DIAGNOSTIC SCREENS
'In Auto'
Switches
Seal leak input
Press to view the output screen.
Analog output common
for all 3 outputs
Alarm levels
Seal leak alarm
Transducer fail
The diagnostic screens provide information about the current status of inputs and outputs and
provide valuable information to aid in trouble shooting.
The screens show the status of the 'RAW' analog input and output values. These raw values are
approximately the input and output range in the selected input value; as shown, the input is
20.00 MA and the output is 20.00 MA. These values can provide help in determining if the
Myriad TPC LITE is receiving the correct analog input.
INPUTS
'Raw' Analog In
Network Data
Receive
OUTPUTS
Pump run relays
General Alarm
Pump Run / Fail
Network data received
error
Software
Revision Level
Network data buffer full
Network data transmit
