESTIONS? PLEASE CONTACT SSV WORKS AT 818-991-1778 OR EMAIL SUPPORT@SSVWORKS.COM © 2024 SSV Works, Oxnard, CA 93030 RG4-Q3V1 1-8-24...
