Nav TV NTV-KIT955 Quick Start Manual

Gm ios,iot,iok avb to rca, spdif & toslink sound processor

Advertisement

Quick Links

th
3950 NW 120
Ave, Coral Springs, FL 33065 TEL 561-955-9770 FAX 561-955-9760
GM IOS,IOT,IOK AVB to RCA, SPDIF & TosLink sound processor
NTV-KIT955

Advertisement

loading
Need help?

Need help?

Do you have a question about the NTV-KIT955 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nav TV NTV-KIT955

  • Page 1 3950 NW 120 Ave, Coral Springs, FL 33065 TEL 561-955-9770 FAX 561-955-9760 GM IOS,IOT,IOK AVB to RCA, SPDIF & TosLink sound processor NTV-KIT955...
  • Page 2 03/04/20 NTV-DOC349 Overview NAV-TV’s AVB-GM processor seamlessly converts GM’s AVB bus to low level (6 channel) RCA or TOSLink outputs. Adding an aftermarket amplifier to the OE BOSE IOS/IOT system will never be so easy or seamless. This plug & play kit integrates with various OEM data networks to retain OnStar, door chimes, volume control, full fade and balance (analog only), treble, mid-range, bass control &...
  • Page 3 03/04/20 IMPORTANT NOTE: Many GM vehicles have poor chassis grounding. BEFORE connecting this NTV-DOC349 interface, check the GROUND to the amplifier using a digital multimeter. If resistance (reference vehicle’s battery negative) is greater than 1 OHM, run amp ground directly to battery or find a better ground source.
  • Page 4 03/04/20 IMPORTANT NOTE: Many GM vehicles have poor chassis grounding. BEFORE connecting this NTV-DOC349 interface, check the GROUND to the amplifier using a digital multimeter. If resistance (reference if you have the BOSE amp without the Brown plug follow the diagram below: Please note you will also need to set the dipswitch 1 accordingly P a g e...
  • Page 5 03/04/20 NTV-DOC349 AVB-GM Installation 1. Use the chart on page 3 to locate the OEM amplifier. Access the amplifier and remove all plugs. 2. Connect the provided 16-PIN connectors (brown & black) to the previously removed 16-pin plugs from the OE amplifier. The other connectors connected to the OE BOSE amp contain OE speaker wires. See pin-outs (page 6-7) to use for aftermarket amplification, if desired.
  • Page 6 03/04/20 NTV-DOC349 AVB-GM System Layout Options TYPE 1: Signal directly to amp, no additional external processor TYPE 2: Signal to additional external processor, then to amplifier P a g e...
  • Page 7 03/04/20 NTV-DOC349 OEM BOSE Amp Pin-Outs Size Color Type Option Circuit Function Terminal (1)- (7)7 (7)7 BU/GY Left/Rear Subwoofer Speaker Control(+) (1)1 (2)YE Right Front Speaker Control(+) (2)1 (2)- (3) 3 (3)BU Left Front Speaker Control(+) (3) I (3)- (4)- RD/YE 3740 Battery...
  • Page 8 03/04/20 NTV-DOC349 OEM BOSE Amp Pin-Outs P a g e...
  • Page 9 03/04/20 NTV-DOC349 ZEN Configuration: Analog Outputs (online tool) To access the ZEN online configuration tool, first connect the provided USB cable from the ZEN module to the computer. Open an internet browser and navigate to zen/ If using a PC or zen.local/ if using a Mac.
  • Page 10 03/04/20 NTV-DOC349 ZEN Configuration: Digital Outputs (online tool) For Digital TOSLink output, Tones and Chimes will mimic factory output on the front and rear channels. Adjust output level to suit. Once complete, select SAVE to store the settings in the ZEN module. ZEN Configuration: Global Adjustments (online tool) •...
  • Page 11 03/04/20 NTV-DOC349 AVB-GM Technical Specifications Hardware & Software Current HW version: Version 1.0 Current SW version: ZEN-AVBGM-1.1-7-11-13-19.enc Compatible SW (update) OS: Windows 7 (64 bit), 8, 10 INPUT Digital Input AVB, GM-LAN OUTPUT Digital Outputs: TosLink Digital Outputs supported: 24bit/48kHz Frequency Response (digital): 18Hz –...
  • Page 12 03/04/20 NTV-DOC349 AVB-GM Pin Out Pin # Description Color CAN HIGH White CAN LOW White & Silver --Empty-- GM-LAN Green --Empty-- Ground (-) Black AVB TX (+) Orange AVB TX (-) White/Orange --Empty-- --Empty-- NTV-HAR310 Remote OUT Blue Wire Side 12v Batt (+) Yellow •...
