Schematics
This section provides the design schematics for the STM32-MICRIUM evaluation board
board key features, to help you implement these features in your applications.
The following schematics are provided:
Figure 5: Block diagram on page 15
Figure 6: STM32F107VCT6 on page 16
Figure 7: CAN on page 17
Figure 8: Ethernet on page 18
Figure 9: Extension connector on page 19
Figure 10: SD card on page 20
Figure 11: Temperature sensor on page 21
Figure 12: RS-232 on page 22
Figure 13: USB-OTG-FS on page 23
Figure 14: J-Link on page 24
Figure 15: Power on page 25
