2009-up mercedes gl/ml/r/e/cls/slk new generation backup camera / av input / rse / video in motion interface

Advertisement

Backup camera / AV input / RSE / Video In Motion interface
Thank you for purchasing the NTG3, a multi-featured integration interface designed specifically
for 2009 Model Year Mercedes Vehicles equipped with next-generation radios.
Backup Camera:
Vehicles not equipped with a Backup Camera can be retrofitted with a Camera in an OEM fashion.
Programming is done via the NTG3 interface, All required wiring is included; OEM-Grade Cameras are available
separately from NAV-TV.
Rear Seat Entertainment:
interface comes standard with zoned A/V outputs. The front DVD player can be used to drive rear screens, even
while the driver is listening to Radio, HD, MP3's, iPod or SAT radio. Rear passengers can enjoy iPod, Radio or SAT
music while the driver listens to CD's. Additionally, a rear mounted DVD player or Video iPod could be routed to the
radio for Front passenger entertainment
additional AUX Audio input labeled REAR is available as well for CE devices such as Music players.
Video-in-motion:
Where applicable by law, and for passenger use only, Front DVD and AUX video could be enabled
while the vehicle is in motion. Please do not drive and watch movies! it is illegal in many states and most importantly
- dangerous.
WARNING: Check entire surroundings while backing. Do not become distracted by using COMAND.
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. Would not be held liable for misuse of it's product.
NAV-TV
www.nav-tv.com
NTG3 / NTG3E /NTG3SLK
2009-up Mercedes GL/ML/R/E/CLS/SLK New Generation
Product Description
Adding Rear screens, headphones and rear DVD players could not be easier. The NTG3
(Not for the driver's use while operating the vehicle, see Agreement below
If you do not agree, please discontinue use immediately and return product to place of purchase.
This product is intended for off-road use and passenger entertainment only.
100 NW 11
th
street, Boca Raton, FL 33432
Tel. 561-955-9770
Fax. 561-955-9760
info@nav-tv.com
NTG3 2.10.09
Moni
Rev. 1.5 Tony Yankovsky
). An

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTG3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nav TV NTG3

  • Page 1 Backup Camera: Vehicles not equipped with a Backup Camera can be retrofitted with a Camera in an OEM fashion. Programming is done via the NTG3 interface, All required wiring is included; OEM-Grade Cameras are available separately from NAV-TV. Rear Seat Entertainment: Adding Rear screens, headphones and rear DVD players could not be easier.
  • Page 2 Boca Raton, FL 33432 Tel. 561-955-9770 Fax. 561-955-9760 www.nav-tv.com info@nav-tv.com NTG3 / NTG3E /NTG3SLK 2009-up Mercedes GL/ML/R/E/CLS/SLK New Generation Backup camera / AV input / RSE / Video In Motion interface Operation Instructions To Activate Rear View Camera Fig. 1 - Vehicle in Reverse With the brake depressed and engine running, engage reverse gear.
  • Page 3 Plug Fiber connector into supplied plug and play harness connector. 3. Plug in the NTG3 adapter harness to factory harness, Radio and NTG3 Module. 4. If adding Rear-view Camera: Plug video cable to Green FAKRA, Connect to Camera.
  • Page 4 Factory Reset GL, ML, R Class Important Note: Press and hold NTG3 Must learn the VIN and can not be 30 seconds: re-installed in a different vehicle unless origi- nal vehicle has been reset to factory settings! VR OFF + VR...
