Measure lamp height to center
This installation guide is for the following SKUs:
DD6221 Worklight SS3 Sport Type GM Kit White SAE Driving
DD6222 Worklight SS3 Sport Type GM Kit White SAE Fog
DD6224 Worklight SS3 Sport Type GM Kit Yellow SAE Fog
DD6225 Worklight SS3 Pro Type GM Kit White SAE Driving
8
100% SATISFACTION
GUARANTEE
year
w arranty
PP0081
PP0108D
13. Aim your SS3 pods on each side, so that
the top of the beam pattern is on the
cutoff line mark.
14. Tighten the 5/32" allen bolts back down to
complete the installation. Do not overtighten or
use power tools to torque them down.
15. If desired, install the included snap-on cover
onto your SS3. Simply snap the cover onto the
front bezel of the pod. Two different styles are
included. One set won't be used.
Four (4) inches
25 feet
DD6226 Worklight SS3 Pro Type GM Kit White SAE Fog
DD6228 Worklight SS3 Pro Type GM Kit Yellow SAE Fog
DD6690 Worklight SS3 Max Type GM Kit White SAE Fog
DD6691 Worklight SS3 Max Type GM Kit Yellow SAE Fog
Level
Top of
Beam
SS
3" LED Pod
3
Type GM Foglight Kit
