- Page 1 D-Switch Panel Installation Guide...
-
Page 2: Table Of Contents
TABLE OF CONTENTS GETTING STARTED Thank you for purchasing the Diode Dynamics D-Switch Panel for your vehicle. Please read the operating instructions prior to use and observe all GETTING STARTED safety instructions. WHAT’S INCLUDED D-SWITCH PANEL INSTALLATION Mounting The Hub... -
Page 3: D-Switch Panel Installation
Center Wire Hole: 7/8” NOTE: User may need to supply their own M3 x 0.5 screws for thicker surfaces. *NOTICE: Diode Dynamics is not liable for any damages caused by drilling. Vehicle owner is responsible for determining suitable location. www.diodedynamics.com... -
Page 4: Connecting The Hub To The Controller
CONNECTING THE HUB TO THE CONTROLLER CONTROLLER CONTROLLER 1. Connect the Controller Harness to the HARNESS included 3-Meter Extension Harness. NOTE: Align the arrows and DD logos on the M8 connectors, as shown below. 3-METER EXTENSION HARNESS 2. Route the 3-Meter Extension Harness to the Hub and connect it to the Hub Harness. -
Page 5: Connecting The Sensor Wires
CONNECTING THE SENSOR WIRES HOW TO USE QUICK SPLICE The D-Switch includes an Accessory Harness with five bare lead wires. These sensor wires are used to setup automations. The sensor wires require 12VDC discreet signals and will NOT work with CAN, LIN, or CXPI or any other 1. -
Page 6: Connecting The Output Channels
If an output channel will exceed 30A such as a SS5 Pro CrossLink, a winch, or an air compressor, our recommendation is to utilize one of Diode Dynamics’ Heavy Duty or Ultra Heavy Duty relay harnesses. 2. Feed the channel leads through one of the 1. -
Page 7: Controller Overview
CONTROLLER OVERVIEW LABELING THE CONTROLLER BUTTONS By default, each numbered button on the controller is linked to the correlating Sticker sheets are included to label the buttons on the controller. numbered output channel: NITROUS NITROUS STICKER SHEET 1. Thoroughly clean and dry the buttons on the With the Dynamic Channel Assignment feature, the D-Switch can be configured via controller. -
Page 8: Application Guide
APPLICATION GUIDE UNPAIRING THE D-SWITCH 1. Select the menu icon at the top of the main The D-Switch Bluetooth Application can be used to control and program your control screen. This will open the Device List. D-Switch 8-Channel Switch Panel. Search for the D-Switch application in the Apple Store or Google Play store and download it for free. -
Page 9: Using The Control Menu
USING THE CONTROL MENU SWITCHING BETWEEN THE CONTROL AND SETTINGS MENU From the Control Menu, you have complete operational control At the bottom of the app screen, you’ll find two options: Control Menu and of the D-Switch. Settings Menu. Tapping a button icon will toggle it On/Off. When active, the button’s border will highlight to indicate its status. -
Page 10: Configuring The Button And Channel Settings
CONFIGURING THE BUTTON AND CHANNEL SETTINGS Each of the eight buttons in the Control Menu has its own set of configuration options. Linked Channels: This section links channels (also referred to as outputs) to the button. It’s important to note that Button 1 is not fixed to Output 1—any button can be configured to 1. -
Page 11: Configuring The Button Backlight Settings
CONFIGURING THE BUTTON BACKLIGHT SETTINGS The Button Backlight settings control the backlight illumination of the buttons on Button Color & Brightness - Off: the physical controller. These settings allow you to configure the backlight color and brightness levels when a button is in the Off state. 1. -
Page 12: Configuring The Sensor Wire Settings
CONFIGURING THE SENSOR WIRE SETTINGS The D-Switch features four bare sensor wires, which can be configured to All sensor wires, including Night Mode Sensor, automatically turn channel outputs On or Off using vehicle functions. The sensor have the same configuration settings. wires are designed to be connected to OEM vehicle wires or other external triggers Sensor Name: This option allows users to that use a constant +12VDC. -
Page 13: Configuring The Output Channel Settings
CONFIGURING THE OUTPUT CHANNEL SETTINGS Output Channel Settings: Unlike the Button & Channel settings, which configure each Channel Name: Rename the output channel. individual button and its functionality, the eight output channels each have their own distinct properties. 1. From the main Control Menu, select the Settings Menu. -
Page 14: Configuring The System Settings
CONFIGURING THE SYSTEM SETTINGS System Settings includes all global operational settings for the D-Switch that affect Auto Cutoff Input Voltage: The D-Switch the entire unit, rather than individual buttons or channels. continuously monitors the vehicle voltage, which can be viewed on the status bar of the main Control Menu. -
Page 15: Configuring The Firmware Settings
Scan the QR code to see all of our installation videos. Be sure to subscribe to our channel to stay up- to-date on the newest products and videos from Diode Dynamics! www.diodedynamics.com... -
Page 16: Warranty And Contact
3-YEAR REPLACEMENT LIMITED WARRANTY: Diode Dynamics warrants that its products will be free from defects in material and workmanship for a period of three (3) years after the date of purchase, subject to exceptions, limitations, and stipulations. - Page 17 PP0236 D-Switch Panel Installation Guide D-SWITCH INSTALLATION Scan the QR Code below to link to our YouTube Channel! CONTACT US contact@diodedynamics.com | 314-205-3033 10:00-5:00 Monday-Friday, CST 3870 Millstone Pkwy, St. Charles, MO 63301 www.diodedynamics.com...
