SEA USER 1 DG MAXI Manual

Control unit to manage a 24v sliding operator
Hide thumbs

Advertisement

Quick Links

Download this manual
Compliance with
ANSI/UL/CSA 325:2003
(7th Ed., Feb. 21, 2023)
USER 1 DG MAXI
CONTROL UNIT
TO MANAGE A 24V
SLIDING OPERATOR
SEA USA Inc.
10850 N.W. - 21st - unit 160 - Doral - MIAMI - Florida (FL) - 33172 - USA
Telephone: ++1-305.594.1151
www.sea-usa.com
67412000
REV. 06 - 01/2025

Advertisement

loading
Need help?

Need help?

Do you have a question about the USER 1 DG MAXI and is the answer not in the manual?

Questions and answers

Related Manuals for SEA USER 1 DG MAXI

Summary of Contents for SEA USER 1 DG MAXI

  • Page 1 Compliance with ANSI/UL/CSA 325:2003 (7th Ed., Feb. 21, 2023) USER 1 DG MAXI CONTROL UNIT TO MANAGE A 24V SLIDING OPERATOR SEA USA Inc. 10850 N.W. - 21st - unit 160 - Doral - MIAMI - Florida (FL) - 33172 - USA Telephone: ++1-305.594.1151...
  • Page 2 INDEX SAFETY INFORMATION AND «UL» STANDARDS REQUIREMENTS PRELIMINARY INFORMATION AND PRODUCT DETAILS 1 - WIRINGS 2 - CONNECTIONS ON CN1 START, PARTIAL START STOP , « » « » , 24V CONNECTIONS ON CONNECTIONS ON CONNECTIONS ON CN4 - PRIMARY/SECONDARY OPERATION ( CONNECTIONS ON CONNECTIONS ON CONNECTIONS ON...
  • Page 3 INDEX 13 - ADDITIONAL FUNCTIONS OF THE CONTROL UNIT , « » 14 - DISPLAY OPERATION AND PROGRAMMING MENU 15 - BASIC MENU 16 - INPUTS STATUS MANAGEMENT N.C. N.O. 17 - WORKING TIMES LEARNING - PROGRAMMING OF THE CONTROL UNIT 18 - OPERATING LOGICS 19 - PASSWORD - PROTECTION OF THE CONTROL UNIT BY PASSWORD...
  • Page 4 UL 325 ED. 7 FOR GATE OPERATORS GENERAL SAFETY PRECAUTIONS The following precautions are an integral and essential part of the product and must be supplied to the user; Read them carefully as they contain important indications for the safe installation, use and maintenance. 1.
  • Page 5 A gate operator shall be provided with the specific instructions describing all user adjustments required for proper operation of the gate. Detailed instructions shall be provided regarding user adjustment of any clutch or pressure relief adjustments provided. The instructions shall also indicate the need for periodic checking and adjustment by a qualified technician of the control mechanism for force, speed, and sensitivity.
  • Page 6 e. A wireless contact sensor such as one that transmits radio frequency (RF) signals to the gate operator for entrapment protection functions shall be located where the transmission of the signals is not obstructed or impeded by building structures, natural landscaping or similar obstruction. A wireless contact sensor shall function under the intended end-use conditions.
  • Page 7 As for misunderstandings that may arise refer to your area distributor or call our help desk. These instructions are part of the device and must be kept in a well-known place. The installer shall follow the provided instructions thoroughly. SEA products must only be used to automate doors, gates and wings.

  • Page 8: Technical Information

    PRELIMINARY USER 1 24V DG MAXI requires the programming of the working times (chapter 17); it is not possible to start the operator correctly without first programming the control unit! The unit and the accessories programming and settings can be carried out by the display on board or by the JOLLY 3 programmer or SEACLOUD JOLLY 3 SEACLOUD...
  • Page 9 1 - CONNECTIONS Make all the wirings when the control unit is not powered! Keep the power cables separate from the command cables - always run cables in separate sheaths to prevent interferences! OPTIONAL JUMPERS ANT COM START STPD STOP COM PH1 PH2 EDGE1 24VAUX COM 24V(FL) FL(-) N.C.
  • Page 10 2 - CONNECTIONS ON CN1 2.1 - START (N.O.) Connect the « » command on clamps 3 and 6 (or 2) START Logics to be linked to the « » command in chapter 18 START If the input is engaged during the pause time, the g a t e d o e s n o t c l o s e u n t i l t h e i n p u t i s r e l e a s e d 2.2 - PARTIAL START (N.O.) Connect the «...
  • Page 11 2.6 - 24V FLASHING LIGHT - MAX 3W The flashing lamp can be wired on clamps 12 and 13 Door movement signals: BLINK SECOND IN OPENING BLINKS SECOND IN CLOSING TEADY LIT DURING PAUSE Management of the flashing lamp operating FLASHING LASHING LAMP mode from menu 86...

  • Page 12: External Receiver

    2.9 - 10K PHOTOCELL SINGLE OR DOUBLE It is possible to wire up to two couples of 10K photocells on * or to clamps 9 - 11(or COM 6) - 12, as shown on the side COM 6 Set the menu 100 on « 10K»...
  • Page 13 2.13 - LATCH OPENING OR LATCH CLOSING BUTTON Wire the button to be used as LATCH on clamps 4 and 6 OPENING LATCH «P » XAMPLE Management: set the desired operation mode (in opening or in closing) via the menu 118 To enable the , press the ;...
  • Page 14 3 - CONNECTION ON CN2 3.1 - PRE-WIRED LIMIT SWITCH It is possible to connect the pre-wired limit switch to the CN2 connector; Respect the cable colors The type of limit switch is automatically detected during the working times learning WIRED WIRED XAMPLE...
  • Page 15 5 - CONNECTION ON CN4 5.1 - «PRIMARY/SECONDARY» (MASTER/SLAVE) CIRCUITS mode: to manage 2 operators (ex. opposite barriers or bollards) RIMARY ECONDARY having each one its control unit Wire each « » circuit to the CN4 connector of each control unit PRIMARY SECONDARY PRIMARY...
  • Page 16 6 - CONNECTION ON CN5 The CN5 connector is adjustable via and can be used either as a 24V JUMPER output for the direct connection of 24V accessories or as a dry contact to connect 24V accessories via external power supply 6.1 - DIRECT CONNECTION OF 24V ACCESSORIES By adjusting the two as shown on the...

  • Page 17: Emergency Batteries

    CONNECTIONS ON 8.1 - EMERGENCY BATTERIES It is possible to connect a group of two 12V BATTERIES E-SUN Q batteries in series (24V Pb 1.2Ah min.) to the operator, via the battery charger unit «E-SUN Q» battery charger unit keeps a «E-SUN Q»...
  • Page 18 10 - CONNECTIONS ON 10.1 - STANDARD ENCODER CONNECTION Connect the on CNE via the special ENCODER ENCODER ON THE MOTOR pre-wired connector. Respect the cables colors and the plug-in way! BLACK Some Encoder models may have different cables BLUE colors;...
  • Page 19 12 - CONNECTIONS ON 12.1 - «SEM 2» MANAGEMENT UNIT The SEM 2 accessories management unit 24V~ / (ac/dc) or 230V~ allows you to connect and manage the following additional accessories: - - - - - - - - - - - - - - - - SEM 2 READS THE LIMIT SWITCHES STATUS - - - - - - - -...
  • Page 20 12.4 - LINEAR POTENTIOMETER CONFIGURATION The menus 51-52-53 are visible only when the menu 32 is set to « » POTENTIOMETER Motor 1 partial impulses - menu 51 ; display of the operator current position I. PAR. M1 Motor 1 impulses in opening - menu 52 ; display of the impulses when the leaf is completely I.

  • Page 21: Additional Functions

    13 - ADDITIONAL FUNCTIONS 13.1 - AMPEROMETRIC MANAGEMENT - FOR ELECTROMECHANICAL OPERATORS ONLY! The control unit is equipped with an (for electromechanical operators OBSTACLE DETECTION SYSTEM only), which allows the inversion in case of obstacle and the automatic detection of the mechanical stops Torque parameters setting in opening and closing for adjustment of the inversion force on obstacle...
  • Page 22 14 - DISPLAY and PROGRAMMING CONNECT ALL THE ACCESSORIES WHEN THE CONTROL UNIT IS SWITCHED OFF! AFTER ALL CONNECTIONS HAVE BEEN MADE, POWER ON THE UNIT FOR SETTINGS 14.1 - POWER ON THE CONTROL UNIT SOFTWARE INPUTS STATUS OWER BASIC REVISION (CHAPTER 16) MENU...

  • Page 23: Basic Menu

    15 - BASIC MENU RETURN TO ENGLISH LANGUAGE THE MAIN MENU DOWN SKIP THIS STEP IF YOU DO NOT NEED TO PROGRAM THE TX CONFIRM READ THE AND EXIT CHAPTER 20 PRESS ON THE TX PRESS STORED START BEFORE THE BUTTON TRANSMITTERS BUTTON PROGRAMMING...
  • Page 24 16 - INPUTS STATUS MANAGEMENT 16.1 - INPUT STATUS DISPLAY Every input corresponds to a fixed position on the display, according to the diagram below Every input can be: (0) - N.O. - N.C. - START (*) MOTOR 1 OPENING LIMIT SWITCH 1 2 3 4 5 6 7 8 PARTIAL START MOTOR 1 CLOSING LIMIT SWITCH...
  • Page 25 16.3 - INPUTS MANAGEMENT MENU HIS MENU ALLOWS TO ENABLE OR DISABLE THE INPUTS WITHOUT REPEATING THE WORKING TIMES LEARNING LANGUAGE HOLD PRESSED 5 SECONDS TO ACCESS START ENABLED START RETURN START DISABLED DOWN PARTIAL ENABLED START PARTIAL RETURN START PARTIAL DISABLED START...

  • Page 26: Preliminary Settings

    17 - WORKING TIMES LEARNING DANGER! AVE A QUALIFIED SERVICE PERSON TO CARRY OUT THE OPERATIONS IN SAFE CONDITIONS Check the correct operation of all accessories (photocells, buttons, etc.) Do not jumper the inputs not in use (limit switch, safety edge, etc.) 17.1 - PRELIMINARY SETTINGS Before programming the working times, it is necessary to carry out the essential settings of the basic menu.
  • Page 27 17.3 - QUICK LEARNING - ONLY FOR SLIDING OPERATORS The control unit on board the SEA sliding operators is pre-set by default (model and parameters) to allow the quick learning of the working times GATE ON HALFWAY XAMPLE OWER OWER...
  • Page 28 17.5 - WORKING TIMES LEARNING BY STANDARD ENCODER Times learning through automatic detection of the end-of-stroke points Enable the encoder reading by setting to «ON» the special menu 32 see paragraph 17.2) Start-up the working times learning by following the procedure below OWER GATE ON HALFWAY OWER...
  • Page 29 17.7 - WORKING TIMES LEARNING BY MANUAL PULSES Working times learning through manual pulses on the points of stop If installed, enable the encoder in the special menu 32, otherwise set to OFF (paragraph 17.2) OWER LOCK OWER UNLOCK LEAF ON HALFWAY INPUTS SOFTWARE STATUS...
  • Page 30 Once the password is enabled, all the menus can not be adjusted, they are only displayed If you forget the password, contact the SEA technical assistance: SEA reserves the right to evaluate and decide whether to provide or not the unlocking procedure...
  • Page 31 20 - RECEIVERS AND TRANSMITTERS ONNECT THE RECEIVER CIRCUIT WHEN THE CONTROL UNIT IS NOT POWERED AS INDICATED IN CHAPTER When the control unit is switched-off, check if the receiver is correctly plugged in Program the transmitters before connecting the antenna Program the transmitters only when the gate is closed and the motor is stopped allow the use of both r allows the use of the...
  • Page 32 20.4 - TRANSMITTERS FUNCTIONS DIAGRAM T H E « S T A R T » COMMAND MUST ALWAYS PRESS STORED START BE STORED ON THE FIRST LANGUAGE TRANSMITTERS BUTTON TX CHANNEL PRESS THE BUTTON TO STORE SETTING OF THE PARTIAL START PARTIAL PRESS STORED...
  • Page 33 21 - ALARMS XAMPLE 21.1 - FAULTS SHOWN ON THE DISPLAY LIMIT SWITCH EXIT The control unit advises of the faults may happen through a FAULT message on the display (Note: press ok to exit the message) Below the list of the faults that are signaled on the display and the possible solutions to the problems (if the fault message holds out, contact the technical support) SOLUTION WARNING MESSAGE...
  • Page 34 21.2 - FAULTS SIGNALED ON THE FLASHING LIGHT It is also possible to visualize the warning signals through the flashing light simply by observing the number of flashes emitted (see the table of correspondences below) When an event occurs, the warning flashes will be issued at each « »...

  • Page 35: Troubleshooting

    22 - TROUBLESHOOTING AKE SURE THAT ALL THE SAFETY DEVICES ARE ENABLED PROBLEM POSSIBLE REASON SOLUTION The operator does not a) Check the connections and the jumpers on the safety edge or stop or photocell a) Check that the N.C. are connected respond to any START inputs, if connected b) Blown fuse...
  • Page 36 PROBLEM POSSIBLE REASON SOLUTION a) Opening control active a) Check if there is an active input among the open inputs b) Pause not set b) Check the pause settings The gate opens but does not c) The closing anti-entrapment protection device is c) Check if there is an active sensor among all the inputs of the anti-entrapment close with TX or closing timer active...
  • Page 37 USER 1 DG MAXI MENU FUNCTIONS TABLE MENU DESCRIPTION DEFAULT NOTES Italiano Italian English English 1 LANGUAGE Français English French Español Spanish Dutch Dutch Start Start Partial START Partial START External module External module Stop Stop Pressed once, it stops the gate.
  • Page 38 MENU DESCRIPTION DEFAULT NOTES The START command is not accepted during pause 8 START IN PAUSE The START command is accepted during pause 9 PROGRAMMING To start up the working times learning To give a START command for testing the operator 10 TEST START (This command can be used only if the unit has already been programmed!)

  • Page 39: Special Menu

    SPECIAL MENU PRESS AT THE SAME TIME FOR 5 SECONDS TO ENTER OR TO EXIT THE SPECIAL MENU SPECIAL MENU DESCRIPTION DEFAULT NOTES 17 OPENING SPEED 1 100% Motor 1 speed in opening 18 CLOSING SPEED 1 100% Motor 1 speed in closing SLOWDOWN SPEED From 30% to 100% Motor 1 slowdown speed in opening...
  • Page 40 SPECIAL MENU DESCRIPTION DEFAULT NOTES The menus 47 - 48 are shown only if the menu 32- ENCODER = ON The menus 51 - 52 - 53 are shown only if the menu 32- ENCODER = Potentiometer 57 WORKING CURRENT …...
  • Page 41 SPECIAL MENU DESCRIPTION DEFAULT NOTES To get the priority in entry (via a START command) or in exit TRAFFIC LIGHT (via a PARTIAL START command) . The function is available RESERVATION only if a traffic light is wired via SEM management unit 90 PARTIAL OPENING 100% Adjustable from 20% to 100%...
  • Page 42 SPECIAL MENU DESCRIPTION DEFAULT NOTES If the photocell is occupied during closing, the gate reverses Closing the movement; If the photocell is occupied during the pause, it prevents the gate reclosing If the photocell is occupied during opening or closing, it stops Opening and closing the gate movement;...
  • Page 43 SPECIAL MENU DESCRIPTION DEFAULT NOTES If the photocell is occupied during closing, the gate reverses Closing the movement; If the photocell is occupied during the pause, it prevents the gate reclosing If the photocell is occupied during opening or closing, it stops Opening and closing the gate movement;...
  • Page 44 SPECIAL MENU DESCRIPTION DEFAULT NOTES SAFETY EDGE 2 Opening and closing Safety edge enabled in opening and closing DIRECTION Opening Only opening Safety edge enabled only in opening Menu available only if Closing the menu 98 is set to Only closing Safety edge enabled only in closing "SAFETY EDGE 2"...

  • Page 45: General Warnings

    PRICES: Prices are based on the Price List in force. Discounts and quotations from Sales Dept. and other selling branches must be approved by SEA. Prices are F.O.B SEA warehouse in Miami and do not include shipment costs. SEA reserves the right to modify the price list at any time and provide notice to its sales network.
  • Page 46 NOTES...
  • Page 48 SEA USA Inc. 10850 N.W. - 21st - unit 160 - Doral - MIAMI - Florida (FL) - 33172 - USA Telephone: ++1 305 594 1151 www.sea-usa.com Compliance with ANSI/UL/CSA 325:2003 (7th Ed., Feb. 21, 2023)
