Summary of Contents for PureLink OLC III
- Page 1 Optical Extender (Multi-Mode) Installation Guide...
- Page 2 ✔ Manufacturer : Purelink ✔ Part No. : OLC III XXX-XXX-XXX-X-XXXXX...
- Page 3 Optical Extender (Multi-Mode) Installation Guide...
- Page 4 Packing List Additional Packing List -Power Supply -Quick start guide...
- Page 5 Features • High Speed and long distance transmission by single LC type Multi-mode Fiber • Single Link TMDS video signals and EDID data are transmitted by optical fiber • Extends up to 300m by Multi-mode OM3 fiber • DVI Specification 1.0 Compliant •...
- Page 6 Connection ● Caution ✔ Use the DC adapter (5V) included in the product package for the transmitter and Receiver. ✔ Connect Multi-mode OM3 Fiber-Optic cable in order to transmit the signal till 300 meters distance.
- Page 7 Connection Connect transmitter to the DVI port on your computer. • Connect receiver to the DVI port on your digital display product. • Connect Multi-mode LC type 1 channel standard fiber-optic cable • between transmitter and receiver. Connect power adapter to the transmitter and receiver which has been •...
- Page 8 Precautions for Safety Make sure to comply with precautions to prevent danger and damage on the property through proper usage product. This symbol is intended to alert you that uninsulated voltage Within this product may have sufficient magnitude to cause Electric shock. Therefore, it is dangerous to make any kind of Contact with any inside part of this product.
- Page 9 Insert the power plug firmly to avoid shanking. If not inserted firmly, it can cause major issues. Do not disassemble, repair and modify. It can cause a fire and an injury by electrical shock due to abnormal operation. Do not insert a metallic material (ex. hair pin or ironware) or combustible foreign object (ex.
- Page 10 Dtrovision, LLC. (hereinafter “PureLink”) warrants its HDTools and PureStreamTM branded products (hereinafter “Product”) purchased directly from PureLink or Dealer shall be free from defects in workmanship and materials, under normal use and service, for a period of five (5) years on parts and five (5) years on labor.
- Page 11 TERMS & CONDITIONS PureLink shall repair or replace the Product if it develops a material fault during the period of warranty, on condition that i) the Product has only been subject to normal use in a domestic or commercial environment in a manner consistent with its specification...
- Page 12 To make a warranty claim, promptly notify PureLink within the warranty periods described above by calling PureLink’s Technical Support Department at 1-201-488-3232. PureLink, in its sole discretion, will determine what action, if any, is required under this warranty. Most problems can be corrected over the phone through close cooperation between Customer and a PureLink technician.
- Page 13 Technical Support 22-10 State Route 208 Fair Lawn, NJ 07410 USA Technical support inquiries can be submitted electronically through the PureLink website at www.purelinkav.com. For immediate assistance please contact PureLink’s Customer Care Team at +1 (201) 488-3232.
