INSTALLATION INSTRUCTIONS
DXV Modulus
Pressure Balance
Shower Valve Trim Kit
Models D35120500
D35120500RB
To be used with D35000500.191
Pressure Balanced Shower Valve
Thank you for selecting DXV. To ensure that your
installation proceeds smoothly, please read these
instructions carefully before you begin.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work has begun.
TRIM DIMENSIONS:
• For reference
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: (800) 227-2734
www.DXV.com
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2018
™
Hex Wrench
Phillips Screwdriver
(Supplied)
FINISHED WALL
BOTTOM OF
SHOWER HEAD
74" FOR HEAD
CLEARANCE
(OPTIONAL)
(1880 mm)
4-1/8"
(105 mm)
48" TO 54"
OPTIONAL
(1219 TO 1372 mm)
BOTTOM OF
OR SHOWER
Flat Blade Screwdriver
1-5/8" TO 3-1/4"
(41 TO 82 mm)
1/2" NPT
(1829 AND 2134 mm)
7-7/16"
XX" D.
(189 mm)
(XX mm)
4-1/8"
(105 mm)
TUB
STALL
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: 1-800-395-1498
www.DXV.ca
- 1 -
OPTIONAL TO
FINISHED
FLOOR
USUALLY
BETWEEN
72'' AND 84"
In Mexico:
DXV
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx
M965825 Rev. 1.1 (3/18)
Advertisement
Related Manuals for DXV Modulus D35120500
Summary of Contents for DXV Modulus D35120500
- Page 1 Models D35120500 D35120500RB To be used with D35000500.191 Pressure Balanced Shower Valve Thank you for selecting DXV. To ensure that your installation proceeds smoothly, please read these instructions carefully before you begin. RECOMMENDED TOOLS AND MATERIALS Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing supply stores.
- Page 2 INSTALL VALVE TRIM Figure 1. Turn off hot and cold water CAUTION supplies before beginning. VALVE CARTRIDGE • When finished tiling the wall, remove the PLASTER GUARD (1). • Figure 1. Push CAP (2) over VALVE CARTRIDGE until seated against stop. •...
- Page 3 TEST INSTALLED FAUCET • Turn VALVE “off”. • With HANDLE in “off” position, turn on water supplies and check all connections for leaks. • Operate HANDLE and flush water lines thoroughly. DXV Modulus ™ Pressure Balanced Shower Valve Trim Kit...
