Sigma Controls Myriad TPC LITE Instruction Manual page 5

 CPU Activity Monitor (Automatic Reset)
 PROGRAMMING:
Menu based, all parameters and setpoints are user configurable via menu prompts and
user keys. The preconfigured screens and 'pull down' sub menus with English prompts
assure rapid setup and commissioning.
 1 YEAR WARRANTY
 OPTIONS:
Expansion cards, networking
Auxiliary Analog I/O PCB with predefined functions
 MODBUS® RTU RS485
Network allows multiple units to be connected together for distributed applications or
remote monitoring SCADA applications.
 EXPANSION CARDS:
Significant expansion is possible via additional control boards and MODBUS®
networking. Up to 128 units may be interconnected, 4000 feet per node.
FEATURES:
 Microprocessor Based
 Graphic LCD Display
 5 Function Keys
 Isolated 24VDC Sensor Power
 4/20MA, 1-5V, 0-5V, 0-10VDC Programmable input
 2 Analog Input
 4 Analog Outputs
 7 Digital Inputs
 4 Digital Outputs
 4 Form 'C' Relay Outputs
 Fully User Programmable in English
 2 Ea. RS485 Ports (Programming and SCADA)
 CPU Activity Monitor
5
