Measure lamp height to center
This installation guide is for the following SKUs:
DD6192 Worklight SS3 Sport Type M Kit White SAE Driving
DD6193 Worklight SS3 Sport Type M Kit White SAE Fog
DD6195 Worklight SS3 Sport Type M Kit Yellow SAE Fog
DD6196 Worklight SS3 Pro Type M Kit White SAE Driving
8
100% SATISFACTION
GUARANTEE
year
w arranty
PP0081
PP0106D
14. Aim your SS3 pods on each side, so that
the top of the beam pattern is on the
cutoff line mark.
15. Tighten the 5/32" allen bolts back down to
complete the installation. Do not overtighten or
use power tools to torque them down.
Four (4) inches
25 feet
DD6197 Worklight SS3 Pro Type M Kit White SAE Fog
DD6199 Worklight SS3 Pro Type M Kit Yellow SAE Fog
DD6688 Worklight SS3 Max Type M Kit White SAE Fog
DD6689 Worklight SS3 Max Type M Kit Yellow SAE Fog
Level
Top of
Beam
SS
3" LED Pod
3
Type M Foglight Kit
