3.4.5 Port G2
3.4.6 Port G5
3.4.7 RSTON

3.5 Configuration summary

ATmega2564/1284/644RFR2
8
The port G2 is not connected to a pin in the ATmega2564/1284/644RFR2. The
alternate pin function AMR (asynchronous automated meter reading input to timer 2) is
not available.
The port G5 is not connected to a pin in the ATmega2564/1284/644RFR2. The
alternate pin function OC0B (output compare channel of 8-Bit timer 0) is not available.
The RSTON reset output signaling the internal reset state is not connected to a pin in
the ATmega2564/1284/644RFR2.
According to the application requirements a variable memory size allows to optimize
current consumption and leakage current.
Table 3-1 Memory Configuration
Device
ATmega2564RFR2
ATmega1284RFR2
ATmega644RFR2
Package and associated pin configuration are the same for all devices providing full
functionality to the application.
Table 3-2 System Configuration
Device
ATmega2564RFR2
ATmega1284RFR2
ATmega644RFR2
The devices are optimized for applications based on the ZigBee and the IEEE 802.15.4
specification. Having application stack, network layer, sensor interface and an excellent
power control combined in a single chip many years of operation should be possible.
Table 3-3 Application Profile
Device
ATmega2564RFR2
ATmega1284RFR2
ATmega644RFR2
Flash
256KB
128KB
64KB
Package GPIO
QFN48 33
QFN48 33
QFN48 33
Application
Large Network Coordinator / Router for IEEE 802.15.4 / ZigBee Pro
Network Coordinator / Router for IEEE 802.15.4
End node device / network processor
EEPROM
8KB
4KB
2KB
Serial IF
2 USART, SPI, TWI
2 USART, SPI, TWI
2 USART, SPI, TWI
42073BS-MCU Wireless-09/14
SRAM
32KB
16KB
8KB
ADC channel
7
7
7
