Romik 1011 Installation Instructions

Running boards for audi q7 2004-2015

REV 3 01/08/2020

Hardware

M6 Bolt

M8 Bolt

M10 Bolt

M12 Bolt

Torque Specifications

3 ft-lbs.

7 ft-lbs.

16 ft-lbs.

28 ft-lbs.

ATTENTION: Use correct torque settings to avoid

damaging the running boards and or mounting

brackets. Failure to do so will void your warranty.

If you have any questions please contact our technical

team at 1-866-717-6645

Part No.

1011

Product: Running Boards

Application:

Audi Q7 2004-2015

Level of Difficulty: 1 2

Installation Time: 90 Min

4 5

Table of Contents

Need help?

Do you have a question about the 1011 and is the answer not in the manual?

Page 1 Part No. 1011 Product: Running Boards Application: Installation Instructions Audi Q7 2004-2015 Level of Difficulty: 1 2 Installation Time: 90 Min REV 3 01/08/2020 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs. damaging the running boards and or mounting M8 Bolt 7 ft-lbs.
Page 2 Installation Instructions 1011 Audi Q7 2004-2015 Video Installation Instruction: Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Remove factory crossmember bolt as shown on Figure 1, do not discard as it is re-used Figure 2.
Page 3 Installation Instructions 1011 Audi Q7 2004-2015 Step 5: Locate middle bracket location and hardware Step 6: Install supplied M10 carriage bolt HTC 274 with HTC 269 as shown on Figure 7. Note you may have to remove rubber plug on some models.
Page 4 Installation Instructions 1011 Audi Q7 2004-2015 Step 10: Locate rear mounting area, Note you may have to remove a part of the plastic shield Figure 12 Step 11: Insert HTC 230 with HTC 269 as shown on Figure 13 and Figure 14.
Page 5 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
