Installation Instructions
REV 1 11/01/24
Hardware
Torque Aluminum
M6 Bolt
3 ft-lbs.
M8 Bolt
7 ft-lbs.
M10 Bolt
16 ft-lbs.
M12 Bolt
28 ft-lbs.
Attention: Please make sure that you have the latest instructions
from Romik.com
Torque Steel to Steel
14 ft-lbs.
35 ft-lbs.
64 ft-lbs.
112 ft-lbs.
Part No.
1439
Product: Running Boards
Buick Enclave 2025 – Present
Application:
Level of Difficulty: 1 2
Installation Time: 90 Min.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty. If
you have any questions, please contact our technical
team at 1-866-717-6645
QR Scan
3
4 5
Advertisement
Related Manuals for Romik 1439
Summary of Contents for Romik 1439
- Page 1 Part No. 1439 Product: Running Boards Buick Enclave 2025 – Present Installation Instructions Application: Level of Difficulty: 1 2 Installation Time: 90 Min. REV 1 11/01/24 Hardware Torque Aluminum Torque Steel to Steel ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 3 Important Install Tip: When installing Romik HTC inserts follow the sequence below. Make sure the HTC is seated correctly and do not use power tools as this will only spin the insert and possibly damage it. Test by tugging on it before installing braket.
- Page 4 Installation Instructions 1439 Buick Enclave Step 6: Locate middle bracket position, remove factory rubber plug Figure 4. Figure 4 HTC 311 HTC 243 Step 7: Install provided HTC 311 as shown Figure 5. Figure 5 HTC 311 Step 6: Install provided HTC 243 and Install pre-assembled middle bracket hand tight only Figure 6.
- Page 5 Installation Instructions 1439 Buick Enclave Step 7: Locate rear bracket position Figure 7, Install provided HTC 284. Remove factory rubber plug and install proviced HTC 243 Figure 10. Figure 7 HTC 284 HTC 243 Step 8: Install pre-assembled rear bracket hand tight only as show Figure 8.
- Page 6 2X per year. Wash often with mild soap and make sure to remove all soap residue. Many car automatic carwashes use a strong soap, make sure to use enough water to remove all residue. For video instructions on how to clean your Romik products please click here https://romik.com/cleaning...
