Romik 1433 Installation Instructions

Running boards for chevy equinox 2018+, gmc terrain 2018+

Table of Contents

Download this manual

Installation Instructions

REV 1 03/30/20

Hardware

M6 Bolt

M8 Bolt

M10 Bolt

M12 Bolt

Torque Specifications

3 ft-lbs.

7 ft-lbs.

16 ft-lbs.

28 ft-lbs.

ATTENTION: Use correct torque settings to avoid

damaging the running boards and or mounting

brackets. Failure to do so will void your warranty.

If you have any questions please contact our technical

team at 1-866-717-6645

Part No.

1433

Product: Running Boards

Application:

Chevy Equinox 2018+

GMC Terrain 2018+

Level of Difficulty: 1

Installation Time: 60 min

3 4 5

Table of Contents

Need help?

Do you have a question about the 1433 and is the answer not in the manual?

Page 1 Part No. 1433 Product: Running Boards Application: Chevy Equinox 2018+ Installation Instructions GMC Terrain 2018+ Level of Difficulty: 1 3 4 5 Installation Time: 60 min REV 1 03/30/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
Page 2 Video Installation Installation Instructions 1433 Bracket Kit Instruction: Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Install HTC 243 as show on Figure 2 and 4. Install front bracket as shown on Figure 5 and 6. Do not...
Page 3 Installation Instructions 1433 Bracket Kit Step 4: Install HTC 243 as shown Figure 11. Install middle bracket as shown image 12. If you chose option 2 use supplied M8 bolt on inner portion. Do not tighten Figure 12 Figure 11 HTC 243 Step 5: install HTC 240 as shown Figure 13, Install HTC 311 as show on Figure 14 and 15.
Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
