- Page 1 OWNER'S MANUAL DOMINATOR Product may vary slightly from the item pictured due to model upgrades DOMINATOR...
-
Page 2: Important Safety Instructions
Never operate the treadmill if it has a damaged cord or plug. Keep the cord away from heated surfaces. Do not operate where aerosol spray products are being used or where oxygen is being administered. Sparks from the motor may ignite a highly gaseous environment. DOMINATOR... -
Page 3: Important Electrical Information
Be sure to read the entire manual before operating your machine. Understand that changes in speed and incline do not occur immediately. Set your desired speed on the computer console and release the adjustment key. The computer will obey the command gradually. DOMINATOR... - Page 4 A safety key is provided with this machine. Remove the safety key will stop the walking belt immediately; the treadmill will shut off automatically. Insert the safety key will reset the display. Do not use excessive pressure on console control keys. They are precision set to function properly with little finger pressure. DOMINATOR...
-
Page 5: Fixing Tools
42 FLAT 19 BOLT M8*26 8 MAIN FRAME WASHER 8 WASHER 10 ST4.2*12 61 WRENCH 59 6# ALLEN 60 5# ALLEN W/SCREW WRENCH 6mm WRENCH 5mm DRIVER FIXING TOOLS: ALLEN WRENCH :6mm 1 pcs ALLEN WRENCH: 5mm 1 pcs DOMINATOR... -
Page 6: Assembly Steps
5. Connect the computer right cable between computer frame and right upright. 6. Insert computer frame into left upright and right upright. Connect them with the bolts M10*25 (20) and flat washer (42). CAUTION: Tighten all the bolts again. DOMINATOR... -
Page 7: Technical Parameter
4. Children should not be allowed to play on the treadmill or move the treadmill deck up and down. TECHNICAL PARAMETER BUILT UP SIZE(mm) 1980*910*1325 POWER 220V~240V(50~60HZ) RUNNING BELT SIZE(mm) 3150*520 SPEED RANGE 1—20 Km/h FOLDABLE SIZE(mm) 890*910*1790 NET WEIGHT 117.5KGS SIGNAL BLUE SPEED, DISTANCE, CALORIES, PULSE, TIME and INCLINE BACKGROUND DISPLAY DOMINATOR... -
Page 8: Exercise Guide
So as you can see, the fitter you are, the healthier and greater you will feel. Warm-up Start each workout with 5 to 10 minutes of stretching and some light exercises. A proper warm-up increases your body temperature, heart rate and circulation in preparation for exercise. Ease into your exercise. DOMINATOR... -
Page 9: Workout Guidelines
EXERCISE. REMEMBER TO WARM UP AND COOL DOWN FOR A FEW MINUTES. The most important factor here is the amount of effort you put in. The harder and longer you work the more calories you will burn. Effectively this is the same as if you were DOMINATOR... -
Page 10: Operation Guide
400 racetrack, LAPS means circles. 2、Function button: POWER、 START/STOP、 SELECT、 ENTER、 INCLINE▲、 INCLINE▼、 SPEED▼、 SPEED▲、SPEED SHORTCUT KEY(RIGHT 10)、INCLINE SHORTCUT KEY (LEFT 10). 3、Function button explanation: A. POWER ： When you open the power switch and press POWER DOMINATOR... - Page 11 G.SPEED SHORTCUT KEY: When the treadmill is running, pressing the SPEED SHORTCUT KEY will adjust the speed to be exactly you need. H. INCLINE SHORTCUT KEY: When the treadmill is running, pressing the INCLINE SHORTCUT KEY will adjust the incline to be exactly you need. DOMINATOR...
-
Page 12: Time Interval
1.0km/hour after 3 seconds. 4、After start-up, you can use speed up or down to adjust the speed and use incline up or down to adjust the incline. DOMINATOR... -
Page 13: Safety Lock Function
2. Attach the magnet end of the safety pulling rope to the computer and also attach the clip of the safety pulling rope to your clothing. 3. To end your workout safely, press the STOP button or pull out the safety pulling rope, then the treadmill will stop immediately. DOMINATOR... -
Page 14: Range Of Program
2.Checking the button is 2. Reset the START KEY to 2.Do not press START KEY. valid or not started the test. switch. 3.Checking the safety pull 3.Safety pull pin not inserted 3.Insert safety pull pin. pin is plugged well. DOMINATOR... - Page 15 3.Put both hands to bedew The hand pulse does 3.Reset to test. little or scrub with both touch well hands. 1.the connected wire is 1.Use the multimeter to test the Message failure wrong. wire is stand or fall. DOMINATOR...
- Page 16 1．Safety lock badness 1．Change the safety lock 2．Test the iron piece of the Out of safety lock 2．Computer badness safety lock is dropped out or change the computer. 1． Change 24C02 EEPROM 24C02 message failure 1．Data transfer failure DOMINATOR...
-
Page 17: Maintenance Instructions
• Inspect the power cord. If the power cord is damaged, contact Lifespan Fitness. • Make sure the power cord is not underneath the treadmill or in any other area where it can become pinched or cut. -
Page 18: Every 6 Months
It may be necessary to lubricate your treadmill running deck at least once every six months to maintain optimal performance of your treadmill (refer to section 4.4 for information). Only use lubricant provided by Lifespan Fitness! Please contact Lifespan Fitness with questions about applying lubricant to your treadmill. -
Page 19: How To Check The Running Mat For Proper Lubrication
If the surface is dry to the touch, apply a suitable silicone lubricant. We recommend you use a silicone based spray to lubricate your Lifespan Treadmill. This Can be purchased from your local sports Retailer or a local hardware store. -
Page 20: Belt Adjustment
After a few minutes of use, the belt should have a tendency to centre itself. If during use, the belt continues to move toward one DOMINATOR... -
Page 21: Warranty Registration
Please visit the following link to complete the product warranty form online. Please visit: http://www. warrantyform.lifespanfitness.com.au PLEASE NOTE: YOUR WARRANTY IS ONLY VALID IF YOU CAN PROVE YOU ARE THE ORIGINAL PURCHASER ON THIS ITEM (i.e. A copy of the receipt, invoice, delivery date or internet confirmation). DOMINATOR... -
Page 22: Exploded Drawing
EXPLODED DRAWING DOMINATOR... -
Page 23: Parts List
RIGHT INSIDE PLASTIC 280*160*123 M10*45 20 COVER HANDLEBAR TUBE BOLT M8*30 20 φ38*50 M8*26 RIGHT SOUND BOLT 153.4*100*14.5 CONNECTED BOARD LEFT SOUND BOLT 153.4*100*14.5 M10*25 CONNECTED BOARD BOLT RIGHT END CAP 109.5*160*120 M8*45 30 BOLT LEFT END CAP 109.5*￠160*120 M8*52 30 DOMINATOR... - Page 24 FLAT WASHER ADJUST AXIS CORE φ30*30 SPRING WASHER COMPUTER CONTROL BOARD COMPUTER UPPER AC SINGLE LINE LINE LONG 120 LINE LONG 900mm WIRE COMPUTER MIDDLE LINE LONG M8*8 BOLT WIRE 1200mm COMPUTER LOWER M6*40 LINE LONG 800mm SCREW WIRE DOMINATOR...
- Page 25 SLIDE RAIL AXIS INCLINE MOTOR φ18*645 65mm, CORE LIMIT DIGIT AXIS OVER LOADING φ18*552 CORE PROTECTOR OILINESS BUSHING φ20*φ8.2*9 SWITCH 45KG POWER CABLE LINE LONG 2600 AIR PRESSURE BAR 6# ALLEN WRENCH ∮16* 28*28 MAGNETIC RING ∮ 5# ALLEN WRENCH DOMINATOR...
- Page 26 DOMINATOR...
