V850ES/Jx3-U - Plug it!
32
Demonstration Kit for the V850ES/Jx3-U
32-bit RISC microcontroller
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corp. without notice. Please review the latest information published by
Renesas Electronics Corp. through various means, including the Renesas Technology Corp.
website (http://www.renesas.com).
www.renesas.com
R20UT0582ED0100, Rev. 2.00
March 16, 2011
